Summary of Contents for Vertiv Liebert NXL 500

  • Page 1 _________ l � -' -------- - - ИБП Liebert NXL - руководство по эксплуатации батарейной системы Юниджет Постоянная ссылка на страницу: https://www.uni-jet.com/catalog/istochniki- besperebojnogo-pitaniya/on-line-ibp-100-kva/liebert-chloride-nxl.html...
  • Page 2 Liebert Large System, 3-Phase UPS Battery ® System Installation Manual...
  • Page 3: Attery Abinet Recautions

    Click on Product Registration and fill out the form. ©2016 Vertiv Co. All rights reserved throughout the world. This document may contain confidential and/or proprietary information of Liebert Corporation, and its receipt or possession does not convey any right to reproduce, disclose its contents, or to manufacture or sell anything that it may describe.
  • Page 4: Table Of Contents

    TABLE OF CONTENTS ............2 ATTERY ABINET RECAUTIONS...
  • Page 5 FIGURES Figure 1 Shipping bolts—Top-terminal battery cabinet, standard width ........5 Figure 2 Shipping bolts—Top-terminal battery cabinet, reduced width .
  • Page 6 ™ Figure 39 Terminal details, Liebert NXL 500kVA UPS to top-terminal battery and attached junction cabinet, point-to-point wiring..............41 ™...
  • Page 7 TABLES Table 1 Liebert eXL UPS control contacts to battery interface boards........17 Table 2 Liebert NX UPS control contacts to battery interface boards.
  • Page 8: Important Safety Instructions

    Risk of electric shock. Can cause personal injury and death. In case of fire involving electrical equipment, use only carbon dioxide fire extinguishers or those approved for use in fighting electrical fires. Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 9 Operation of this unit in a residential area may cause harmful interference that the user must correct at his own expense. Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 10: 1.0 Mechanical Installation

    77°F (25°C). Storage at a higher temperature will increase the rate of self-discharge, requiring earlier recharge. Consult the battery manufacturer on how to determine when the batteries need to be recharged. Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 11: Positioning

    The cabinet with top-terminal and front-terminal batteries ships with extra bolts installed on the interior doors. Once the cabinet is in the final position, these bolts can be removed. See Figures 1 and 2. Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 12: Figure 1 Shipping Bolts-Top-Terminal Battery Cabinet, Standard Width

    Shipping Bolts Shipping Bolts Outer doors not shown Figure 2 Shipping bolts—Top-terminal battery cabinet, reduced width Shipping Bolts Shipping Bolts Shipping Bolts Shipping Shipping Bolts Bolts Outer doors not shown Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 13: Clearances

    A battery system can consist of a number of equipment cabinets, depending on the individual system design requirements, e.g., Battery Cabinet, Junction Cabinet. Refer to 3.0 - Installation Drawings for the positioning of the cabinets described below. Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 14: 2.0 Battery Installation

    • Determine if the battery is grounded. If it is grounded, remove source of ground. Contact with any part of a grounded battery can result in electrical shock. • Battery support tray must be used whenever a battery tray is being pulled out. Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 15: Layout

    UPS. 17-½" Junction 47" 47" 47" 800-1200kVA Cabinet (1194mm) (1194mm) (1194mm) Stand-Alone Interconnected Battery (May be on Battery Battery Systems either end Cabinet Cabinet Cabinet or between any battery cabinets ) Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 16: Figure 4 Top-Terminal Battery System Configurations-Liebert Nx

    Liebert One or more battery cabinets (1194mm) (1194mm) (1194mm) bolted to the UPS Battery Battery Battery Battery cabinets must be on the left side of the UPS. Cabinet Cabinet Cabinet Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 17: Figure 5 Top-Terminal Battery System Configurations-Liebert Nxl

    ) 17-½" Junction 47" 47" 47" 800-1100kVA Cabinet (1194mm) (1194mm) (1194mm) Stand-Alone (May be on Battery Battery Battery Connected Systems either end Cabinet Cabinet Cabinet or between any battery cabinets ) Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 18: Figure 6 Top-Terminal Stand-Alone Battery System Configuration-Liebert Exl

    Top-terminal battery system configuration—Battery cabinets not attached to UPS or each other, Liebert eXL ™ ™ Liebert NX and Liebert NXL Stand-Alone 55" 55" Detached Individual Systems Liebert (1397mm) (1397mm) Junction Battery Battery Cabinet Cabinet Cabinet 32" (813mm) Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 19: Figure 8 Front-Terminal Battery System Configurations-Liebert Exl

