ENFORCER RINS1708-3 Installation & Reference Manual

Wireless alarm system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN50131-1:2006+A1:2009
EN50131-3:2009
EN50131-6:2008
EN50131-5-3:2005+A1:2008
Security Grade 2
Environmental Class II
Software Version >10
Installation Reference Manual
Wireless Alarm System
RINS1708-3
INTERNAL SIREN WARNING
The Enforcer 32-WE control panel
contains a 100 dBA siren,
please be aware of this during
installation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RINS1708-3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ENFORCER RINS1708-3

Summary of Contents for ENFORCER RINS1708-3

  • Page 1 EN50131-1:2006+A1:2009 EN50131-3:2009 EN50131-6:2008 EN50131-5-3:2005+A1:2008 Security Grade 2 Environmental Class II Software Version >10 Installation Reference Manual Wireless Alarm System RINS1708-3 INTERNAL SIREN WARNING The Enforcer 32-WE control panel contains a 100 dBA siren, please be aware of this during installation...

  • Page 2: Table Of Contents

    5.5 DIGI-GPRS (GPRS Modem) ....................19 5.1 DIGI-LAN (LAN Module) ....................... 20 5.2 DIGI-1200 (PSTN Modem) ....................21 5.3 Replacing The Battery of Enforcer 32 WE ................22 6. EN 50131 Terminology ......................22 7. Access Levels ......................... 22 8. NOTES ..........................23...

  • Page 3: Introduction

    2. Introduction The Enforcer is the first two way wireless high security wireless system on the market. It can only be compared to an addressable wired system, but instead of using a wired data bus it uses a wireless one.

  • Page 4: Initial Power Up

    3. Initial Power Up NOTE 1: It is recommended that the Engineer menu is accessed prior to opening a powered Enforcer 32- NOTE 2: If any new peripheral is installed (i.e. Modem, I/O board, Expander) it is recommended that the Enforcer 32-WE is powered down (mains and battery).

  • Page 5: Inside Of The Enforcer 32-We: Rear

    4. The rear tamper adjustment screw is used if the tamper from the front of the Enforcer 32-WE isn't sitting flush to the back plate - this may happen if the Enforcer 32-WE is installed on an uneven surface. 5. If an I/O board is installed, then this space is used to install it.

  • Page 6: Connecting / Replacing The Control Panel Battery

     Ensure that the Input and Output Board (I/O Board) used to connect wired keypads, readers, inputs and outputs to the Enforcer 32-WE, is only connected to circuits operating at SELV voltage.  When securing external wires, ensure that means are provided in the installation to prevent the SELV or signal circuits from coming into contact with live parts of the power supply circuit.

  • Page 7: Technical Specification

    Load Comms Time 40mS + 40ms Battery Type (KF) BATT-CR1/3N(KF4 MK2) Battery Type (PIR) BATT-CR123A EN 50131 Grade 2: Certified devices Battery Type (UT) BATT-CR2 Enforcer 32-WE with input/output board KX10DP-WE KX12DQ-WE MC1-WE MC2-WE KF4-WE DELTABELL-WE KX12DT-WE DIGI-1200 KX10DTP-WE KX25LR-WE...

  • Page 8: Installation Guide

    LCD keypads, readers, expanders etc. are connected via the D1-, D2+, D3 and D4 terminals. This is an example of what a typical Enforcer bus may look like. General Principles: NOTE 1: No alarm system cable should be run with other cables carrying AC or digital signals.

