FlexPower AC Power System Installation Manual FlexPower Features FlexPower Power Management System CCTV Standard Features FlexPower's advanced feature set provides greater product reliability, increased flexibility, shorter install time, a smaller service inventory, and an intelligent, economical solution to the problem of reliable system power. VSelect Reliability+ ®...
Notes and Warnings Symbol Definitions Regulatory Information The following symbols are used throughout this manual. The equipment discussed within this manual has been tested to the following standards: This symbol is intended to alert the installer of shock haz- • UL2044 ards within the enclosure.
Quick Install Guide Section 1 - Installation and Operation 1 .1 Mounting Enclosure-Level Products Mounting an enclosure to a wall is via the two recessed keyholes and two recessed mounting holes in the back of the enclosure. 1. (Optional) Remove the enclosure’s cover. 2.
FlexPower AC Power System Installation Manual 1 .2 Connections and Setup Ensure all power is disconnected before wiring. AC Input (J9) Output Selection Jumpers (JP1 - JP8) The primary AC input for the FPA Series power supplies. Multi-trans-...
Quick Install Guide 1 .2 .1 Transformer Secondary Wire Colors FPA 100/150/300A Winding 1 Brown Blue Orange Common Voltage Current Voltage Current FPA100A 4.17A 3.57A FPA150A 6.25A 5.4A FPA300A 12.5A 10.7A FPA 200A Winding 1 Brown Yellow Green Common Voltage Current Voltage Current FPA200A 16.5V 6.06 5.56A FPA200A Winding 2 Black...
FlexPower AC Power System Installation Manual AC Input Alternate AC Input Class 2 1 .3 Typical Installation & Wire Routing The drawing above shows a typical installation. Actual con- figuration and wire routing will vary based on the compo- nents installed in your system. The following guidelines should be followed for installation.
Troubleshooting 1 .4 Power-Up and Basic System Verification Checklist 1 . Ensure proper configuration of all jumpers. 2 . Apply AC power to the FPA power supply. 3 . Ensure all green Zone LEDs are lit. 4 . Verify zone output voltage with a meter. a.
Verify that 24 and 28V (or 16.5 and 18V for 16.5/18V FPA Models) are being output from the transformer. If not, the transformer's internal protection may have opened. Contact LifeSafety Power. A8 Board Problem Verify all jumpers and fuses are in place and intact. Contact Life- Safety Power.
Specifications Section 3 - Specifications 3 .1 Electrical Specifications FPA Series Power Supplies Specification FPA100A FPA150A FPA300A FPA600A FPA900A FPA200A AC Input Voltage 120VAC ±15% 120VAC ±15% 120VAC ±15% 120VAC ±15% 120VAC ±15% 120VAC ±15% at 60Hz at 60Hz at 60Hz at 60Hz at 60Hz at 60Hz...
