- Page 1 ECOFLOW RIVER 2 User Manual V1.0...
- Page 2 Once you use this product, it is deemed that you understand, approve and accept all the terms and content in this document. EcoFlow is not liable for any loss caused by the user's failure to use the product in compliance with this user manual.
-
Page 3: Table Of Contents
Content Specifications Safety Instructions EcoFlow App What's in the Box Product Details Overview LCD Screen Power On/Off Charge Your Devices Charge RIVER 2 AC Charging (Grid Charging) Solar Charging Car Charging USB-C Charging Additional Features X-Boost Troubleshooting Care and Maintenance... -
Page 4: Specifications
Specifications General Information Weight Approximately 3.5kg (7.8lbs) Dimensions 245 x 215 x 145mm (9.6 x 8.5 x 5.7inches) Capacity 256Wh (20Ah 12.8V ) Frequency range: Wi-Fi (2.4G) 20M: 2412-2472MHz/40M: 2422-2462MHz Maximum output power: 16.54dBm Frequency range: 2402-2480MHz Bluetooth Maximum output power: 4.71dBm Model EFR600 Input Specifications... -
Page 5: Safety Instructions
17. Do not use unofficial components or accessories as this will void the warranty. Consult official EcoFlow channels if you need to replace any component or accessory. 18. This product is not recommended for powering medical emergency equipment related... - Page 6 AC output to "Never Turn Off" through the EcoFlow app when connecting the power supply product to ensure a continuous power supply. Users should pay attention to the power consumption of the power supply.
-
Page 7: Ecoflow App
Do not modify the plug provided with the product – if it will not fit the outlet, have a proper outlet installed by a qualified electrician. SAVE THESE INSTRUCTIONS EcoFlow App Control, monitor and customize your EcoFlow RIVER 2 from afar with the EcoFlow App. What's in the Box RIVER 2... -
Page 8: Product Details
Product Details Overview ❻ ❺ ❼ ❽ ❹ ❸ ❷ ❶ 1. USB-C input/output port 2. Main power button 3. USB-A output port (×2) 4. DC output switch 5. DC output socket 6. LCD screen 7. AC output socket 8. AC output switch ➓... -
Page 9: Lcd Screen
LCD Screen ❶ ❽ ❷ ❾ ❸ ➓ ❹ ❺ ⓫ ❻ ❼ ⓬ 1. Remaining battery percentage 7. Fan 2. Discharge/Recharge level limitation 8. High temperature warning 3. Remaining charge/discharge time 9. Input power 4. Bluetooth connection 10. Output power 5. -
Page 10: Power On/Off
2. If the product is not used for 5 minutes, it will enter hibernation and the LCD screen will turn off. 3. When RIVER 2 is charging, it can't be turned off by pressing and holding the main power button unless the charging cable is unplugged first. -
Page 11: Charge River 2
1. The solar charging cable (MC4-XT60 adapter cable) and the solar panel are supplied separately. 2. When using an EcoFlow solar panel to charge the product, connect them according to the instructions in the user manual. 3. Before connecting the solar panel, ensure that the output voltage of the solar panel is... -
Page 12: Car Charging
To avoid failure to start due to insufficient car battery, use the car charger after the vehicle is started. In addition, please make sure that the car charger cable is securely connected to the cigarette lighter. EcoFlow takes no responsibilities for any loss or damage caused by failure to follow instructions. 100W Max... -
Page 13: Additional Features X-Boost
(with maximum power <600W) at a time and avoid using multiple appliances at the same time to avoid triggering overload protection. EcoFlow takes no responsibilities for any device failure or data loss caused by failure to follow instructions. -
Page 14: Troubleshooting
If a warning appears during the use of the product and the warning icon persists after restart, please stop using the product immediately (do not attempt to charge or discharge it). For problems not covered in the preceding table, please consult EcoFlow customer service. -
Page 15: Faq
1. What battery does the product use? High-quality LFP battery. 2. What devices can the product's AC output socket power? The rated power of the product is 300W and the peak power is 600W. With the X-Boost feature, the product's AC output sockets can power devices rated at 600W or below. We recommend that you confirm the power of devices before use, and ensure that the sum power of all loaded devices is less than the rated power.