  • Page 9: Wiring Peripherals To The Rs485 Bus

    4 x Keypads/Readers (same bus): PCX-LCD/EX, PCX-PROX/INT, and PCX-PROX/E 5.1.2 Wiring Keypads Up to 3 additional keypads can be connected to the Enforcer 32-WE. These will be addressed individually and also addressed in the Engineer function '‘Assign Keypads / Readers’.
  • Page 10 5.1.3 Wiring Internal Readers PCX-PROX/INT Up to 3 readers can be connected to the Enforcer 32-WE. Each reader needs to be addressed as described below. These will also need assigning in the Engineer function '‘Assign Keypads / Readers’. Addressing at the Reader Address 1 = SWITCH 1 ON.
  • Page 11 5.1.5 Wiring a Wired External Sounder To create the bell tamper circuit, a resistor is required across 0V supply and tamper circuit of the bell box. Note that the input must be programmed as ‘tamper’. The resistor value is 1K as shown in the diagram above.
  • Page 12 RIX Address 2 (Inputs 51-58), RIX Address 3 (Inputs 59-66). 5.1.8 Connecting an Output Expander 1 x Remote Output Expander can be connected to the Enforcer 32-WE. Each output expander allows 16 additional outputs NOTE: The above shows the I/O board connected to a PCX-ROX8R8T. If using a PCX- ROX16R+PSU+ PSU, the D2+ MUST NOT be connected.

  • Page 13: Entry Control With The Internal Tag Reader

    5.2 Entry Control with the Internal Tag Reader 5.2.1 Connecting the Push to Exit Button (Entry Control) 5.2.2 Connecting the Mag Lock Control (Entry Control) Page: 13...
  • Page 14 5.2.3 Arming with Entry Control Action Visual Sequence Present a valid tag to the The door lock will open reader and then remove it. Present the same tag to the reader within 10 seconds, The system will set after the and then remove it.

  • Page 15: Entry Control With The External Tag Reader

    5.3 Entry Control with the External Tag Reader 5.3.1 Connecting the Push to Exit Button (Entry Control) 5.3.2 Connecting the Mag Lock Control (Entry Control) Page: 15...
  • Page 16 5.3.3 Arming with Entry Control Action Visual Sequence Present a valid tag to the The GREEN LED will reader and then remove it. illuminate and if programmed, the door will unlock. Present the same tag to the The RED LED will illuminate reader, and then remove it.

  • Page 17: Connecting To Insite Software

    5.4 Connecting to Insite Software Enforcer 32-WE control panel can be programmed by the LCD menu or the UDL InSite Software provided free of charge. It can be downloaded from http://www.pyronix.com/pyronix-downloads.php. The connection between control panel and UDL software can be done in the following ways: 5.4.1 GPRS Connection (DIGI-GPRS)
  • Page 18 The PSTN card (DIGI-1200) fits inside the Enforcer 32WE and is used for the following operations: Send Alarms to the ARC: It is possible to send alarm events to the monitoring station via the Contact ID and SIA Level 1 and Level 3.

  • Page 19: Digi-Gprs (Gprs Modem)

    IMPORTANT NOTE: TURN OFF THE MAINS & BATTERY BEFORE DISCONNECTING GPRS MODEM The GPRS modem card is used to enable the Enforcer 32-WE to communicate either via Contact ID or SMS texts via a SIM card. It will also enable remote uploading/downloading.

  • Page 20: Digi-Lan (Lan Module)

    5.1 DIGI-LAN (LAN Module) The DIGI-LAN Module is used to communicate over a Local Area Network to either InSite, Pyronix Cloud, or to an ARC. NOTE: The product has been approved as supplied. If the communications module is replaced with a different model (besides our GSM or PSTN modem), then the certification will be void.

  • Page 21: Digi-1200 (Pstn Modem)

    IMPORTANT NOTE: TURN OFF THE MAINS BEFORE DISCONNECTING THE PSTN MODEM The PSTN modem card is used to enable the Enforcer 32-WE to communicate either via contact ID, Fast Format, SIA or SMS texts via a telephone line. It will also enable remote uploading/downloading.

  • Page 22: Replacing The Battery Of Enforcer 32 We

    5.3 Replacing The Battery of Enforcer 32 WE To ensure meeting the specification the Enforcer 32WE backup battery should be replaced by a Pyronix battery. The code for this battery is BATT9V6/2.1Ah-WE. Open the battery holder cover. Install the batteries in the space provided and...

  • Page 23: Notes

    8. NOTES Page: 23...
  • Page 24 Pyronix Ltd. Secure House Braithwell Way Hellaby Rotherham S66 8QY Customer Support line (UK Only): +44(0)845 6434 999 (local rate) or +44(0)1709 535225 Hours: 8:00am - 6:30pm, Monday to Friday Email: customer.support@pyronix.com Website: www.pyronix.com...
