- Page 1 NetSure™ 200 A Distribution Fuse Panel Assembly Installation and User Manual (UM563317), Revision B Specification Number: 563317 Model Number: NSFP200...
- Page 2 Any questions regarding usage of trademark names should be directed to the original manufacturer. © 2017 Vertiv Energy Systems, Inc. All rights reserved. Vertiv and the Vertiv logo are trademarks or registered trademarks of Vertiv Group Corporation.
-
Page 3: Table Of Contents
Troubleshooting and Repair ................21 Contact Information ............................21 Replacement Procedures ..........................21 Replacing a Distribution Fuse ......................... 21 Replacing the Alarm Card ..........................21 Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 4: Admonishments Used In This Document
SAFETY! Informs the reader of general safety information, reminders, precautions, or policies not related to a particular source of hazard or to fire safety. (ISO, ANSI, OSHA) Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 5: Important Safety Instructions
Observe all battery safety precautions in this manual and in the battery instruction manual. These precautions should be followed implicitly at all times. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 6: Handling Equipment Containing Static Sensitive Components
If necessary to repair equipment containing static sensitive components, wear an appropriately grounded wrist strap, work on a conductive surface, use a grounded soldering iron, and use grounded test equipment. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 7: Description
100 A per side, 200 A total at @ +55 °C (+131 °F). 80 A per side, 160 A total @ +65 °C (+149 °F). Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 8: Environmental
Safety Compliance (pending): This panel is UL Recognized for use in DC Power Distribution Centers for Communications Equipment. NEBS Compliance (pending): Compliance verified by a Nationally Recognized Testing Laboratory (NRTL) per GR-1089-CORE and GR-63-CORE. Contact Vertiv for NEBS compliance reports. GR-3108 (Pending): GR-3108 Class 2 Compliant. Vertiv... -
Page 9: Dimensions And Weight
Top View 1.72 1.25 17.6 Left Side View Right Side View 18.3 19.0 1.00 1.25 23” Mounting Brackets 22.3 23.0 Front View Rear View Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 10: Accessories
Technology Equipment - Safety - Part 1: General Requirements): when the equipment is deployed in Canada the maximum fuse value that can be used in this product is 15 A. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 11: Lugs
(Flex Wire) 150552 1/0 AWG (Narrow Tongue) (Standard Wire) 128945 2/0 AWG (Narrow Tongue) (Standard Wire) Note: Lugs should be crimped per lug manufacturer’s specifications. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 12: Installing The Distribution Fuse Panel
• The shelf-to-rack mating surfaces must be cleaned. • Electrical anti-oxidizing compound must be applied to the shelf-to-rack mating surfaces. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 13: Installing Load Distribution Fuses
Figure 3: Installing Load Distribution Fuses Fuse Front Front Fuse Pull out the fuse label and record the fuse size, location, and other pertinent information. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 14: Making Electrical Connections
Provide a grounding lead terminated in a two hole lug to one set of Figure 4 Table 2 these swage nuts, if required. Refer to for location and recommended torque. Refer to for available lugs. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 15: External Alarm Connections
22 of TB1 and relay contacts close between terminals 20 and 21 of TB1. Normal operation (Side B energized) provides closed relay contacts between terminals 21 and 22 of TB1 and open relay contacts between terminals 20 and 21 of TB1. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... - Page 16 A PWR Fail and B PWR Fail relays are normally energized and de-energize during an alarm condition. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B...
-
Page 17: Load Distribution Wiring
Replace the rear shields onto the distribution fuse panel. Adhere the appropriate furnished voltage label to the outside of the rear shields as shown in Figure 6. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... - Page 18 Feed A and Feed B must be of the same voltage and polarity. Rear Adhere the appropriate Adhere the appropriate furnished label here. furnished label here. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B...
-
Page 19: Input Wiring
Remove the rear shields from the distribution fuse panel. Make input connections as required. See Figure 7. Replace the rear shields onto the distribution fuse panel. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 20: Initial Startup
Feed B FA Indicator: When illuminated (red), a distribution fuse is open on side B. MAJ: When illuminated (red), a major alarm is active. MIN: When illuminated (amber), a minor alarm is active. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... -
Page 21: Troubleshooting And Repair
The following circuit card replacement procedure can be performed with the unit operating. Refer to Figure 9 as this procedure is performed. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B... - Page 22 Enable the external alarms, or notify appropriate personnel that this procedure is finished. Ensure that there are no local or remote alarms active on the system. Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B...
- Page 23 Figure 9: Alarm Card Replacement Rear Alarm Card Captive Fasteners Alarm Card Replacement Vertiv | 200 A Distribution Fuse Panel Assembly Installation & User Manual (UM563317) | Rev. B...
- Page 24 UM563317 (RB 05/17)
