Assembly Instructions
Step 18
Prepare the doors
a:
Fit 2 hinge plates
onto the carcase door
. , making sure that
9
they face the same way
as the diagram.
b:
Push fit 2
cantilevered hinge arms
. into the carcase door
M
. .
9
Secure each hinge arm
with 2 screws .
D
Note: Before securing
with the screws, make
sure that the hinges are
positioned at 90 degrees
with the front edge of the
door.
Push hole plugs
Q c
into the 2 unused hinge
holes.
c:
Push fit 2 bent hinge
arms into the hinged
N
door .
8
Secure each hinge arm
with 2 screws .
D
Note: Before securing
with the screws, make
sure that the hinges are
positioned at 90 degrees
with the front edge of the
door.
Push hole plugs
R c
into the 2 unused hinge
holes.
17
RICARDI DOORS ONLY - RIGHT SIDE HINGE PLATES
Only follow this step if
you have fitted the hinge
K
plates to the RIGHT side
a:
K
b:
R c
c:
N
(see step 1).
K
H=2 H=4
Q
D
D
M
M
9
D
D
D
D
8
K
K
D
D
Arch at
this end
N
Arch at
this end
9
Arch at
this end
M
90
N
90
R c