    Cabinet 17-½" Junction 62" 62" 62" 800-1200kVA Cabinet (1575mm) Stand-Alone (1575mm) (1575mm) Interconnected Systems Battery (May be on Battery Battery either end Cabinet Cabinet Cabinet or between any battery cabinets ) Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 20: Figure 9 Front-Terminal Battery System Configurations-Liebert Nx

    62" 225-600kVA Liebert One or more battery cabinets (1575mm) (1575mm) (1575mm) bolted to the UPS Battery Battery Battery Battery cabinets must be on left side of UPS. Cabinet Cabinet Cabinet Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 21: Figure 10 Front-Terminal Battery System Configurations-Liebert Nxl

    ) 17-½" Junction 62" 62" 62" 800-1100kVA Cabinet (1575mm) (1575mm) (1575mm) Connected (May be on Battery Battery Battery Stand-Alone Systems either end Cabinet Cabinet Cabinet or between any battery cabinets ) Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 22: Cable Entry

    For cabinets ordered as connected (battery cabinets will bolt to each other), the positive and negative busbars are connected between battery cabinets with the supplied busbar connector extensions. See Figure 33 Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 23: Connected Or Stand-Alone Arrangement

    Risk of improper installation. Can cause equipment damage. During system commissioning, Vertiv Liebert Services will set the jumpers on the (External Interface Board) EIB and the BIB. If another battery cabinet is added to the system after commissioning, it is imperative that Liebert Services reset the jumpers on the EIB board and the BIB board.
  • Page 24: Liebert Nx ™ And Liebert Nxl

    Backfeed Circuit XT3/8 Breaker (BFB) X19A X19B External Communication Panel, See Detail A (Non-Functional) (Non-Functional) Front Doors Removed U38-3C-2000 Rev. 2 Detail A External Communication Panel (See specific control wiring drawings) Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 25: Figure 15 Tb3 Location-400-600Kva Liebert Nx

    Circuit Breaker (CB1), optional Backfeed Circuit Breaker (BFB) External Communication X19B X19A Panel, See Detail A XT3/8 Front Doors Removed XT1/2 U38-6C-2000 Rev. 2 XS6 (LIFE) Detail A External Communication Panel Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 26: Figure 16 Wiring External Interface Board In Liebert Nxl To Battery Interface Board In Battery Cabinet

    Wiring external interface board in Liebert NXL to battery interface board in battery cabinet Detail A TB1154A EXT BATT External Interface Board (in UPS) Detail A TB1154A Battery Interface Board (in Battery Cabinet) Detail B TB1154 Detail B TB1154 Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 27: Figure 17 Battery Temperature Sensor Control Connection

    This sensor is connected to the BIB board (see Figure 17). This sensor will allow the Liebert UPS to perform temperature compensation charging. Figure 17 Battery temperature sensor control connection Battery Interface Board (in Battery Cabinet) P1153 TB1154 Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 28: Figure 18 Outline Drawing, Liebert Top-Terminal, 47" (1194Mm) Wide Battery Cabinet

    6. Depth dimension includes the front door and rear panel. 7. Refer to the battery technical information drawing for more information. BPP12003 Pg. 1, Rev. 0 Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 29: Figure 19 Main Components, Liebert Top-Terminal, 47" (1194Mm) Wide Battery Cabinet

    Module (Optional) Module (Optional) Battery Breaker Battery Interface Battery Board (BIB) Service Tray Batteries Battery Service Tray Supports BPP12003 Pg. 2, Rev. 0 FRONT VIEW FRONT VIEW (Doors and Panels Not Shown) Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 30: Figure 20 Terminal Details, Liebert Top-Terminal, 47" (1194Mm) Wide Battery Cabinet

    57.1" (1451mm) Positive Negative Terminal Terminal TOP VIEW Bus (+) Bus (-) (Door Open) FRONT TOP VIEW BPP12003 Pg. 3, Rev. 0 RIGHT SIDE VIEW Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 31: Figure 21 Outline Drawing, Liebert Top-Terminal, 55" (1400Mm) Wide Battery Cabinet

