7.4

Connecting External Debuggers

Even though there is an on-board debugger, external debuggers can be connected directly to the PIC16F15376
Curiosity Nano to program/debug the PIC16F15376. The on-board debugger keeps all the pins connected to the
PIC16F15376 and board edge in tri-state when not actively used. Therefore, the on-board debugger will not interfere
with any external debug tools.
Figure 7-5. Connecting the MPLAB PICkit
Nano
CAUTION
CAUTION
©
2019 Microchip Technology Inc.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
MPLAB® PICkit™ 4
NC
ID
CDC RX
CDC TX
DBG1
DBG2
The MPLAB PICkit 4 In-circuit Debugger/Programmer is capable of delivering high voltage on the MCLR
pin. R110 can be permanently damaged by the high voltage. If R110 is broken, the on-board debugger can
not enter programming mode of the PIC16F15376, and will typically fail at reading the device ID.
To avoid contention between the external debugger and the on-board debugger, do not start any
programming/debug operation with the on-board debugger through Microchip MPLAB
programming while the external tool is active.
PIC16F15376 Curiosity Nano
™
4 In-Circuit Debugger/Programmer to PIC16F15376 Curiosity
8 7 6 5 4 3 2 1
MCLR
V
Ground
CLOCK DATA
USB
PS LED
DEBUGGER
CURIOSITY NANO
User Guide
1 = MCLR
2 = V DD
3 = Ground
4 = PGD
5 = PGC
6 = Unused
7 = Unused
8 = Unused
DD
VBUS
VOFF
DBG3
DBG0
GND
VTG
®
X or mass storage
