- Page 1 MP120 MP120TG MP120M MP120M/TG Remote-control alarm control unit IS0175-CH...
- Page 2 The information contained in this document have been collected and checked very carefully. In any case, Elkron S.p.A. will not be responsible for any errors or omissions. Elkron S.p.A. reserves the right to make changes or improvements to the products described in this manual at any time and without advance notice.
-
Page 3: Table Of Contents
1.2.13 KV100 SYNTHESIS KIT...........................10 1.2.14 TTL/RS232 INTERFACE..........................10 1.2.15 IT/USB INTERFACE..........................10 1.2.16 MR02 ................................10 1.2.17 Fast Link ..............................10 2 – INSTALLING THE MP120 SYSTEM........................11 TION PROCEDURE ..........................11 INSTALLA 2.2 FITTING OPTIONAL ITEMS AND ACCESSORIES ..................11 2.2.1 INSTALLING THE PSTN TELEPHONE INTERFACE ................12 2.2.2 INTEGRATING THE voice synthesis ......................12... -
Page 4: Mp120 System
1.1 GENERAL DESCRIPTION 1.1.1 SYSTEM ARCHITECTURE The MP120 system is an antitheft and safety alarm wire system suitable for individual users both in the residential, industrial or service industry fields. The inputs can be configured as unbalanced (N.C.), single-balancing and dual- balancing inputs. -
Page 5: Input And Output Arrangement
• the sectors may be associated to the areas (each sector may belong to several areas); • 3 predefined areas are available (A, B and C). The actuating devices (sirens, blinkers, solenoid valves, presence lights etc.) are connected to the outputs. The outputs may be associated to the inputs, sectors and areas. MP120 5/32... -
Page 6: Max. System Size And Its Respective Expansibility
• 5 alarm outputs in the control unit (one of which of the relay type); • up to 20 electric outputs (4 OC PNP/NPN in the control unit, 16 OC PNP in the expansions). MP120 6/32... - Page 7 8 alarm inputs 1 24-h input 1 mechanic key input 1 relay output TTL/RS232 4 electric outputs INTERFACE 1 weekly time programmer MP120 CONTROL UNIT LOCAL PC auxiliary EP100 EXPANSION inputs 8 alarm inputs 1 auxiliary input 1 24-h input...
-
Page 8: System Components
The keypad address configuration and tamper enable occur by means of dip-switches. The 12 V− power supply is drawn from the connecting bus. A MP120 system shall always include at least one keypad to program and control the system on the spot. MP120... -
Page 9: Dk2000M Inserter
(they shall incorporate the UR1Z interface module for connection to the secondary bus). NOTE. The sensors connected to the expansion shall be powered by the control unit. 1.2.9 UR1Z MODULE This is an interface module to be used with the ES100 expansion. MP120 9/32... -
Page 10: Er20Wl Expansion
1.2.14 TTL/RS232 INTERFACE The TTL/RS232 serial interface module makes it possible to connect, through the RS232 serial port, a PC with the MP120 control unit for local programming, through the Fast Link software. 1.2.15 IT/USB INTERFACE The IT/USB interface module makes it possible to connect, through the USB port, a PC with the MP120 control unit for local programming, through the Fast Link software. -
Page 11: Installing The Mp120 System
8. setting the dip-switches (refer to paragraph 2.3.3 INPUT hardware CONFIGURATION); 9. configuring and testing the system, as described in the programming manual. This sequence minimizes the time required to commission an MP120 system, while ensuring optimum results. 2.2 FITTING OPTIONAL ITEMS AND ACCESSORIES WARNING! The optional items and accessories must always be connected and disconnected when the control unit is not powered. -
Page 12: Installing The Pstn Telephone Interface
Reminder. The control unit MP120TG and MP120M/TG versions incorporate the PSTN telephone interface. To fit the PSTN telephone interface into the MP120 and MP120M control units, plug the interface female connector into the corresponding male connector of the control unit master card. -
Page 13: Installing The Ttl/Rs232 Interface
1. secure the nylon pin (supplied with the unit) into the special hole available on the TTL/RS232 interface card; 2. plug the female connector of the TTL/RS232 interface card into the corresponding male connector of the control unit master card; 3. hook the nylon pin to the special hole available in the control unit master card. MP120 13/32... -
Page 14: Fitting The Control Unit
Supply To install the MP120 and MP120TG control units, proceed as follows: 1. use a pencil to mark the positions of the three fastening holes on the wall, paying attention to the cable run; 2. drill the wall by using a bit at least 6 mm large, then fit the three dowels in;... -
Page 15: Input Hardware Configuration
If the KEY input is used, connect an external switch (for hold-on control) or a button (for impulsive control) to the negative (- S). Either the switch of the button shall be key-controlled due to safety reasons, in accordance with the “IMQ CERTIFICATION - SAFETY SYSTEMS” indications on the last page. MP120 15/32... -
Page 16: Output Hardware Configuration
The Open Collector outputs can be used to control relays or signalling LEDs. The Elkron MR02 module features 2 free-exchange relays (1 A - 24 V) which can be controlled by the OC electric outputs. MP120 16/32... -
Page 17: Connections
Alarm input 1 Alarm input 2 Alarm input 3 Alarm input 4 Alarm input 5 Alarm input 6 Alarm input 7 Alarm input 8 24-h input (for system self-protection) Mechanic key input (normally open, close to negative for switching) MP120 17/32... - Page 18 Normally closed (N.C.) inputs Single-balancing inputs Dual-balancing inputs Important! If a N.O. contact is used for antitheft protection, the IMQ certification will be lost. All the balancing resistors (supplied with the unit) feature 22 kΩ, tolerance: 5%. MP120 18/32...