    6. Width dimension is without side panels; add 0.7" (18mm) per side where applicable. 7. Depth dimension includes the front door and rear panel. 8. Refer to the battery technical information drawing for more information. BPP12001 Pg. 1, Rev. 0 Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 32: Figure 22 Main Components, Top-Terminal, 55" (1400Mm) Wide Battery Cabinet

    Battery Breaker Battery Interface Battery Board (BIB) Service Tray Ground Bus Battery Service Tray Batteries Supports Typical View BPP12001 FRONT VIEW FRONT VIEW OF INNER DOORS Pg. 2, Rev. 0 Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 33: Figure 23 Terminal Details, Top-Terminal, 55" (1400Mm) Wide Battery Cabinet

    3. All wiring must be in accordance with national and local electrical codes. FRONT BPP12001 CONDUIT DETAIL B Pg. 3, Rev. 0 (Bottom Conduit Plate) RIGHT SIDE VIEW Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 34: Figure 24 Outline Drawing, Liebert Front-Terminal Battery Cabinet

    7. Depth dimension includes the front door and rear panel. 8. Refer to the battery technical information drawing for more information. BPP12002 Pg. 1, Rev. 0 Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 35: Figure 25 Main Components, Liebert Front-Terminal Battery Cabinet

    Cabinet 1. Module (Optional) Module (Optional) Batteries Battery Typical Breaker View Battery Interface Board (BIB) Ground BPP12002 FRONT VIEW FRONT VIEW Pg. 2, Rev. 0 (Doors and Panels Not Shown) Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 36: Figure 26 Terminal Details, Liebert Front-Terminal Battery Cabinet

    2. Control wiring and power wiring must be run in separate conduit. 3. All wiring must be in accordance with national and local electrical codes. BPP12002 Pg. 3, Rev. 0 RIGHT SIDE VIEW Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 37: Figure 27 Front-Terminal Battery Cabinet Shipping Split

    Installation Drawings Figure 27 Front-terminal battery cabinet shipping split Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 38: Figure 28 Liebert Stand-Alone 32" (813Mm) Junction Cabinet Terminal Wiring

    3. Unless otherwise noted, use copper or aluminum conductors suitable for at least 75°C. 4. Widths are without side panels. The width is 32.1" (815mm) with side panels. 5.The depth dimension includes the front door and rear panel. Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 39: Figure 29 Liebert Attached Junction Cabinet-Terminal Details

    Bus Top Bolt Busbar DO NOT DOUBLE-STACK LUGS (two lugs on same side of busbar). This is to prevent DUAL LUG the cables from coming into CONNECTION DETAIL contact with other busbars. Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 40: Figure 30 Liebert 15-1/2" Attached Junction Cabinet-Outline Drawing

    (The final installation will always require the unit to be bolted to another Liebert product.) Failure to comply with these instructions could result in equipment damage and injury to personnel. Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 41: Figure 31 17" Junction Cabinet Junction Cabinet

    Installation Drawings Figure 31 17" junction cabinet junction cabinet Center Gravity Center Gravity FRONT 41.04" (1042.5mm) 9.59" (243.5mm) FRONT VIEW 553636 REAR Rev. 0 Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 42: Figure 32 Liebert Battery Cabinet Control Wiring

    P1152 TB1150 TB1151 P1153 This end field-connected. See sheet 3 for shipping instructions. TB1158 1-TB1154-1+24V - Red Battery 2-TB1154-2 GND - Black Monitoring 3-TB1154-3CANH- White TB1154 System 4-TB1154-4CANL - Black Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 43: Figure 33 Attached Battery Cabinet Connections

    Typical ground strap installation of Units locations. 2. Torque Values: M6: 40 in-lb (5 Nm) for battery cabinet to UPS or ancillary M10: ( 14 Nm ) 120 in-lb cabinet connections. Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 44: Figure 35 Top-Terminal, Standard Width Battery Cabinet Interconnection Wiring To 250-400Kva Ups

    Battery Cabinet - Battery CAN Control Cables Board (EIB) Interface Board (BIB) * This is used only for detached cabinets. If the cabinets are attached, use the grounding shown in Figure 34. Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 45: Figure 36 Liebert Top-Terminal, Standard Width Battery Cabinet Interconnect Wiring To Liebert

