use-fan – which fan to use in manual mode (main | auxiliary; main by default).

Firware information

This menu displays RouterBOARD model number, serial number, the current boot loader version and the
version available in the current software packages installed.
[admin@MikroTik] > system routerboard print
routerboard: yes
model: "rb800"
serial-number: "154201C1DD3C"
current-firmware: "2.21"
upgrade-firmware: "2.21"
[admin@MikroTik] >
The firmware version can be upgraded using "/system routerboard upgrade" command.

Firmware Settings

Boot loader settings are also accessible through this menu.
[admin@MikroTik] > system routerboard settings print
baud-rate: 115200
boot-delay: 2s
boot-device: nand-if-fail-then-ethernet
enter-setup-on: any-key
boot-protocol: bootp
enable-jumper-reset: yes
[admin@MikroTik] >
The Software Reset 2 jumper (S2), which resets both boot loader settings and RouterOS setting by default,
can be disabled in this menu (it will still reset the boot loader settings).

Software Reset

It is possible to reset all software configuration by holding the Software Reset 2 jumper (S2) during the
power-up. No confirmation or passwords will be asked, so use with caution. This feature can be disabled in
the "system routerboard settings" menu by switching the "enable-jumper-reset" parameter to "no".
To use it, simply shorten it with a screwdriver, and power up the device, until RouterOS loads.
JP5 DIS POE Jumper
This jumper will disable the 802.11af compatible smart PoE, and also lower the undervoltage protection
threshold to approx 10V, allowing to use this device with passive PoE in 24V Solar power installations.

Appendix

Connector Index

J1 CompactFlash slot
J11 RJ45 Gigabit Ethernet 1000Base-T port LAN3 (no PoE)
J4 Daughterboard PCI connector
J10 Daughterboard PCIe connector
J5 MiniPCI Type type IIIA/B connector 1
J6 MiniPCI Type type IIIA/B connector 2
J7 MiniPCI Type type IIIA/B connector 3
J8 MiniPCI Type type IIIA/B connector 4
J2 RS232C male DB9 serial port
2 RxD (Receive Data)
3 TxD (Transmit Data)
