- Page 1 MP 110 MP 110TG MP 110 M MP 110 M TG Remote Controllable Control unit DS80MP1A-005B LBT80426...
-
Page 2: Table Of Contents
DK200M Reader ..................p. 5 Input/Output expansions ................p. 5 Accessories ....................p. 6 Installation/connections ................p. 7 MP110: Wall installation of Thermoplastic container ......p. 7 MP110M: Wall installation of Metallic container ........p. 8 Terminal board description ............... p. 10 Inputs ......................p. 11 Outputs .......................p. -
Page 3: System Composition
INPUT 1 INPUT 1 INPUT 2 INPUT 2 INPUT 1 INPUT 1 INPUT 2 INPUT 2 INPUT 1 INPUT 1 INPUT 2 INPUT 2 INPUT 1 INPUT 1 INPUT 2 INPUT 2 MAX 56 INPUTS - 21 OUTPUTS (((ELKRON))) - MP110... -
Page 4: Mp110 Control Unit
1.1 MP110 Control unit • Wire control unit for small and medium size plants equipped with 8 zones max + 1 tamper input + 1 mechanical key input. Expandable up to 56 zones + 5 zones 24H + 4 AUX •... -
Page 5: Kp100D Remote Keyboard
• In every expansion a 24h balanced input, an auxiliary input ,a self-protecting tamper and 4 freely programmable electric outputs are also available. • Expansions are connectable on the control unit serial line (max • For further characteristics please refer to the dedicated technical manual. UR1Z module (((ELKRON))) - MP110... -
Page 6: Accessories
1.6 Accessories • ILT100: interface module for connecting the communicator ( for MP110 control unit only) to the telephone line ILT100 • SV108:voice synthesis module • KV100: voice synthesis kit consisting of microphone and speaker MR02 • MR02: 2 relais module for TTL o OPEN COLLECTOR NH/ NL electrical outputs •... -
Page 7: Installation/Connections
2.0 INSTALLATION/CONNECTIONS 2.1 MP110 : Wall Installation of Thermoplastic container microphone prearrangement for voice breakable synthesis hole with slot hole with slot prearrangement for wall fixing for wall fixing for cable passage 127,5 mm breakable prearrangement for cable passage wall anti-removal... -
Page 8: Mp110M: Wall Installation Of Metallic Container
L i d Wall closing fixing Cable passage Cable Passage 270mm Wall Wall Fixing Fixing ANTI-OPENING/ANTI-REMOVAL MICROSWITCH VITE DI FISSAGGIO DEL COPERCHIO Lid fixing screw to tamper connector on central mother board Anti-tamper CONTATTO contact ANTIMANOMISSIONE 35mm MURO WALL (((ELKRON))) - MP110... - Page 9 1 2 3 4 N.B. In compliance with electric safety regulations, for 230V~ supply a double insulated cable (with double sheath) must be used. Moreover an appropriate switching device must be installed to protect the mains,e.g. a bipolar magnetothermal switch. (((ELKRON))) - MP110...
-
Page 10: Terminal Board Description
(PNP) and is lost in case of alarm. The opposite setting makes output become Zone 2: programmable input NPN,i.e. normally low (0V) at rest, Zone 3: programmable input which is lost in case of alarm. Zone 4: programmable input Zone 5: programmable input (((ELKRON))) - MP110... -
Page 11: Inputs
Input 2 keyboard 1 tamper keyboard 2 Input 1 keyboard 2 tamper keyboard 3 Input 2 keyboard 2 tamper keyboard 4 Input 1 keyboard 3 Input 2 keyboard 3 Input 1 keyboard 4 Input 2 keyboard 4 (((ELKRON))) - MP110... - Page 12 5 seconds. If an intruder gets in from a window there will be an immediate alarm (even if IR is delayed). If he gets in from the door protected by CM the entrance delay will be enabled. (((ELKRON))) - MP110...
- Page 13 An programmed SILENT PANIC input (antirobbery) will activate the corresponding electric panic output for 1 minute. A programmed PANIC WITH SIRENS input (antiaggression) will activate the electric panic output and the alarm relay for 1 minute and the corresponding telephone alarm will be sent. (((ELKRON))) - MP110...
- Page 14 The programming of double AL AL TC TA TA balancing inputs allows to discrimi- nate the 2 events of "zone alarm" and " zone tamper" with the same return wire on the station input. DETECTOR (((ELKRON))) - MP110...