- Page 19 (not supplied with the unit) may be optionally installed on the telephone line, upstream the control unit. DECLINATORY CLAUSE Elkron S.p.A. decline all responsibility for non-availability, either temporary or permanent, of the PSTN telephone line, which may affect making calls and sending programmed messages. MP120...
-
Page 20: Installing The Keypad
7. Connect the keypad to the bus by means of terminals +, –, CK and D (refer to paragraph 1.1.2 bus for more information), then close inputs Z1 and Z2 to the negative, if they are not used. MP120 20/32... -
Page 21: Installing The Inserter
Jumpers Inserter yellow wire green wire INSERTER 1 INSERTER 2 INSERTER 3 INSERTER 4 3. Connect the inserter to the bus by means of terminals +, –, CK and D (refer to paragraph 1.1.2 bus for more information). MP120 21/32... -
Page 22: Dk3000M Inserter
2.7 EXAMPLES OF CONNECTION DIAGRAMS The diagrams below illustrate the connections for the various devices in a system equipped with N.C. (normally closed) inputs and a system equipped with dual-balancing inputs. MP120 22/32... -
Page 23: Connection Diagram For N.c. Inputs
2.7.1 CONNECTION DIAGRAM FOR N.C. INPUTS UNUSED INPUT MP120 23/32... -
Page 24: Connection Diagram For Dual-Balancing Inputs
2.7.2 CONNECTION DIAGRAM FOR DUAL-BALANCING INPUTS UNUSED INPUT MP120 24/32... -
Page 25: System Maintenance
Prior to replacing the device, actuate the system's maintenance status Replacing a detector or signalling device with an identical one will not involve making new configuration. MP120 25/32... -
Page 26: Restart Bus
• Logo on the display (when the control unit is in stand-by mode) • No mains supply timeout Time might need resetting • Base voice message length after the reset operation has • Call-back telephone call been performed. • Customized denominations • Event file MP120 26/32... -
Page 27: Replacing The Battery
It is recommended that the batteries of the entire system (self-powered sirens, controllers, etc.) are replaced at the same time, since the average life of lead batteries is nearly the same, regardless of their capacity or intended use. MP120 27/32... -
Page 28: Technical Features
4 – TECHNICAL FEATURES MP120 CONTROL UNIT AND PS515 & PS28 (Meanwell S-40-15) POWER SUPPLY Rated supply voltage 230V~ 50Hz +10 -15% (metal versions with PS28) (plastic versions with PS515) Max. current absorption with PS515 250 mA Max. current absorption with PS28 (S-40-15) 500 mA Max. - Page 29 + 2x0.75 cable for connected sensor power supply) Max. number of expansions that can be connected to 4 (for 8 UR1Z modules each + 1 24-h input + 1 for aux. the MP120 system input) DK2000M INSERTER Rated supply voltage...
-
Page 30: Appendix A - Dimensioning
In any case, you should check, by means of a voltmeter, that the voltage measured at the terminals of every single device is not lower than the supply voltage delivered by the control unit or auxiliary power supply – 0.7 V-. MP120 30/32... -
Page 31: Battery Dimensioning
April 8 , 2000. All the available versions of the Elkron MP120 control unit comply with the R&TTE 99/05 EC Directive. This equipment has been designed to operate with all the PSTN (Public Switched Telephone Network) switched public telephone networks with addressing performed through dual-tone signalling with several DTMF frequencies. - Page 32 ELKRON S.p.A. Via G. Carducci, 3 – 10092 Beinasco (TO) – ITALY Tel. +39 (0)11.3986711 – Fax +39 (0)11.3499434 MP120 32/32 www.elkron.it – e-mail: info@elkron.it...