    Liebert top-terminal, standard width battery cabinet interconnect wiring to Liebert junction cabinet From Conductors Battery Cabinet Negative Bus Junction Negative Bus Negative DC Power Battery Cabinet Positive Bus Junction Positive Bus Positive DC Power Battery Cabinet Ground Junction Ground Ground Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 46 Negative DC Power Left Mount UPS Ground Battery Cabinet Ground Ground Battery Cabinet UPS External Interface Board (EIB) CAN Control Cables Battery Interface Board (BIB) * For detached units only Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 47: Stand-Alone Junction Cabinet

    Positive DC Power Junction Negative Bus UPS Cabinet Negative Bus Negative DC Power Junction Ground UPS Cabinet Ground Ground Battery Cabinet Battery Interface Board (BIB) UPS External Interface Board (EIB) CAN Control Cables Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 48: Figure 39 Terminal Details, Liebert Nxl

    Junction Negative Bus UPS Cabinet Negative Bus Negative DC Power Junction Ground UPS Cabinet Ground Ground Battery Cabinet UPS External Interface Board (EIB) CAN Control Cables Battery Interface Board (BIB) Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 49: Figure 40 Terminal Details, Liebert Nxl

    Positive DC Power Junction Negative Bus UPS Cabinet Negative Bus Negative DC Power Junction Ground UPS Cabinet Ground Ground Battery Cabinet Battery Interface Board (BIB) UPS External Interface Board (EIB) CAN Control Cables Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 50: Figure 41 Terminal Details Liebert Nxl ™ 500Kva To Top-Terminal Battery Point-To-Point Wiring

    Battery Cabinet Positive Bus Positive DC Power UPS Negative Bus Battery Cabinet Negative Bus Negative DC Power UPS External Interface Board (EIB) Battery Cabinet Battery Interface Board (BIB) CAN Control Cables Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 51: Figure 42 Terminal Details Liebert Nxl ™ 500Kva To Front-Terminal Battery Point-To-Point Wiring

    Battery Cabinet Positive Bus Positive DC Power UPS Negative Bus Battery Cabinet Negative Bus Negative DC Power Battery Cabinet UPS External Interface Board (EIB) CAN Control Cables Battery Interface Board (BIB) Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 52: Point-To-Point Wiring

    Junction Negative Bus UPS Cabinet Negative Bus Negative DC Power Junction Ground UPS Cabinet Ground Ground Battery Cabinet Battery UPS External Interface Board (EIB) CAN Control Cables Interface Board (BIB) Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 53: Table 12 Liebert Nxl Terminal Details Ups 625/750Kva To Front-Terminal Battery And Stand-Alone

    Positive DC Power Junction Negative Bus UPS Cabinet Negative Bus Negative DC Power Junction Ground UPS Cabinet Ground Ground Battery Cabinet Battery Interface Board (BIB) UPS External Interface Board (EIB) CAN Control Cables Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 54 Junction Negative Bus UPS Cabinet Negative Bus Negative DC Power Junction Ground UPS Cabinet Ground Ground Battery Cabinet, Battery UPS External Interface Board (EIB) CAN Control Cables Interface Board (BIB) Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 55: Table 14 Terminal Details, Liebert Nxl 625/750Kva Ups To Top-Terminal Battery And Stand-Alone

    Positive DC Power Junction Negative Bus UPS Cabinet Negative Bus Negative DC Power Junction Ground UPS Cabinet Ground Ground Battery Cabinet Battery Interface Board (BIB) UPS External Interface Board (EIB) CAN Control Cables Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 56 Battery Cabinet Positive Bus Positive DC Power UPS Negative Bus Battery Cabinet Negative Bus Negative DC Power Battery Cabinet UPS External Interface Board (EIB) CAN Control Cables Battery Interface Board (BIB) Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 57: Figure 48 Terminal Details 625/750Kva Ups To Front-Terminal Battery And Attached Junction Cabinet

    Positive DC Power Junction Negative Bus UPS Cabinet Negative Bus Negative DC Power Junction Ground UPS Cabinet Ground Ground Battery Cabinet Battery Interface Board (BIB) UPS External Interface Board (EIB) CAN Control Cables Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 58: Figure 49 Terminal Details 625/750Kva To Front-Terminal Battery And Stand-Alone Junction Cabinet

    Junction Negative Bus UPS Cabinet Negative Bus Negative DC Power Junction Ground UPS Cabinet Ground Ground Battery Cabinet Battery Interface Board (BIB) UPS External Interface Board (EIB) CAN Control Cables Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 59: Figure 50 Typical Alber ® Battery Monitoring Connections