-
Page 15: Outputs
TC1, TC2. TC3 AND Voltage at the Voltage at the output output is +12V if is +12V only if all at least one of the TC’s are present TC’s is present (+12V) (+12V) negative positive command command (((ELKRON))) - MP110... -
Page 16: Dip-Switches
PHASE: BIP! BIP! With station OFF shortcircuit PIN RST for a moment DIP 2/3 COUNTRY SELECTION ITALY SOFTWARE "A" SPAIN FRANCE The product software version is indicated on the control unit Eprom ITALY SOFTWARE "C" GERMANY PORTUGAL (((ELKRON))) - MP110... -
Page 17: Devices Description
Every READER may assume 4 addressed (1 to 4). According to the addressed assigned the opening of the additional zone Z1 Z2 GREEN (yellow wire) or Z2 (green wire) will be identified on keyboard Z1 YELLOW display as shown in the table above. (((ELKRON))) - MP110... - Page 18 A flashing light indicates that burglaries have occurred on one or more parts of the system. A flashing light indicates that there are protected zones (doors or windows protected by contacts) that are still open. A flashing light indicates that some sensors/contacts are disabled. (((ELKRON))) - MP110...
- Page 19 A flashing light indicates that burglaries have occurred on one or more parts of the system. A flashing light indicates that there are some protected zones (doors or windows protected by contacts) that are still open. A flashing light indicates that some sensors/contacts are disabled. (((ELKRON))) - MP110...
- Page 20 INPUT 2 NEGATIVE IF NOT USED ADDRESS TAMPER EXCLUSION DISPLAY VISUALISATION KEYBOARD TAMPER ADDRESSES TAMPER CUTTING OFF KEYBOARD 1 TAMPER TAMPER DISABLED ENABLED KEYBOARD 2 CAUTION DIP SWITCH N.3 MUST BE ALWAYS KEYBOARD 3 IN ON KEYBOARD 4 (((ELKRON))) - MP110...
- Page 21 • The unit must be reset by short-circuiting the reset (RST) pin- strip with dip-switch 1 OFF. (ATTENTION: With dip-switch 1 ON, the unit is reset to factory parameters and loses all its programmings). CONTROL UNIT TERMINALS 1 2 3 4 READER INSERITORI KEYPAD TASTIERE ESPANSIONI EXPANSION (((ELKRON))) - MP110...
-
Page 22: System Running
Code Associated sectors Enabling MASTER code 111111 1-2-3 USER 2 2 22222 1-2-3 INSTALLER 3 33333 1-2-3 SURVEILLANCE 4 44444 USER 5 5 55555 USER 6 6 66666 USER 7 7 77777 USER 8 8 88888 (((ELKRON))) - MP110... - Page 23 The symbol indicates Fire that the zone may be programmed. Associated to sector 1 Associated to sector 2 The white space indi- cates that the zone may Associated to sector 3 not be programmed. Failure input Line control (((ELKRON))) - MP110...
- Page 24 3.1.6 Communicator factory parameters FACTORY PROGRAMMABILITY Transponder Disabled 3 to 15 rings Telephone selection DTMF DTMF/Impulsive Tone control Disabled Disabled/enabled Answer control Disabled Disabled/enabled Routing Disabled Disabled/enabled Protocol IDP/ADF/S1400/C200b/141910/141820/231820/231840/SIA/DGF Answering system skip Enabled Enabled/disabled Communicator enabling OR sectors AND/OR sectors (((ELKRON))) - MP110...
- Page 25 The white space indi- TC3 status cates that the zone may OR of TC1, TC2, TC3 not be programmed. AND of TC1, TC2, TC3 Reset output Buzzer piloting System status Open inputs Telephone line status NH/NL level NPN/PNP type (((ELKRON))) - MP110...
-
Page 26: Access Codes
If the timeout ends, the procedure is automatically terminated without saving the modifications carried out. • In almost all procedures the button sequence is identical for the two models of keypad ( LED and Display). Obviously the mode of the display warnings will change. (((ELKRON))) - MP110... - Page 27 Record messages Association event /channel ing of the F key twice. Association event/number Prog.telephone line options Numeric protocols Prog.timeout cyclic call Prog.delay of telephone alarm Prog. events Calls/answers ring number progr. Event code programming (((ELKRON))) - MP110...
-
Page 28: Visualization Input Status
Segments Keyboard: KP100 B=keyboards If one or more tamperings have been stored, these are indicated by the 0 to 8 flashing of the led. Press the key to display them. The following will be displayed: (see next page) (((ELKRON))) - MP110... - Page 29 . The display shows the control unit model as well as the relevant software version: MP110 A Vx.xx (A= italian or UK or France or Spain version) • Pressing key you visualize the software release of all the equipments connected to the system: Read.
