Electric Connections - Key Automation CT1RD Instructions And Warnings For Installation And Use

EN
4 - PRODUCT INSTALLATION
4.1 - Electrical connections
WARNING - Before making the connections, ensure that the control unit is not powered up.
MOTOR / POWER SUPPLY CONNECTIONS
Power supply connection terminal board
11 Motor close
12 Motor open
13 Motor common
14 Power supply 230 Vac 50-60 Hz
15 Power supply 230 Vac 50-60 Hz
SELECTION
MODE
A.R
W.T
CD.
1 2
GND 12/24
_
AC/DC
16
MEMORY
3 4
1 2
GND 12/24
COM OUT
_
AC/DC
NC
RX PH1 TX
J1
J2
J3
J4
J5
FUSE
6,3 A
M
MIN
MAX