    Installation Drawings ® Figure 50 Typical Alber battery monitoring connections Input Fuse for Alber Power Alber Control Module Alber Battery Module Alber Power Transformer Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 60: Figure 51 Alber ® Battery Monitoring Wiring To Multiple Battery Cabinets

    Installation Drawings ® Figure 51 Alber battery monitoring wiring to multiple battery cabinets 300V 270V 240V 208V 200V 300V 270V 240V 208V 200V Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 61: Battery Monitoring Assembly Diagram

    1.5 A, 600VAC 0 (Top) 300 (Top) to 208 (Bottom) 300 (Bottom) 2.0 A, 600VAC 0 (Top) to 0 (Bottom) and 0 (Top) 208 (Top) 3.5A, 600VAC 208 (Top) to 208 (Bottom) Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 62: Figure 53 Top-Terminal Battery Configuration

    JAR 14 JAR 19 JAR 23 JAR 15 JAR 18 JAR 22 JAR 16 JAR 17 JAR 21 FRONT OF TRAY FRONT OF TRAY FRONT OF TRAY CABLE INTERCONNECT DIAGRAM Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 63: Figure 54 Front-Terminal Battery Configuration

    JAR #19 JAR #12 JAR #10 15 14 13 18 17 16 JAR #18 JAR #17 JAR #16 JAR #15 JAR #14 JAR #13 Bottom of Cabinet FRONT CABLE INTERCONNECT DIAGRAM Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 64: Figure 55 Busbar Connection Between Battery Cabinet And Attached Junction Cabinet

    Busbar connection between battery cabinet and attached junction cabinet Left-Side Busbar Connections This connection is the same for top-terminal (12V) battery cabinets and front-terminal (16V) battery cabinets. Right-Side Busbar Connections Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 65: Table 22

    Width dimensions are with side panels attached. Subtract 1.4" (35mm) for dimensions without side panels. Depth dimensions include the front door and rear panel. Contact the factory about storage at temperatures outside this range. Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 66: Junction Cabinet Specifications

    Width dimensions are with side panels attached. Subtract 1.4" (35mm) for dimensions without side panels. Depth dimensions include the front door and rear panel. ® Table 21 Alber battery monitoring option specifications Electrical Data Value Input Voltage 220-600VAC Input Current < 0.5A Frequency 60Hz Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 67: Table 22 Battery Cabinet Weights And Breaker Frame Size

    Liebert NXL 225kW 700AT/1200AF 270kW 800AT/1200AF 360-1100kW: 900AT/1200AF HR3000 3565 (1617) 400AT/600AF HR3500 3965 (1798) 450AT/600AF East Penn HR4000 4375 (1984) 500AT/600AF 65 (7.3) 31HR5000 5095 (2311) 500AT/600AF HR5500 5455 (2474) 600AT/600AF Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 68: Table 23 Torque Specifications, Unless Otherwise Labeled

    400 - 1200 Amps 300 (34) — Circuit Breakers with Compression Lugs (For Control Wiring) AWG Wire Size or Range lb-in (Nm) — #22 - #14 3.5 to 5.3 (0.4 to 0.6) — Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 69 Specifications NOTES Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 70 Specifications Vertiv | Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 71 Specifications Vertiv Large System, 3-Phase UPS Battery System Installation Manual...
  • Page 72 TECHNICAL SUPPORT / SERVICE Web Site www.vertivco.com Monitoring liebert.monitoring@vertivco.com 800-222-5877 Outside North America: +00800 1155 4499 Three-Phase UPS & Power Systems 800-543-2378 Outside North America: 614-841-6598 LOCATIONS United States 1050 Dearborn Drive P.O. Box 29186 Columbus, OH 43229 Europe Via Leonardo Da Vinci 8 Zona Industriale Tognana 35028 Piove Di Sacco (PD) Italy +39 049 9719 111...
  • Page 73 © 2016 Vertiv Co. All rights reserved. Vertiv and the Vertiv logo are trademarks or registered trademarks of Vertiv Co. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness herein, Vertiv Co. assumes no responsibility, and disclaims all liability, for damages resulting from use of this information or for any errors or omissions. Specifications are subject to change without notice.
