- Page 1 RC Rackmount Installation Manual LifeSafety Power, Inc. | PH 888.577.2898 | TechSupport@LifeSafetyPower.com P03-050 Rev A03...
- Page 2 RC Series Rackmount Installation Manual Table of Contents Notes and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii Symbol Definitions .
- Page 3 Notes and Warnings Symbol Definitions Regulatory Information The following symbols are used throughout this manual The equipment discussed within this manual has been test- ed to the following standards: This symbol is intended to alert the installer of shock hazards within the enclosure . Service should only be •...
- Page 4 RC Series Rackmount Installation Manual Introduction Product Description RC Series of power sup plies provide include removable terminal strips for field wiring, input and FLEXPOWER DC Lock or Camera power for lifesafety applications . De- output surge suppression, automotive blade fus es for im- signed to fit neatly into standard 19"...
-
Page 5: Section 1 – Installation & Operation
Installation and Operation Section 1 – Installation & Operation The following pages cover the installation of the RC Series power supplies . 1 .1 Mounting the Rackmount Supply into a Standard 19" Rack Use the following procedure when mounting an RC series Use rails or other appropriate support for heavy en- supply into a standard EIA 19"... -
Page 6: Rc Series Rackmount Power Supply Overview
RC Series Rackmount Installation Manual 1 .2 RC Series Rackmount Power Supply Overview CONTROLLED OUTPUTS 1 CONTROLLED OUTPUTS 2 MAIN OUTPUT 2 MAIN OUTPUT 1 AC Power 10-100 Base-T CONTROL INPUTS 1 CONTROL INPUTS 2 CONTROLLED OUTPUTS 2 3 4 6 7 8 - + - + - + -... -
Page 7: Field Wiring
Installation and Operation The following are basic descriptions . Refer to the appropriate section for more detailed information . Note that the front and back panels may appear different based on the configuration of your system . systems . Single voltage systems should leave these jumpers in the DC1 Main AC Power Switch / Circuit Breaker (UP) Position . -
Page 8: Internal Pre-Configuration
RC Series Rackmount Installation Manual 1 .3 Internal Pre-Configuration Configuration internal to the enclosure is required on setting the output voltage . RC Series power supplies prior to installation into a rack . 1.3.4 Enabling or Disabling Battery Presence Detection Ensure all power is disconnected before performing this initial configuration . - Page 9 Installation and Operation B100 230VAC Jumper Earth GND Earth GND Battery DETECT Battery DETECT Voltage SELECT Figure 3 - Configuring the Internal Power Supplies cut jumper for 230VAC AC Input AC ON AC ON AC Input...
-
Page 10: Making The Wiring Connections
RC Series Rackmount Installation Manual 1 .4 Making the Wiring Connections Field wiring connections are made on the rear panel after in- DC1+, DC1– stalling the enclosure into the rack . Field wiring connections The main DC output of the FPO power supply . The full cur- are made to the removable terminal strips, which accept AWG rent of the FPO is available on these terminals at all times 12-22 wire . - Page 11 Installation and Operation Activation with a Normally Open Relay Contact Activation with a Voltage Input FAI Activates when the NO contact CLOSES . FAI Activates when voltage is APPLIED in the correct po- larity . FAI Deactivates when voltage is REMOVED or the FAI Deactivates when the NO contact OPENS .
- Page 12 RC Series Rackmount Installation Manual 1.4.2 Main AC Power Connection 1.4.3 Ethernet Connection To connect the RC Series to the main AC power source, plug The RC Series is available with an optional NetLink Ethernet one end of the included computer-style AC cord into the AC communication module .
-
Page 13: Section 2 – Configuration And Usage
Configuration and Usage Section 2 – Configuration and Usage This section describes the final configuration as well as operation details for the RC Rackmount series power supplies . 2 .1 Removing the Faceplate of the Enclosure Use the following steps to remove the faceplate of the rack- mount enclosure and gain access to the front boards . -
Page 14: Status Leds
RC Series Rackmount Installation Manual 2 .3 Status LEDs Each front board has nine LEDs (See figure 9) . The eight green LEDs indicate the status of the zone’s output . VOLTAGE SELECT JUMPERS • On Steady – Door Locked (Fuse or PTC Intact) •... - Page 15 Configuration and Usage PAGE INTENTIONALLY BLANK...
-
Page 16: Section 3 – Electrical Specifications
RC Series Rackmount Installation Manual Section 3 – Electrical Specifications 3 .1 Electrical Specifications RC Series Rackmount Power Supplies Specifications RC75 Series RC75B Series RC150 Series RC150B Series AC Input Voltage 120/230VAC 120/230VAC 120/230VAC 120/230VAC ±15% at 50-60Hz ±15% at 50-60Hz ±15% at 50-60Hz ±15% at 50-60Hz Power... - Page 17 LifeSafety Power’s only obligations are those in the LifeSafety Power Standard Terms Tel (888) 577-2898 and Conditions of Sale for this product, and in no case will LifeSafety Power or its distributors be liable for any incidental, indirect, or conse- info@lifesafetypower .com quential damages arising from the sale, resale, use, or misuse of the product.
- Page 18 LifeSafety Power’s only ob- Tel (888) 577-2898 ligations are those in the LifeSafety Power Standard Terms and Conditions of Sale for this product, and in no case will info@lifesafetypower .com LifeSafety Power or its distributors be liable for any incidental, indirect, or consequential damages arising from the sale, resale, use, or misuse of the product.
