User Manual
© 2007. All rights reserved. Black Box Corporation.
ServSwitch Affinity
Affordable many-to-many
Affordable many-to-many
multiplatform KVM switching.
multiplatform KVM switching.
FREE 24-hour Tech Support: 724-746-5500
blackbox.com
Advertisement
Related Manuals for Black Box KV130A
Summary of Contents for Black Box KV130A
- Page 1 © 2007. All rights reserved. Black Box Corporation. ServSwitch Affinity Affordable many-to-many Affordable many-to-many multiplatform KVM switching. multiplatform KVM switching. FREE 24-hour Tech Support: 724-746-5500 blackbox.com...
- Page 2 FEATURES • As many as 16 users have keyboard/mouse/video control over as many as 1024 PC, Sun, RS/6000, SGI, HP, and/or Alpha computers. • Easily expandable with plug-in port cards and flexible cabling. • Free lifetime firmware upgrades. • Supports video resolutions up to 1280 x 1024.
- Page 3 2/19/2007 724-746-5500 #22921 If you need to share access to a large number of CPUs, think about putting in a ServSwitch Affinity daisychain made up of 4-user expansion chassis (like the fully loaded one shown at right) or 8- or 16-user chassis. They come empty (no cards installed), but you can install 1 expansion card (or 2 in the 16-user units) and add as many as 4 Port Cards (0 x 4 or 1 x 4) to them, giving you a maximum of 4, 8, or 16 user...
-
Page 4: Tech Specs
All other models: Single transformer; Consumption: Up to 40 VA (40 watts) Size — KV132A-R2, KV130A, KV130DA, KV134A-R2, KV138A, KV138DA: 5.3"H (3U) x 16.7"W x 7"D (13.5 x 42.4 x 17.8 cm); KV139A, KV139DA: 7"H (4U) x 16.7"W x 7"D (17.8 x 42.4 x 17.8 cm);... -
Page 5: What's Included
KV130A 2/19/2007 724-746-5500 #22921 WHAT‘S INCLUDED ✦ The ServSwitch Affinity, including any cards and blanking plates that are normally preinstalled with your model. (Blanking plates will cover all unused slots, as well as the slot on 4-user models that the tiny terminator card is installed in.) - Page 6 EHN485 EHN225 2/19/2007 724-746-5500 #22921 Item CPU/Server to ServSwitch Cables (Continued) VGA, Coax 5-ft. (1.5-m) EHN515-0005 10-ft. (3-m) EHN515-0010 20-ft. (6.1-m) EHN515-0020 35-ft. (10.7-m) EHN515-0035 50-ft. (15.2-m) EHN515-0050 75-ft. (22.9-m) EHN515-0075 100-ft. (30.5-m) EHN515-0100 USB, Coax 5-ft. (1.5-m) EHN485-0005 10-ft. (3-m) EHN485-0010 20-ft.
