Installation Manual
IMPORTANT - PLEASE READ THIS MANUAL
BEFORE INSTALLING UNIT
CAUTION -
Before installation, careful consideration must be given to how this system
will operate if connected to any other piece of mechanical equipment, i.e. air handler, operat-
ing at a higher static. After installation, the compatibility of the two pieces of equipment
should be confirmed by measuring the airflow of the Energy Recovery Ventilator.
It is always important to assess how the operation of any ERV may interact with vented com-
bustion equipment (i.e. Gas Furnaces, Oil Furnaces, Wood Stoves, etc.).
NEVER -
install a ventilator in a situation where its normal operation, lack of operation or par-
tial failure may result in the backdrafting or improper functioning of vented combustion equipment!!!
Your ventilation system should be installed in conformance with the appropriate provincial or state requirements
or in the absence of such requirements with the current edition of the National Building Code, and / or
ASHRAE's " Good Engineering Practices".
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
ERV RT-EC SERIES
Outdoor Energy Recovery Ventilator
1
Advertisement
Related Manuals for SystemAir ERV RT-EC Series
Summary of Contents for SystemAir ERV RT-EC Series
- Page 1 ERV RT-EC SERIES Outdoor Energy Recovery Ventilator Installation Manual IMPORTANT - PLEASE READ THIS MANUAL BEFORE INSTALLING UNIT CAUTION - Before installation, careful consideration must be given to how this system will operate if connected to any other piece of mechanical equipment, i.e. air handler, operat- ing at a higher static.
-
Page 2: Table Of Contents
Warranty TABLE OF CONTENTS • The motors found in all Systemair ERV’s require no lubrication, and are factory RECEIVING & INSPECTION OF UNIT ........3 balanced to prevent vibration and promote silent operation. -
Page 3: Receiving & Inspection Of Unit
If any damage exists, do not accept the shipment without written acknowl- edgement of the damages by the shipper. Report damage to the carrier and to Systemair Inc. immediately. Note type of damage on copy of Bill of Lading. -
Page 4: Installation
INSTALLATION The unit may be secured to a metal or wooden curb fastened to the roof. If securing the unit to the curb is required, fasteners and isolators may be used at the mounting points on the frame protruding from the unit (all mounting hardware is field supplied and specified). Roofcurb Care must be exercised in locating the roof opening and in all cases a structural engineer should confirm location of the unit on the roof. -
Page 5: Lifting And/Or Supporting The Unit
INSTALLATION – CONT. Figure 4: Roofcurb detail for ERV3200/4600 RT-EC Bottom View Eletrical Wire Channel 1261 1627 *NOTE: Standard curb heights are 12” (305mm), 18” (475mm), 24” (610mm) 77.8 1694 **NOTE: Drawings are not to scale LIFTING AND/OR SUPPORTING THE UNIT The ERV series units are factory equipped with rigging holes which should be used to hoist and install the unit. -
Page 6: Placing The Unit
INSTALLATION - CONT. PLACING THE UNIT Figure 6: All ERV series units are provided with integral rigging holes. Units Remove obstructions from supply and exhaust air openings must be lifted via these rigging provisions using a spreader system (provided by others) which protects the upper exterior of the Sys- temair Energy Recovery Unit during lifting. -
Page 7: Electrical Wiring
Check control schematics and related circuit diagrams furnished with each unit. The following pages are pre-start-up guidelines which should be followed carefully. If any problems exist, startup of the unit should not take place without consulting the Systemair representative or the factory. **WARNING**... - Page 8 Maintenance record A record of regular maintenance is required to maintain any letters of guarantee issued by Systemair Inc. Date of service, actions taken, and the name of the service person are required. Frequency of maintenance required should be determined by inspection. The Systemair Energy Recovery Unit requires minimal maintenance in clean airstreams.
- Page 9 NOTES...
- Page 10 NOTES...
- Page 11 NOTES...
- Page 12 Systemair Inc. reserves the right to make changes and improvements to the contents of this manual without prior notice. Systemair Inc. 50 Kanalflakt Way Bouctouche, NB E4S3M5, Canada Phone +1 800 263 7081 10048 Industrial Blvd KS, 66215 United States Phone +1 800 263 7081 www.systemair.net...
