SPARTAK ENTERPRISES, INC.
FOLD DOWN DESK
Model #SB1019-33OA
LOT# 2029
IF PARTS ARE MISSING AND OR DEFECTIVE, IF INSTRUCTIONS ARE NOT CLEAR
OR IF YOU ARE EXPERIENCING PROBLEMS ASSEMBLING OUR PRODUCT.
BEFORE YOU RETURN THE PRODUCT TO THE STORE,
PLEASE CALL US TOLL FREE FOR CUSTOMER SERVICE ASSISTANCE
(888) 777-8250
OR SEND US EMAIL AT
help@spartakent.com
PLEASE HAVE ITEM NUMBER READY, AND A REPRESENTATIVE WILL GLADLY ASSIST YOU
Advertisement
Related Manuals for venture horizon 1019
Summary of Contents for venture horizon 1019
- Page 1 SPARTAK ENTERPRISES, INC. FOLD DOWN DESK Model #SB1019-33OA LOT# 2029 IF PARTS ARE MISSING AND OR DEFECTIVE, IF INSTRUCTIONS ARE NOT CLEAR OR IF YOU ARE EXPERIENCING PROBLEMS ASSEMBLING OUR PRODUCT. BEFORE YOU RETURN THE PRODUCT TO THE STORE, PLEASE CALL US TOLL FREE FOR CUSTOMER SERVICE ASSISTANCE (888) 777-8250 OR SEND US EMAIL AT help@spartakent.com...
- Page 3 1017A-Left Side 1pcs 1019I-Top 1019B-Right Side 1017J-Extension Left 1017C-Sliding side left 1017K-Bottom 1017D-Drawer back 5pcs 1017L-Brace 5pcs 1017E-Drawer bottom 1017M-Back Panel 5pcs 1017F-Dr. Sides & Front 1019N-Sliding Side Right 8pcs 1017G-Rail 1019O-Extension Right Parts are usually marked on the raw edge.
- Page 4 Place part (G) in the center of groove A&B and push down and make sure it stays there A&B CAMBTQF UNLOCKED Leave parts (A&B) on the floor POSITION to allow the glue to set for at least 30 minuts. In the mean time you can assemble the drawers.
- Page 5 We recommend you do one drawer at the time. The excess of glue can be wiped off with a damp cloth. Also, once glue sets it will turn translucent and it will not stick to laminated surface and can be easily peeled off. Press down Allow glue to set at least for 2 hours.
- Page 6 Raw Side Dont leave a gap between sides and the top.
- Page 7 Turn camlocks clockwise until full stop (slightly over a turn to lock the bolt) Screw cover cap 4 locations SFH833A 1. Insert part (K) onto part (A) then open the unit as much as you need to fit the part (K). 2.
- Page 8 Use block provided in hardware kit. Locking casters install in the front. Tap in plastic inserts in first.
- Page 9 Do not over tighten the screws as you may strip the wood. It will be a good idea not to use power drill. SF1025BL Place flat side of plastic spacer on the board and insert screw on UCHAN12 recessed side. SP12PR SPB1016BL...
- Page 10 SFH833A Raw Edge Laminated Edge SFH833A SFH612A...
- Page 11 Blocks Use two blocks provided in hardware kit to support mobile panel while connecting part (C) to part (L) with the SFH612A hinge..
- Page 12 SPB1016BL...
- Page 13 TRANSFORMATION INSTRUCTIONS First, lift the top panel slightly. (NOTE: Lift just enough so that the boards will not get damaged). Next, push the side panel in. Make sure you push it in as far as it will go. Finally, gently let the top panel down. The U-chanel #UCHAN12 clamps onto the side wall of part C between the square posts.
