522HS, 522SA
Ballina
Hand Shower/Shower Arm
™
Operation & Maintenance Manual
Model Numbers
522HS
Hand Shower Assembly
522SA
Shower Arm
Modifications
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-BBZ
Brushed bronze finish
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
Modifications
522HS
A
522SA
C C
A
Note: Dimensions are subject to change without notice.
Symmons Industries, Inc.
©2014 Symmons Industries, Inc.
Specifications
Hand shower assembly includes 3 mode hand shower
with standard 2.5 gpm (9.5 L/min) flow restrictor. Hand
shower assembly and shower arm components are made
from metal and nonmetallic materials plated in standard
polished chrome finish.
Compliance
-ASME A112.18.1; CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
B B
D D
■
■
31 Brooks Drive
Braintree, MA 02184
■
■
www.symmons.com
gethelp@symmons.com
Measurements
A
Ø 2 1/2", 64 mm
1/2" IPS thread must protrude
B
1/2" from finished wall
C
2 1/4", 57 mm
D
7 1/2", 191 mm
■
■
(800)796-6667
Fax: (800)961-9621
■
ZV-3088 REV 0 09/18/14
