FlexPower
DC Power System Installation Manual
LifeSafety Power, Inc. | PH 888.577.2898 | TechSupport@LifeSafetyPower.com
P03-40 Rev A15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexPower and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LifeSafety Power FlexPower

  • Page 1 FlexPower DC Power System Installation Manual LifeSafety Power, Inc. | PH 888.577.2898 | TechSupport@LifeSafetyPower.com P03-40 Rev A15...
  • Page 2: Table Of Contents

    FlexPower DC Power System Installation Manual Table of Contents Notes and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii Symbol Definitions .
  • Page 3: Notes And Warnings

    Notes and Warnings Symbol Definitions Regulatory Information The following symbols are used throughout this manual: The equipment discussed within this manual has been test- ed to the following standards: This symbol is intended to alert the installer of shock • UL294, UL603, UL1076 hazards within the enclosure .
  • Page 4: Power Supply Quick Start

    FlexPower DC Power System Installation Manual Power Supply Quick Start This section gives a quick visual guide of installation connections and settings for installers already familiar with the Flex- Power line of power supplies . For full information, please read this entire manual before installing .
  • Page 5: Section 1 - Installation And Operation

    Use the following procedure when mounting an FPO power sup- Male to female Stando ply to a LifeSafety Power enclosure (figure 2) . 1 . Locate the appropriate mounting holes in the enclosure and snap the four or six standoffs provided into the holes .
  • Page 6 FlexPower DC Power System Installation Manual FPO75 120/230VAC    Cut for 230V Cut for 230V   DC2 NO DC2 NO  DC2 NC DC2 NC  AC Input Battery Battery Detect Detect GND FLT  REV BAT ...
  • Page 7: Jumper / Led / Connector Descriptions

    This LED lights when a system trouble is detected by the DataLink cables and the PowerCom software package are FPO . Trouble conditions indicated by the SYS FLT LED available separately from LifeSafety Power for accessing these include: features .
  • Page 8 FlexPower DC Power System Installation Manual FPO75 120/230VAC    Cut for 230V Cut for 230V   DC2 NO DC2 NO  DC2 NC DC2 NC  AC Input Battery Battery Detect Detect GND FLT  REV BAT ...
  • Page 9 Installation and Operation 12V batteries in series) . Battery Presence Detection (JP3) The BAT DET jumper en- Observe polarity or damage to the system will occur . ables or disables Battery Presence (BP) fault detection as follows: • Position 1 (jumper ON) Enable EG Fault Detection It is the installer’s responsibility to determine the proper bat- •...
  • Page 10: Fai Input Usage

    FlexPower DC Power System Installation Manual 1 .3 FAI Input Usage This section provides more detailed information on the connection and usage of the FAI input . Activation with a Normally Open Relay Contact Latching the FAI Input FAI Activates when the...
  • Page 11: Typical Installation & Wire Routing

    Installation and Operation 1 .4 Typical Installation & Wire Routing AC Input Wiring AC Input Wiring Class Class FPO75 FPO150 FPO250 The drawing above shows a typical installation . • Any wiring passing through knockouts in the bottom or top surfaces of the enclosure must be enclosed in rigid Actual configuration and wire routing will vary based on or flexible metal conduit .
  • Page 12: Power-Up And Basic System Verification Checklist

    FlexPower DC Power System Installation Manual Section 1 – Installation and Operation 1 .5 Power-Up and Basic System Verification Checklist 1 . Ensure proper configuration of all jumpers and switches . 2 . Apply AC power to the FPO power supply .
  • Page 13: Section 2 - Troubleshooting And Maintenance

    High or Low Output Voltage • Measure the output voltage at the DC1 terminals . The voltage should be 12 .50V for the 12V setting or 25 .00V for the 24V setting (±10%) . Contact LifeSafety Power if the voltage is outside of this range Blown Fuse •...
  • Page 14: Troubleshooting Table (Continued)

    FlexPower DC Power System Installation Manual Section 2 – Troubleshooting and Maintenance 2 .1 Troubleshooting Table (continued) Symptom Possible Problem Information / Possible Solution No DC2 Output Blown DC2 Fuse • Check fuse DC2 LED Extinguished • Verify the integrity of the output wiring and powered devices before replac- ing any ruptured fuses .
  • Page 15: Section 3 - Specifications

    Specifications Section 3 – Specifications 3 .1 Electrical Specifications FPO Power Supplies Specifications FPO75 FPO150 FPO250 AC Input Voltage 120VAC or 230VAC 120VAC or 230VAC 120VAC or 230VAC ±15% at 50-60Hz ±15% at 50-60Hz ±15% at 50-60Hz Current 1 .6A 2 .5A 3 .2A Standby...
  • Page 16: Temperature Specifications

    FlexPower DC Power System Installation Manual Section 3 – Specifications 3 .2 Temperature Specifications All Models Ambient Temperature 0°C to 49°C (32°F to 120°F) Ambient Humidity 93% at 32°C (90°F) maximum Storage Temperature –30°C to 70°C (–22°F to 158°F) 3 .3 Mechanical Specifications Visit www .lifesafetypower .com for AutoCAD files .
  • Page 17: Replacement Parts

    Specifications Section 3 – Specifications 3 .4 Replacement Parts Board Kits Order # Description FPO250 A01-007 FPO250 replacement board FPO150 A01-005 FPO150 replacement board FPO75 A01-003 FPO75 replacement board A05-006 Battery Disconnect Module cable B100 A03-009 DC-DC Convertor (12VDC or adjustable 5 to 18VDC) replacement board A02-001 Simple distribution replacement board A02-002...
  • Page 18: Appendix 1 - Tamper Switch Wiring

    Appendix 2 – User Certificate Below is a certificate required for UL603 installations, to be cut out, framed and hung adjacent to the FlexPower Power Supply system after installation . It contains the required battery information, as specified in UL603 .
  • Page 19: Appendix 3 - Ul Compliance Verification Sheet

    User Certificate Appendix 3 – UL Compliance Verification Sheet General - All Applications: 1 . The power supply must be installed within the protected area . 2 . The LifeSafety Model EB-80 must be used to house the required battery(ies) when capacites of 40 to 80Ah are re- quired .
