Takara Belmont Barber Chair
Installation and Operation Manual
Product No. AY-CLIP
Thank you very much for purchasing a product from Takara
Belmont.
Please read through and fully understand this Installation
and Operation Manual to ensure proper use.
Failure to read this Installation and Operation Manual before use
may result in an accident
This product is commercial equipment for use in barbershops and beauty salons.
Do not use for any purpose other than hair and beauty treatments.
Keep this Installation and Operation Manual in a safe place for
future reference.
Contact and inform us of the serial number to request a replacement copy of this
Installation and Operation Manual if illegible due to smearing, tearing, etc., or loss.
November. 2016
CLIPPER
1A0KDMA0
Second edition
Contents
Standard period of use
Availability of maintenance parts
Consumables
Disposal of this product
Daily Inspection Guide
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Takara Belmont CLIPPER AY-CLIP
Summary of Contents for Takara Belmont CLIPPER AY-CLIP
-
Page 1: Table Of Contents
Takara Belmont Barber Chair CLIPPER Installation and Operation Manual Product No. AY-CLIP Contents General Safety instructions Safety precautions Precautions for use Precautions for use of synthetic leather Position of warning label About this product Names of components Accessories Installation procedure... -
Page 2: General Safety Instructions
Stop use in case of a jam or if something feels wrong. When the plating on any part is peeled off, immediately contact Takara Belmont or the In case of a jam or if something feels wrong, nearest dealer for maintenance parts. Continued stop use immediately and contact us, or contact use without repair may result in injury. - Page 3 Safety precautions (Be sure to observe them) WARNING (Continued from previous page) Comply with the following when adjusting the chair height: Be careful when relocating the chair. Before adjusting the chair To relocate the chair, tilt the chair to one side, spread a mat underneath, and pull the mat with the chair on it height, always ensure that according to the “Installation Procedure”...
- Page 4 Safety precautions (Be sure to observe them) CAUTION Do not place any non-human object on the seat. Install on a stable surface. Do not place any non-human Install the chair on a flat, hard floor. Failure to comply may object on the seat. Failure to cause the chair to topple over.
-
Page 5: Precautions For Use
Precautions for use CAUTION Always wipe and dry the floor if wet. Do not wipe with chemicals or apply heat. Failure to comply may result in deterioration or Wipe and dry the floor immediately if it is wet discoloration. In case of chemical spillage on the after shampooing. -
Page 6: Precautions For Use Of Synthetic Leather
Precautions for use of synthetic leather Dye migration from clothes The synthetic leather used in this product may be susceptible to dye migration due to contact with clothes or belts. In case of dye migration, wipe clean immediately to prevent penetration due to plasticizer. Wipe clean using a softcloth soaked with a 10-percent solution of neutral detergent diluted with water. -
Page 7: Names Of Components
Names of components Headrest Backrest Armrest Seat Hook Leg rest Step Gooseneck Adjuster Headrest retraction button Reclining lever Main body of the chair The reclining lever may be on the right or left side depending on the destination of delivery. (A right-side lever type is shown here.) Foot pedal... -
Page 8: Installation Procedure
Installation procedure About the chair installation space Install the chair with space sufficient for rotation. The range of rotation for the chair is as shown to the right. Center of rotation Install on a stable surface. Install the chair on a flat, hard floor. Failure to comply may cause the chair to topple over. Look round before turning the chair around. - Page 9 Installation Procedure Continued from previous page (1) Using the L-shaped wrench (size 6), slightly loosen Screws A fixing the step to the gooseneck. (Screw A is found on each of the left and right sides.) Gooseneck Screw A (M8) L-shaped wrench Step (size 6) (2) Fold the step forward to fix it to the gooseneck...
- Page 10 Installation Procedure Installing the adjuster Screw the step adjuster into the step, adjust the step to Step an appropriate height, and tighten and fix the nut fitted to the adjuster to the step using the WAF-17 spanner. Adjuster...
- Page 11 Installation Procedure Continued from previous page Inserting the headrest Press down the headrest retraction button Headrest to insert the headrest in place. Be careful with the orientation of the headrest (front-to-back orientation). Headrest retraction button Relocation of the chair Tilt the chair to one side to spread a mat underneath to prevent damage to the floor.
-
Page 12: Read Before Use
Read before Use This product comes complete with a step for the feet. The following instructions contain important information on the step to ensure safe use of the product. Be sure to comply with these instructions. WARNING Comply with the following when Bring the chair to its lowest position for the adjusting the chair height: customer to sit on and get up from it. -
Page 13: Operating Instructions
Operating instructions Guiding the customer into the chair Turn the chair to a position most convenient for the customer. Guide the customer to the chair. Bring the chair to its lowest position to help the customer to get seated on it. Step lightly on the foot pedal to unlock the chair. -
Page 14: Adjusting The Chair Height
Operating instructions Adjusting the chair height Adjusting the chair height up Step on the foot pedal lightly in succession to adjust the chair height up slowly. Carefully avoid stepping too hard. Failure to comply will result in the lowering of the chair height. Adjusting the chair height down To adjust the chair height down, step hard on the foot pedal to the lowest position. -
Page 15: Headrest Adjustment And Mounting/Removal
Operating instructions Headrest adjustment and mounting/removal Press down the headrest retraction button to insert the headrest. Without pressing down the headrest retraction button, the headrest cannot be inserted in place. Headrest retraction button Adjust the headrest to the customer’s head height. Headrest retraction button The headrest height can be adjusted in six steps up and down. -
Page 16: Reclining And Raising The Backrest
Operating instructions Reclining and raising the backrest The backrest can be unlocked by operating the reclining lever. The backrest can be moved only while the reclining lever is pulled down in the direction indicated by the arrow. When reclining the backrest Pull the reclining lever down in the direction indicated by the arrow and recline the backrest slowly with a hand... -
Page 17: Daily Maintenance Procedure
Daily Maintenance Procedure After a day’s work, perform daily maintenance on the chair. Failure to clean the chair may result in mold growth. Never use thinner, alcohol, gasoline, kerosene, or any other volatile chemical, abrasive-containing wax or sponge, organic solvent-containing cleaners, acid, alkali, or chloride-based cleaners, or cleaning tools, such CAUTION Thinner... -
Page 18: Specifications
Specifications Product number AY-CLIP Weight Main body of the chair 44 kg (97 lb) Reclining angle 30° as reclined to 75° as raised Load capacity 1,350 N (135 kgf, 298 lb) Upholstery material PVC leather 1545 15 1085 15 250 10 Unit: mm (Unit in [ ]: inches) 380 3 Chair with SLIM-R BASE (AN-B5110) - Page 19 About the standard period of use The standard period of use of this product is seven years. The standard period of use is the standard period for safe use of a product used under the product-specific normal conditions and subjected to proper maintenance and inspection (including parts replacement).
- Page 20 Ensure that the backrest stops and If the backrest fails to stop, stop use immediately remains still at a desired position. and contact Takara Belmont or the nearest dealer. No oil leaks? Ensure that there are no oil drops on the The hydraulic parts may be leaking oil.
