4.

Hardware User Guide

4.1

Connectors

4.1.1 PIC16F15376 Curiosity Nano Pinout
All the PIC16F15376 I/O pins are accessible at the edge connectors on the board. The image below shows the kit
pinout.
Figure 4-1. PIC16F15376 Curiosity Nano Pinout
4.1.2 Using Pin Headers
The edge connector footprint on PIC16F15376 Curiosity Nano has a staggered design where each of the holes is
shifted 8 mil (~0.2 mm) off center. The hole shift allows the use of regular 100-mil pin headers on the kit without
soldering. Once the pin headers are firmly in place, they can be used in normal applications like pin sockets and
prototyping boards without any issues.
©
2019 Microchip Technology Inc.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
NC
ID
RD0 CDC RX
RD1 CDC TX
ICSPCLK RB6 DBG1
SW0 RE2 DBG2
TX RC2
RX RC3
SDA RB2
SCL RB1
MOSI RC4
MISO RC5
SCK RC6
SS RD4
GND
TX RB0
RX RB3
RB4
RC7
TX RD0
RX RD1
RD2
RD3
GND
Info: Peripheral signals shown in the image above such as UART, I
shown at specific pins to comply with the Curiosity Nano board standard. These signals can usually be
routed to alteriative pins using the Peripheral Pin Select (PPS) feature in the PIC16F15376.
PIC16F15376 Curiosity Nano
Analog
Debug
I2C
SPI
UART
USB
Shared pinout
PS LED
VBUS
VOFF
DBG3
DEBUGGER
DBG0
GND
PIC16F15376
VTG
CURIOSITY NANO
RA7
RA6
RA5
RA4
RA3
RA2
PIC16F15376
RA1
RA0
GND
RD7
RD6
RD5
RB5
(RC1)
(RC0)
RE1
LED0
RE0
GND
SW0
User Guide
Hardware User Guide
Peripheral
Port
PWM
Power
Ground
RE3 MCLR
RB7 ICSPDAT
ANA7
ANA6
ANA5
ANA4 PWM
ANA3 PWM
ANA2
ANA1
ANA0
SOSCI
SOSCO
LED0
2
C, SPI, ADC, PWM, and others are
