I-130 TS2 HOW TO ORDER PARTS: IMPORTANT Parts must be ordered through your local authorized ASHLAND dealer. Be sure to state MODEL and SERIAL NUMBER of your machine, PART NUMBER, DESCRIPTION and QUANTITY needed. Unless this is done, we cannot provide prompt service or assure shipment of the correct parts. Ashland Industries weldable replacement parts are available to rebuild, modify or update your scraper to current factory specifications.
Page 3
I-130 TS2 SAFETY SIGNAL WORDS Note the use of the signal words DANGER, WARNING and CAUTION with the safety messages. The appropriate signal word for each has been selected using the following guidelines: DANGER: Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. This signal word is to be limited to the most extreme situations typically for machine components which, for functional purposes, cannot be guarded.
Page 4
I-130 TS2 OPERATORS AND MAINTENANCE INSTRUCTIONS This scraper is a durable piece of equipment and with proper care will yield many years of trouble free operation. The scraper requires a power source with TWO 4 way (double acting) hydraulic control valves. The scraper should be greased at all points where grease fittings are provided.
I-130 TS2 Front End Key Number Part Number Description A123292 Front End Assembly A123456 Trunion Mount Block A14039 "Bushing, 2-3/8” OD x 2” ID x 2” Long with Grease passage" A10152A "Frame Attachment Pin, 2” x 8-1/16”" A123292-17 Travel Lock A125006 Safety Snap Pin AFB-00054...
Page 7
I-130 TS2 Apron Assembly Key Number Part Number Description A123341 Apron A123343 Bushing: 2” OD X 1-1/2” ID x 1-3/4” Long AFB-00038 "Bolt, 1-1/2” NF x 5-1/2” long" AFN-00018 "Nut, Self lock 1-1/2” NF" 14505 Grease fitting Page #6 Ashland Industries Toll-free:877-634-4622 Fax:715-682-9717...
Page 8
I-130 TS2 Bowl & Frame Assembly Blade Bolts Required: A123331 (& Ser) PB9P-NC-088-0275 (12) A123332L & R PB9P-NC-088-0275 PB9P-NC-088-0225 A123338L & R PB9P-NC-088-0275 PB9P-NC-088-0225 Key Number Part Number Description A123325 Bowl and Frame I-130TS AFB-00094 "Flange Bolt, 3/8” NC x 1”" A123309-62L Left hand cylinder guard A123309-62R...
Page 9
I-130 TS2 Push Off Gate Assembly Key Number Part Number Description A10159 Brace (L.H. & R. H. same) AFN-00006 Nut: 3/4” NC AFB-00037 Bolt: 3/4” NC x 2” Lg. AFW-00002 Lockwasher: 3/4” 7500 Nut: 1/2” NC A10171 Dirt Shield AFB-00019 Bolt: 1/2”...
Page 10
I-130 TS2 Rear Wheel Spindle & Hub Assembly Key Number Part Number Description A14035 Wheel - 17” x 25” A14008 Lock Ring A14038 O-Ring A14015 Bearing cone (Timken 644) A14014 Bearing cup (Timken 632) A14010 A14013 Bearing cup (Timken 742) A14012 Bearing cone (Timken 749) A14011...
Page 11
I-130 TS2 Apron Cylinder 4" x 13" Part #A125050 Key Number Part Number Description A125050-01 Rod 1-3/4” with welded eye A125050-02 Piston A125050-03 "Gland, Threaded" A125050-04 "Lock Nut, 1-1/8” NF" A125050-05 "Seal Kit, a-f" A125050-05a Nylon Wear Ring A125050-05b FSP Seal A125050-05c O-Ring A125050-05d...
Page 12
I-130 TS2 Lift Cylinder Trunion Mount 5 X 16" Part Number A123324 Key Number Part Number Description A123324-1 2-1/2” Rod A123324-2 Barrel Weldment A125159-34 1-3/4 NF Lock Nut A123324-4 Piston A123324-5 Gland A123324-6 Rod Seal A123324-7 Wear Bond A123324-8 Wear Ring A123324-9 Piston Seal (2-pc.) A123324-10...
Page 13
I-130 TS2 Push Gate Cylinder 4-1/2 Bore x 54 Stroke Key Number Part Number Description A125176-10 Barrel Weldment A125176-20 Shaft A125176-32 Spacer A125176-30 Piston A125176-31 Head A125175-33 1 1/4” Nylock Nut A125176-40 Seal Kit A125175-35 Bearing A125175-36 Snap Ring A125175-37 Grease Zerk 8602 1/4 X 2 Cotter Pin...
I-130 TS2 Hydraulic Manifold Assembly IMPORTANT: This Hyd. Manifold was intergrated into production April, 2006 It replaces A125070 valve. For older machines see master parts book on Ashlandind.com. HYDRAULIC MANIFOLD ASSEMBLY A125174 SETTING THE APRON AND PUSHOFF VALVE The manifold block containing the pushoff sequence valve cartridge and apron sequence valve cartridge is used to control two hydraulic circuits with one hydraulic remote.
I-130 TS2 AINTENANCE HECKLIST 1. Grease all zerks. Every 8 hours of operation. See Lubrication Points section on next page. 2. Greasing the hubs. Re-pack wheel bearings after 600 hrs of operation. Completely clean grease out of hub and bearings every 1200 hours of operation. 3.
I-130 TS2 TROUBLESHOOTING Introduction With proper care and maintenance, the I-110TS will give many years of reliable service. When a situation arises where the earthmover performance is not satisfactory, this section will give some pointers on finding and correcting the problem. Grease zerk will not take grease.
Page 19
I-130 TS2 Apron closes slowly or Apron and push-off are not working well together. 1. Sequence valve needs adjusting. a) Remove acorn nut from end of sequence valve with a ½” wrench. Turn adjustment screw, using a 4mm hex wrench, clockwise until front apron rises before the push-off advances while the earthmover is empty.
Page 20
I-130 TS2 Pushing the Earthmover PUSHING THE EARTHMOVER The I-130TS was designed to be pushed when equipped with the optional push-bar. However, Ashland Industries, Inc. STRONGLY recommends using extreme caution when pushing the I-130TS earthmover to prevent any unnecessary damage. CAUTION! The I-130TS earthmover must be pushed in a straight line with a maximum of a 100 hp dozer.
I-130 TS2 Warranty Statement Limited Warranty Statement Ashland Industries Inc. warrants each new product to be free from defects in material and workmanship. This warranty is applicable only for the normal service life expectancy of the product or components, not to exceed six consecutive months from the date of delivery of the new Ashland Industries product to the purchaser, or the date the product is first put into service via a rental agreement or other means, whichever occurs first.
