- Page 1 Models 6PSMT-C02, MMSMT-C02, MMSMT-D02, MMSMT-E02 0.5% Mini Meter in Surface Mount Enclosure with Wireless AMR Option Product Description Technical Specifications Installation Instructions DI-000-MMSMT-00A February 21 , 2014 1.800.544.2843 www.calcert.com sales@calcert.com...
-
Page 2: Table Of Contents
3.9 Testing the Installation ....................15 4. Wireless Automatic Meter Reading ..................15 5.1 Network Activation ......................16 5. Maintenance ........................... 19 6. Troubleshooting/FAQ ......................19 7. Returned Policy/Warranty Information ................21 Leviton Manufacturing Co., Inc. Contents 1.800.544.2843 www.calcert.com sales@calcert.com... -
Page 3: List Of Figures
Figure 1: Mini Meter Surface Mount enclosure dimensions ..........4 Figure 2: Mini Meter connections and display ................. 6 Figure 3: Leviton solid core CTs ....................12 Figure 4: Enclosure installation ..........Error! Bookmark not defined. Figure 5: Mini Meter hookup diagram ..................14 Figure 6: Wireless Network consisting of MDTs, Repeater, DCAP ........ -
Page 4: Product Description
1. Product Description General Description The Leviton 0.5% Mini Meter is a self-powered, current transformer (CT) rated electronic kilowatt-hour (kWh) meter designed for permanent connection to an electrical service. This guide is for use with the 0.5% dual element (1PH 120/240V or 2PH 120/208V, 3-Wire) Mini Meter in a Surface Mount enclosure. -
Page 5: Physical Description
Version 1 MINI METER SURFACE MOUNT INSTALLATION GUIDE 1.4 Physical Description 1.4.1 Mini Meter in Surface Mount Enclosure Figure 1: Mini Meter Surface Mount enclosure dimensions Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com sales@calcert.com... -
Page 6: Tamper Protection
Data Concentrating Access Point (DCAP), where data from a network of meters is stored for on a local computer for billing or energy management functions, or data can be pushed from the DCAP or pulled from remote locations via an Ethernet connection. Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com... -
Page 7: Technical Specifications
EK508-11P or equiv. Table 2: Electrical and environmental specifications Product approved for use with included Leviton Current Transformers, as follows: 200A: Part number CDA01-K12 (black) or CDA01-R12 (red). Pollution Degree 2: Normally only non-conductive pollution occurs. Occasionally, however, a temporary conductivity caused by condensation must be expected. -
Page 8: Input/Output Connections And User Display
Black wire, voltage input, Line 1, 120V with respect to neutral White wire, Neutral input Red wire, voltage input, Line 2, 120V with respect to neutral CT Inputs CT1 : X1 Current Transformer input, CT1. Colored wire of CT1 Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com sales@calcert.com... -
Page 9: Table 3: I/O Connections
Counter (kh = 100 or kh = 1000)* For 12 VDC electro-mechanical counter +12 VDC 12 V DC output @ 3 mA max. Table 3: I/O connections *Recommend Leviton counter MPCTR-1KW (1 kWh models), MPCTR-TKW (0.1 kWh models) or equivalent LED Indicators Description Power LED (green) -
Page 10: Installation Instructions
The following section contains installation and wiring instructions for the Leviton Mini Meter in indoor Surface Mount enclosure. Leviton is not responsible for damage to the meter caused by incorrect wiring. 3.1. Explanation of Warning Symbols Indicates the need to consult the operation manual due to the presence of a potential hazard. -
Page 11: Preparation
Additional wiring for CT or voltage leads extension if needed. Wires must be 18 AWG or thicker and insulated for 300 VAC min. Current Transformers (CTs): This product is designed for use with Leviton CTs; see Section 2.2 for details. -
Page 12: Making Conduit Openings
In accordance with NEC, CTs may not be installed in any panel board where they exceed 75% of the wiring space of any cross- sectional area. Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com sales@calcert.com... -
Page 13: Figure 3: Leviton Solid Core Cts
CT1 on Line 1, CT2 on Line 2); see Figure 5. Leviton solid core CTs (Figure 3): In accordance with CT label, the LINE side of CT must face incoming Line. White lead connects to X2 of CT connection (CT1:X2 or CT2:X2). -
Page 14: Surface Mount Enclosure Installation
7. Mount the enclosure base to the wall with the four screws included. 8. Verify wiring per Sections 3.6 and 3.7 9. After running the tests in Section 3.9, place the cover on the meter and attach with the provided screws. Figure 4A Figure 4B Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com sales@calcert.com... - Page 15 Version 1 MINI METER SURFACE MOUNT INSTALLATION GUIDE Figure 4: Mini Meter hookup diagram Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com sales@calcert.com...
-
Page 16: Testing The Installation
4.1.1 Power: Red wire to meter terminal +12 VDC and black to terminal CNT. 4.1.2 Meter Pulse Input: Green wire to terminal 10 and black to ISOL COM. 4.1.3 Tamper Switch: White and black to tamper proof micro-switch. Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com... -
Page 17: Network Activation
LED indications on a remote Repeater may not provide the useful feedback to the installer that it has successfully joined the Network. Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com... - Page 18 The yellow circle shows where a hidden button is on the enclosure. It may take a few times to get the feel of it, but an LED in the clear window to the right gives you feedback when the button is pushed. Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com...
- Page 19 If no network is present, a device will stay in the slow flash state for 90 seconds then go to sleep for some time before trying to listen again for a beacon. It is highly recommended a device be turned off if no Network is nearby. Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com...
-
Page 20: Maintenance
(see Section 3.7) Ensure that phasing is correct (CT1 on Line 1, CT2 on Line 2) Verify that a load drawing more than 1 Amp is connected to the meter Leviton Manufacturing Co., Inc. 1.800.544.2843 www.calcert.com sales@calcert.com... - Page 21 Q: Can voltage input wires and current transformer secondary leads be routed through the same conduit? A: Yes, provided Leviton supplied CTs are used. Q: I accidentally installed my CTs backwards; can I switch the X1 and X2 terminal connections instead of flipping the CT? A: Yes, but this practice is not recommended as service technicians may believe that meter is wired incorrectly.
-
Page 22: Returned Policy/Warranty Information
3. Original purchase order number 4. Reason for return All paperwork and boxes must be marked with an RMA number issued by Leviton. All authorized returned materials must be shipped freight prepaid to Leviton to the address specified below. Leviton is not responsible for uninsured packages or packages lost by your carrier.
