- Page 1 Installation Sequence Expansion Cityline Installation Guide / Guide d'installation Séquence d'installation JNSASW, JNSASH, JNSAGW, JNSAGH, JNSAFW, JNSAFH & JNSAEW, JNSAEH Add-on Screen - Desk mounted/Panneau séparateur - Sur surface CTL301 402102 Install all brackets on the same side #8 x 1''...
- Page 2 Installation Sequence Expansion Cityline Installation Guide / Guide d'installation Séquence d'installation JNSASW, JNSASH, JNSAGW, JNSAGH, JNSAFW, JNSAFH & JNSAEW, JNSAEH - Add-on Screen - Desk mounted/Panneau séparateur - Sur surface CTL301 SOLID/SOLIDE B02-81017 X80-81001 X80-81006+XX (A25-81028) E04-50105 7.85 x 16mm...
- Page 3 Installation Sequence Expansion Cityline Installation Guide / Guide d'installation Séquence d'installation JNSASW, JNSASH, JNSAGW, JNSAGH, JNSAFW, JNSAFH & JNSAEW, JNSAEH - Add-on Screen - Desk mounted/Panneau séparateur - Sur surface CTL301 GLASS/VERRE B02-81014R Black Piece Noire X80-81008+XX JNWWSSNYYXX JNSAGW If two screens are side by side and they are not aligned, slide a B02-81021 clip between them.
- Page 4 Installation Sequence Expansion Cityline Installation Guide / Guide d'installation Séquence d'installation JNSASW, JNSASH, JNSAGW, JNSAGH, JNSAFW, JNSAFH & JNSAEW, JNSAEH - Add-on Screen - Desk mounted/Panneau séparateur - Sur surface CTL301 FABRIC/TISSU B02-81015R Light Grey / Gris pâle B02-81022R Internal position / Positions internes Dark Grey / Gris foncé...
- Page 5 Installation Sequence Expansion Cityline Installation Guide / Guide d'installation Séquence d'installation JNSASW, JNSASH, JNSAGW, JNSAGH, JNSAFW, JNSAFH & JNSAEW, JNSAEH - Add-on Screen - Desk mounted/Panneau séparateur - Sur surface CTL301 FELT/FEUTRE B02-81022R & R B02-81015L & R Dark Gray / Gris foncé...
