- Page 1 Magellan™ 3410VSi OEM INTEGRATION GUIDE Omni-Directional Imaging Scanner...
- Page 2 Electronic versions of this document may be downloaded from the Datalogic website (www.datalogic.com). If you visit our website and would like to make comments or suggestions about this or other Datalogic pub- lications, please let us know via the "Contact" page.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER 1. INTRODUCTION..................1 Overview ......................... 1 Reference Documents ...................... 1 Unpacking the Scanner ..................... 2 Technical Support ......................2 Website ..............................2 Reseller ..............................2 Scanner Care ............................2 System Overview ......................3 Beeper indicators ......................3 CHAPTER 2. MOUNTING THE SCANNER ..............4 General Considerations .................... -
Page 4: Chapter 1 Introduction
CHAPTER 1 INTRODUCTION This document provides instruction, mechanical details, and design considerations to integrate the Magellan 3410VSi OEM scanner into equipment-integrated scanning appli- cations. OVERVIEW The Magellan™ 3410VSi OEM is designed for retail checkout environments where there is a relatively high number of transactions with a fairly small number of items per trans- action. -
Page 5: Unpacking The Scanner
TECHNICAL SUPPORT Website Datalogic provides several services as well as technical support through its website. Log on to www.datalogic.com. For quick access, from the home page click on the search icon, and type in the name of the product you're looking for. This allows you access to download Data Sheets, Manu- als, Software &... -
Page 6: System Overview
Refer to the 3410VSi Product Reference Guide for a list of these indications. The scan- ner's functions are programmable, and so may or may not be turned on. For example, certain indications such as the power-up beep can be disabled using programming bar code labels. MAGELLAN 3410VSI OEM... -
Page 7: Chapter 2. Mounting The Scanner
CHAPTER 2 MOUNTING THE SCANNER This section describes how to design the mounting for optimum scanner performance. GENERAL CONSIDERATIONS A typical system uses the scanner mounted inside a host enclosure, with an opening for the scanning pattern to exit and read bar codes. The opening should be the size of the scanner window at a minimum, but only exposing as much of the scanner as necessary. -
Page 8: Integrating The Scanner To Read At The Proper Distance
Ensure that there are no reflective surfaces around the area of the scanner open- ing. • The opening or other parts of the host enclosure must not enter the Field of View in order to allow the bar code image to be captured by the scanner. MAGELLAN 3410VSI OEM... -
Page 9: Housing Design
HOUSING DESIGN HOUSING DESIGN The enclosure must be designed to prevent internal reflections from illumination and aiming systems into the receiving optics. It is not recommended to place any type of additional window between the scanner and the bar code to be read. The housing design must provide adequate ESD protection for the scanner. -
Page 10: Exit Window Clearance
The enclosure wall thickness should not exceed 0.38 in to prevent clipping of the FoV, as shown in Figure 2-2 on page 7 Figure 2-2. Exit window clearance USE 3/8" (9.7mm) OR THINNER MATERIAL TO AVOID CLIPPING OF SCAN PATTERN. MAGELLAN 3410VSI OEM... -
Page 11: Chapter 3. Electrical Integration
CHAPTER 3 ELECTRICAL INTEGRATION The scanner is protected from ESD up to ±2.0KV on the host connector. During installation, it is recommended to apply standard ESD handling procedures, such as operating in a properly grounded working area using wrist straps. ELECTRICAL INTERFACE The scanner can be connected to various interfaces, supporting: •... -
Page 12: Supply Voltages
5V-12V DC Input scanner is attached to the Aux port. Please use only Datalogic brand power supply. 5V DC provided by the POS connector when the USB interface is in use. Note that the USB inter-... -
Page 13: Usb Aux Port Interface
2.0 specification. Both FAT16 and FAT32 formats are supported. Filenames are limited to the 8.3 file naming format (i.e., FILENAME.EXT), and MUST be capitalized. MicroSD Function Summary The following table summarizes various functions of microSD card. Contact Datalogic Technical Support regarding upgrade license for new features. LOAD... -
Page 14: Appendix A. Technical Specifications
10 mil PDF: 0 to 12.7 cm / 0 to 5.0 in 2D Codes 10 mil Datamatrix: 0 to 6.4 cm / 0 to 2.5 in 20 mil Datamatrix: 0 to 18.0 cm / 0 to 7.0 in MAGELLAN 3410VSI OEM... -
Page 15: Electrical Parameters
ELECTRICAL PARAMETERS ELECTRICAL PARAMETERS PARAMETER SPECIFICATION Input voltage 5 to 12 VDC Operating Voltage Note: 12V power can only be applied to the DC input power port Power Consumption: 2.25W @ 5V; 3.3W @ 12V • Maximum • Typical (RMS) 1.6W @ 5V;... -
Page 16: Appendix B. Mechanical Specifications
APPENDIX B MECHANICAL SPECIFICATIONS PHYSICAL CHARACTERISTICS PARAMETER SPECIFICATION 12.7 x 14.4 x 7.8 cm Dimensions 5 x 5.7 x 3.1 in 0.3 kg Weight 0.8 lb Figure B-1. Scanner dimensions Magellan 3410VSi OEM... -
Page 17: Mounting Template
MOUNTING TEMPLATE MOUNTING TEMPLATE The Mounting Template in the following page shows the mounting holes for the scan- ner. NOTE: the Mounting Template drawing must be printed actual size to ensure proper dimensions. INTEGRATION GUIDE... - Page 20 © 2022 Datalogic S.p.A. and /or its affiliates • All rights reserved • Without limiting the rights under copyright, no part of this documentation may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means, or for any purpose, without the express written permission of Datalogic S.p.A.