-
Page 30: Exclusion/Inclusion Input
5. LCD keyboard shows the message "ZONE nn SETTED" LED keyboard shows the zone number in a flashing way. To select the following input, press key If there is no excluded input: LCD display shows message “ALL ZONES SETTED ” LED display shows the message: “—” (((ELKRON))) - MP110... -
Page 31: Electronic Key Programming
. From now on, 1 minute time out is activated waiting for the introduction of a key. This timeout is set to zero whenever a key is inserted. The procedure beginning is shown by the led flashing ( LCD or LED keyboard) (((ELKRON))) - MP110... - Page 32 2 flashes slowly waiting for other keys to be programmed, if any. 8. Remove the key. Return to item 4 to program the other keys or press to exit (((ELKRON))) - MP110...
- Page 33 (((ELKRON))) - MP110...
- Page 34 (((ELKRON))) - MP110...
- Page 35 TAMPER ALLARME TAMPER ALLARME TAMPER ALLARME TAMPER ALLARME TAMPER ALLARME TAMPER ALLARME HP12 (((ELKRON))) - MP110...
- Page 36 (((ELKRON))) - MP110...
- Page 37 • keypad with alphanumeric display: “KEY CHECK” • keypad with segmented display: “ ” (flashing”) 3. Press the key. Commutator led 2 flashes slowly to indicate (((ELKRON))) - MP110...
- Page 38 If the key code entred does not correspond to the stored code, all zone leds will flash quickly and the message “UNKNOWN KEY” appears on the alphanumeric displays. Flashing will continue until the key is removed. Press F to exit (((ELKRON))) - MP110...
-
Page 39: User Functions
3. Press the key next to the led to enable/disable the corresponding code. it can also connect and EXIT disconnect 4. Press the key to exit the procedure. (((ELKRON))) - MP110... -
Page 40: Enabling/Disabling Of User Codes 5,6,7 And
. The leds of the associated sectors will turn on in a fixed mode. 6. To modify the association of the sectors of another code, choose it by keys ,then proceed as described from point 3 onwards. EXIT 7. Press key twice to exit and to store the choices made. (((ELKRON))) - MP110... -
Page 41: System Activation/Deactivation By Keyboard
• It is sufficient to introduce the first 2 code digits followed by one of the keys for total activation or for partial TOTAL activation • Quick activation is possible only if the system is fully OFF. (((ELKRON))) - MP110... - Page 42 • In case of introduction of a wrong code for 4 consecutive times, the system visualizes a tamper on the keypads and the readers. When introducing a wrong code for the fifth consecutive time, the system starts a tamper alarm. (((ELKRON))) - MP110...
-
Page 43: System Activation/Deactivation By Electronic Key
(when programmed). With the key permanently inserted, at the end of the fourth cycle, the system exits the procedure and remains in the previous mode. 4. To disarm the system, insert the key and remove it when the leds go OFF. (((ELKRON))) - MP110... -
Page 44: Clock Lcd Keipad
OK beep. When quitting by timeout, the modification is not saved. 4.6.3 Date visualisation PROCEDURE ACCESS 1. Enter MASTER or ENGINEER code EXIT COD. UT.1/3 2. Press in sequence 3. The display will show: PRG DATE dd-mm-yy (((ELKRON))) - MP110... -
Page 45: Clock Segment Keipad
= day of the month • nn where nn = month from 1 to 12 • nn flashing where nn = year from 00 to 99 (00=2000, 01=2001, etc.) • exit from procedure. (((ELKRON))) - MP110... - Page 46 In case of correct data, the new date is stored and the positive result of the operation is confirmed by an OK beep. When quitting by timeout, the modification is not saved. (((ELKRON))) - MP110...
-
Page 47: System Test
5s. To stop the alarm press again or EXIT Note: The test phase is signalled on all keypads and all commutators of the plant by means of appropriate indications on the displays and the slow flashing of the 3 sector leds. (((ELKRON))) - MP110... -
Page 48: Installator Functions
Actions from item 3 will be repeated. EXIT 6. By pressing you leave the procedure and save the modifications made (((ELKRON))) - MP110... -
Page 49: Input Programming
LAST OUTPUT function enabled led on= GONG/CHIME function enabled To enable the function press the corresponding key "Last exit" (see par.12) function can be enabled only if the related input is delayed. (((ELKRON))) - MP110... -
Page 50: Input/Sector Association
“xx” corresponds to the system ON ( even only 1 armed sector). output under reference and “ttttt” cor- responds to the programmed mode. • For all other electric outputs, one of the possible modes can be selected. (((ELKRON))) - MP110... - Page 51 AND/OR sectors mode. Moreover the sectors associated with the The lock positive is missing if at least output under reference are visualized by the corresponding leds one of the associated sectors is armed. that turn on. It is possible to associate (((ELKRON))) - MP110...
