PIC32 USB Starter Kit II
User's Guide
© 2010-2014 Microchip Technology Inc.
DS60001158C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIC32 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microchip Technology PIC32

Summary of Contents for Microchip Technology PIC32

  • Page 1 PIC32 USB Starter Kit II User’s Guide © 2010-2014 Microchip Technology Inc. DS60001158C...
  • Page 2 Total Endurance, TSHARC, UniWinDriver, WiperLock, ZENA and Z-Scale are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. SQTP is a service mark of Microchip Technology Incorporated in the U.S.A. GestIC and ULPP are registered trademarks of Microchip Technology Germany II GmbH &...

  • Page 3: Table Of Contents

    2.1 Hardware Features ..................15 Appendix A. Board Layout and Schematics A.1 PIC32 USB Starter Kit II Development Board Block Diagram ..... 17 A.2 PIC32 USB Starter Kit II Board Layout ............18 A.3 PIC32 USB Starter Kit II Board Schematics ..........20 Appendix B.
  • Page 4 PIC32 USB Starter Kit II User’s Guide NOTES: © 2010-2014 Microchip Technology Inc. DS60001158C-page 4...

  • Page 5: Preface

    This document describes how to use the PIC32 (General Purpose) Starter Kit, PIC32 USB Starter Kit II, and the PIC32 Ethernet Starter Kit (all also referred to as “starter kit”) as a development tool to emulate and debug firmware on a target board. This user’s guide is composed of the following chapters: •...

  • Page 6: Conventions Used In This Guide

    PIC32 USB Starter Kit II User’s Guide CONVENTIONS USED IN THIS GUIDE This manual uses the following documentation conventions: DOCUMENTATION CONVENTIONS Description Represents Examples Italic characters Referenced books MPLAB IDE User’s Guide Emphasized text ...is the only compiler... Initial caps...
  • Page 7 This user’s guide describes how to use the starter kit. The following Microchip documents are available and recommended as supplemental reference resources. PIC32MX5XX/6XX/7XX Family Data Sheet (DS60001156) Refer to this document for detailed information on PIC32 devices. Reference information found in this data sheet includes: • Device memory maps •...
  • Page 8 PIC32 USB Starter Kit II User’s Guide DEVELOPMENT SYSTEMS CUSTOMER CHANGE NOTIFICATION SERVICE Microchip’s customer notification service helps keep customers current on Microchip products. Subscribers will receive e-mail notification whenever there are changes, updates, revisions or errata related to a specified product family or development tool of interest.
  • Page 9 Revision B (December 2010) This revision includes the following updates: • All references to the PIC32 Starter Kit and PIC32 Ethernet Starter Kit have been removed. User information on these two starter kits can be found in their respective user’s guides, which are available from the Microchip web site.
  • Page 10 PIC32 USB Starter Kit II User’s Guide NOTES: © 2010-2014 Microchip Technology Inc. DS60001158C-page 10...

  • Page 11: Chapter 1. Introduction

    Microchip web site at http://www.microchip.com. All project files have been included so that the code may be used directly to restore the PIC32 MCU on the starter kit to its original state (i.e., if the sample device has been reprogrammed with another program).

  • Page 12: Pic32 Functionality And Features

    PIC32 USB Starter Kit II User’s Guide PIC32 FUNCTIONALITY AND FEATURES Representations of the layout of the PIC32 USB Starter Kit II are shown in Figure 1-1 Figure 1-2. The top assembly of the board includes these key features, as indicated in...
  • Page 13 3. Connector for various expansion boards. 4. USB Host and OTG power supply for powering PIC32 USB applications. 5. USB Type Micro-AB receptacle for OTG and USB device connectivity for PIC32 OTG/device-based applications. FIGURE 1-2: PIC32 USB STARTER KIT II LAYOUT (BOTTOM VIEW) ©...
  • Page 14 PIC32 USB Starter Kit II User’s Guide NOTES: © 2010-2014 Microchip Technology Inc. DS60001158C-page 14...

  • Page 15: Chapter 2. Hardware

    This chapter describes the hardware features of the PIC32 USB Starter Kit II. HARDWARE FEATURES The key features of the PIC32 USB Starter Kit II are listed below. They are presented in the order given in Section 1.2 “PIC32 Functionality and Features”.
  • Page 16 2.1.8 120-Pin Modular Expansion Connector The PIC32 USB Starter Kit II has been designed with a 120-pin modular expansion interface, which allows the board to provide basic generic functionality now, and easy extendability to new technologies as they become available.

