- Page 1 Solar inverter UNO-DM-COM KIT UNO-DM-PLUS Ethernet COM KIT Quick installation guide...
-
Page 2: Principal Components
1. Principal Components Principal components of the accessory board UNO-DM-COM KIT and UNO-DM-PLUS Ethernet COM KIT are shown in the figures and described in the following table: Components supplied with the kit Inverter connector RS485 Line Termination Jumper DRM0 Activation Jumper... -
Page 3: Supplied Component List
Components supplied with the kit Q.ty The expansion board can be inserted directly Accessory Board into the dedicated connector inside the inverter UNO-DM-COM KIT and can also be easily added to a previously installed inverter. UNO-DM-PLUS The installation must be performed by an... -
Page 4: Instructions For Connection
(05) mm) and a gasket with two holes to be inserted inside the cable gland, which allows the passage of two (in case of UNO-DM-COM KIT) or three (in case of UNO-DM-PLUS Ethernet COM KIT) separate cables with a maximum diameter of 6 mm. - Page 5 5.2 Cable connection in inverter versions with wiring box To connect the signal cables to the accessory board is necessary to: - Remove both front covers (wiring box (05) and inverter compartment (04)) - Insert the appropriate water-tight conduit connector on signal conduit opening (15) and tighten to the chassis to maintain NEMA 4X compliance.
- Page 6 To connect the wires to the Alarm (04), RS485 cable are listed in the table below: and REM (06) connector terminals: Type Cable diameter 1) With a flathead screwdriver, hold the button CAT 5E or greather 6 mm max. corresponding to the contact to be wired. The ethernet cable must also be wrapped 2) Insert the cable.
- Page 7 8. Connecting the alarm Using the REM terminal (06), terminal when properly contact and the remote configured, allows the use of the “Remote ON / OFF” or the “DRM0” functions. control The inverter can be disconnected from the grid remotely using the REMOTE ON/OFF function. Characteristics and dimensioning of the This function is enabled in the “INVERTER cable for alarm and remote control contact:...
-
Page 8: Features And Technical Data
READ THE MANUAL – In case of inverter fault, remove and keep any accessory boards installed inside the inverter before shipping it to FIMER. Any accessory board will not be reinstalled in case of inverter replacement. FIMER_UNO-DM-COM KIT & UNO-DM-PLUS Ethernet COM KIT_Quick Installation Guide_EN_RevC...
