Troubleshooting

5
Symptom
Analogue Mode WMC01 displays "HOST
COMMS LOST"
IP Mode WMC01 displays "HOST COMMS
LOST"
WMC01 stuck in "Please wait":
WMC01 stuck in "Please wait":
WMC01 – User's Manual
Fix
Ensure the WMC01 interface cable is connected to the correct audio input
port on the VIPEDIA-12 or Integra device.
Connect the WMC01 interface cable to the Router 1 connection on the
WMC01.
Reload the PAVA SCT configuration file using the File Transfer Tool. The
device will reboot.
Once the device reboots move the cable to the Router 1 connection.
Check the WMC01 unit is in the same network as the host VIPEDIA-12.
Verify the MAC address is entered correctly in the PAVA SCT
1) Check connections as described above.
2) If still no comms, re-load configuration into host VIPEDIA-12 unit.
3) Power cycle the WMC01 unit and clear faults on the VIPEDIA-12 unit.
4) If still no comms, reset the WMC01 configuration and re-commission
the unit.
To reset the WMC01 configuration:
Set DIP switch 2 on the rear of the WMC01 to 'UP'
a)
b) Press the
c) Use
d) Select CFG DEFAULT and deselect ASL CONTROLLER (if
selected).
e) Press
f) Configuration will be reset and unit will reboot.
g) Set DIP switch 2 down.
U-0664-0833-WMC_User_Manual.docx – Issue: 02 complete, approved
Page 16 of 20
button.
keys to navigate to the MISC SETTINGS tab.
to confirm.