  • Page 17: Appendix A. Board Layout And Schematics

    PIC32 USB STARTER KIT II USER’S GUIDE Appendix A. Board Layout and Schematics PIC32 USB STARTER KIT II DEVELOPMENT BOARD BLOCK DIAGRAM FIGURE A-1: HIGH-LEVEL BLOCK DIAGRAM OF THE PIC32 USB STARTER KIT II BOARD Power Circuit +3.3V USB OTG Device/OTG +3.3V...

  • Page 18: Pic32 Usb Starter Kit Ii Board Layout

    PIC32 USB Starter Kit II User’s Guide PIC32 USB STARTER KIT II BOARD LAYOUT FIGURE A-2: PIC32 USB STARTER KIT II LAYOUT (TOP ASSEMBLY) © 2010-2014 Microchip Technology Inc. DS60001158C-page 18...
  • Page 19 FIGURE A-3: PIC32 USB STARTER KIT II LAYOUT (BOTTOM ASSEMBLY) © 2010-2014 Microchip Technology Inc. DS60001158C-page 19...

  • Page 20: Pic32 Usb Starter Kit Ii Board Schematics

    PIC32 USB Starter Kit II User’s Guide PIC32 USB STARTER KIT II BOARD SCHEMATICS FIGURE A-4: PIC32 USB STARTER KIT II SCHEMATICS (PIC32MX CPU) © 2010-2014 Microchip Technology Inc. DS60001158C-page 20...
  • Page 21 FIGURE A-5: PIC32 USB STARTER KIT II SCHEMATICS (DEBUG CPU) PIC32MX440F512H...
  • Page 22 PIC32 USB Starter Kit II User’s Guide FIGURE A-6: PIC32 USB STARTER KIT II SCHEMATICS (APPLICATION BOARD CONNECTOR) © 2010-2014 Microchip Technology Inc. DS60001158C-page 22...
  • Page 23 FIGURE A-7: PIC32 USB STARTER KIT II SCHEMATICS (POWER SUPPLY) © 2010-2014 Microchip Technology Inc. DS60001158C-page 23...
  • Page 24 FIGURE A-8: PIC32 USB STARTER KIT II SCHEMATICS (USB OTG/DEVICE POWER SUPPLY)
  • Page 25 FIGURE A-9: PIC32 USB STARTER KIT II SCHEMATICS (USB HOST POWER SUPPLY)
  • Page 26 PIC32 USB Starter Kit II User’s Guide FIGURE A-10: PIC32 USB STARTER KIT II SCHEMATICS (SWITCHES AND LED © 2010-2014 Microchip Technology Inc. DS60001158C-page 26...

  • Page 27: Appendix B. Bill Of Materials

    PIC32 USB STARTER KIT II USER’S GUIDE Appendix B. Bill of Materials TABLE B-1: PIC32 USB STARTER KIT II BILL OF MATERIALS Reference Description Manufacturer Part No. IC SMT, MCP1253,DC/DC Converter 3.3V 8L Microchip MCP1253-33X50I/MS MSOP IC SMT, PIC32MX440F512H-80I/MR 64P QFN...
  • Page 28 PIC32 USB Starter Kit II User’s Guide TABLE B-1: PIC32 USB STARTER KIT II BILL OF MATERIALS (CONTINUED) Reference Description Manufacturer Part No. R5, R19, RES SMT, 330Ω 1/10W 5% 0603 Panasonic ERJ-3GEYJ331V R20, R22, RES SMT, 100 KΩ 1/10W 1% 0603...

  • Page 29: Index

    PIC32 USB STARTER KIT II USER’S GUIDE Index Customer Change Notification Service ...... 8 Starter Kit Board Customer Support ............8 Block Diagram........... 17 Starter Kit Layout Bottom Assembly ........13 Documentation Top Assembly ..........12 Conventions ............6 Starter Kit Schematics Sheet 1 of 3..........

  • Page 30: Worldwide Sales And Service

    Tel: 86-29-8833-7252 Tel: 631-435-6000 Fax: 86-29-8833-7256 San Jose, CA China - Xiamen Tel: 408-735-9110 Tel: 86-592-2388138 Canada - Toronto Fax: 86-592-2388130 Tel: 905-673-0699 China - Zhuhai Fax: 905-673-6509 Tel: 86-756-3210040 10/28/13 Fax: 86-756-3210049 © 2010-2014 Microchip Technology Inc. DS60001158C-page 30...