-
Page 52: Lpa Output Programming
F = Fire C = Chime associable to LPA output. If Led is on means that the current H = Failure option is associated, viceversa if it is off it means that the option is not associated. (((ELKRON))) - MP110... -
Page 53: Input Time Programming
02 = 2min 07 = 7min EXIT 4. By pressing key you leave programming and assume the desired 03 = 3min 08 = 8min 04 = 4min 09 = 9min value. Leaving by timeout, the previously memorized value is kept. (((ELKRON))) - MP110... -
Page 54: Prealarm Signal Enabling
WITH KEY PROGRAMMED AT LEVEL YOU HAVE LED KEYPAD LCD KEYPAD MODE INPUT OPEN = PLANT ON PULSE KEY PULSE IINPUT CLOSED = PLANT OFF LEVEL KEY LEVEL EXIT 4. After selecting the desired option, exit by (((ELKRON))) - MP110... -
Page 55: Masking Programming
24h inputs are present. OPEN ZONE SELF-BYPASSING: If both commutating lock and self-bypassing have been programmed, the zones left open are automatically bypassed when an arming from keypad or DK key is carried out. (((ELKRON))) - MP110... -
Page 56: Mains Lack Time
(0-1-2-4). 2 = 2 hours EXIT 4 = 4 hours 4. By pressing key , you quit the programming and the chosen status is taken. When quitting by timeout, the previously stored status will be kept. (((ELKRON))) - MP110... -
Page 57: Event Log
KP100D status type of event TEST TOTAL EVENT LED STATUS SIREN ZONE EXIT NB: The sector status and the line status indicate the system status TAMPER SENS. at the moment of the visualized event. (((ELKRON))) - MP110... - Page 58 ZONE PANIC nn Technical TECHNICAL ZONE nn Fire ZONE FIRE nn Zone disabling u nn INSULAT Z.nn Zone enabling u nn SETTED Z.nn Remote zone disabling u nn INSULAT Z.nn Remote zone enabling u nn SETTED Z.nn (((ELKRON))) - MP110...
- Page 59 BUS EXP. 3 BUS Tamper – expansion 4 BUS EXP. 4 NOTE: The BUS tamper events take place both in cae of peripheral disconnection and in case of a connection of a peripheral not present in the plant configuration. (((ELKRON))) - MP110...
- Page 60 NOTE: the event log will include all the inputs tested during the system test phase. The visualized access codes correspond to: u nn= user code (nn: 01-08) k nn= key code (nn= 01-51) m k = mechanical key input sys= operation made by the system (e.g. open zone self-bypassing) (((ELKRON))) - MP110...
- Page 61 Telephone line failure TEL. LINE TAMPER NOTE: For LED keypads the failure element cannot be discriminated = Fuse Fail = Mains return = Telephone line = Power Fail = Battery low = No mains = OK battery (((ELKRON))) - MP110...
-
Page 62: Direct Disply Of Failures
1/2 hour timeout. The network is considered to be present only if present at all control points. The event is displayed clearly on the LCD display, and the message disappears as soon as soon as the cause that triggered has been eliminated. (((ELKRON))) - MP110... -
Page 63: Pc Programming
1. LOCAL via RS232: this connection mode requires a TTL/RS232 optional board. 2. REMOTE mode via telephone line (for MP110TG version or MP110 with ILT100 only). This connection mode requires a modem. Recommended modem models are DIGICOM SNM46 - DIGICOM Raffaello. -
Page 64: Direct Connection Via Rs232
Select the RS232 Direct option from the System File page, and click on the “Call” pushbutton.The message “CONNECTED TO SYSTEM” will be dis- played if connection takes place correctly. Click on the CLOSE pushbutton RS232 direct to terminate connection; the connection selection option returns to the first telephone number. (((ELKRON))) - MP110... -
Page 65: Remote Connection Via Modem
The unit is connected after the first ring. If the transmitted codes do not correspond to the unit’s codes, the modem terminates communication and sends the message: INCORRECT CODE ATTENTION The unit terminates communication after 15’ of connection with the message: TIMEOUT 15’. (((ELKRON))) - MP110... -
Page 66: Technical Characteristics
ON/OFF - Degree of protection provided by casing IP30/ IK 02 TECHNICAL CHARACTERISTICS OF REMOTE KEYPADS KP100 - KP100D LINKED TO MP110 SYSTEM - Rated power supply voltage 12V-(drawn from motherboard - serial line) - Page 67 - Max length of serial line from unit 500 meters* (2x0.75 cable sect. for feeder + 2 x 0.22 x data) - Max number of expansions connectable to the MP110 system 4 (for 8 URIZ modules each + 1 for 24h + 1 for aux. zone)
- Page 68 April 8 , 2000. All the available versions of the Elkron MP110 control unit comply with the R&TTE 99/05 EC Directive. This equipment has been designed to operate with all the PSTN (Public Switched Telephone Network) switched public telephone networks with addressing performed through dual-tone signalling with several DTMF frequencies.
