ENFORCER SD-7157-SSTQ Manual

ENFORCER SD-7157-SSTQ Manual

Dual-color vandal-resistant rte plates with buzzer and timer

Advertisement

Quick Links

Dual-Color Vandal-Resistant RTE
SD-7157-SSTQ
SD-7157-SSTQ
SD-7257-SSTQ
SD-7357-SSTQ
Features:
• 12~24 VDC Operation
• 3 Operating modes: Timed (0.5-60 s), toggle,
and momentary
• Pushbutton can still operate as a momentary
mechanical switch when power is lost
• Buzzer volume: 80dB max., adjustable
*European faceplate version is English only
Plates with Buzzer and Timer
SD-7257-SSTQ
Brushed stainless slimline faceplate with English and Spanish
Brushed stainless single-gang faceplate with English and Spanish
Brushed stainless European faceplate with English*
Manual
• Reminder function, LED flashes and buzzer sounds
for last 4 seconds of timed output
• "EXIT" and "SALIDA" silk-screened on plate*
• Vandal-resistant, ø1
illuminated pushbutton
• LED colors: Red on standby, green on activation
®
SD-7357-SSTQ
3
/
" (ø30mm) dual-color,
16

Advertisement

loading
Need help?

Need help?

Do you have a question about the SD-7157-SSTQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ENFORCER SD-7157-SSTQ

  • Page 1 Dual-Color Vandal-Resistant RTE Plates with Buzzer and Timer Manual SD-7157-SSTQ SD-7257-SSTQ SD-7357-SSTQ SD-7157-SSTQ Brushed stainless slimline faceplate with English and Spanish SD-7257-SSTQ Brushed stainless single-gang faceplate with English and Spanish SD-7357-SSTQ Brushed stainless European faceplate with English* Features: • 12~24 VDC Operation •...
  • Page 2 ENFORCER Dual-Color Vandal-Resistant RTE Plates with Buzzer and Timer Introduction: The ENFORCER Dual-Color Vandal-Resistant Request-to-Exit Plates with Buzzer and Timer use a stainless steel vandal resistant button, are illuminated by a circular perimeter LED, and include built-in adjustable buzzer and timer. For indoor use only.
  • Page 3 ENFORCER Dual-Color Vandal-Resistant RTE Plates with Buzzer and Timer Basic Installation: Wiring Diagram: 1. Run wires through the wall to the back box. 2. Connect the wires from the back box to the Red wire: +12~24 VDC switch plate according to the wiring Black wire: Ground (-) diagram, right.
  • Page 4 ENFORCER Dual-Color Vandal-Resistant RTE Plates with Buzzer and Timer Sample Installation: Basic Installation with Fail-Safe Electromagnetic Lock and Keypad SECO-LARM Series Digital Keypad Electromagnetic Lock 12/24 VDC Access Control Power Supply RTE Plate (+) (–) – terminals GN GN BK RD...
