FlexPower Generation 2
DC Power System Installation Manual
LifeSafety Power, Inc. | PH 888.577.2898 | TechSupport@LifeSafetyPower.com
P03-40 Rev A18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexPower Generation 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LifeSafety Power FlexPower Generation 2

  • Page 1 FlexPower Generation 2 DC Power System Installation Manual LifeSafety Power, Inc. | PH 888.577.2898 | TechSupport@LifeSafetyPower.com P03-40 Rev A18...
  • Page 2: Table Of Contents

    FlexPower Generation 2 DC Power System Installation Manual Table of Contents Notes and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii Symbol Definitions .
  • Page 3: Notes And Warnings

    Notes and Warnings Symbol Definitions Regulatory Information The following symbols are used throughout this manual: The equipment discussed within this manual has been test- ed to the following standards: This symbol is intended to alert the installer of shock • UL294, UL603, UL1076 hazards within the enclosure .
  • Page 4: Power Supply Quick Start

    FlexPower Generation 2 DC Power System Installation Manual Power Supply Quick Start This section gives a quick visual guide of installation connections and settings for installers already familiar with the Flex- Power line of power supplies . For full information, please read this entire manual before installing .
  • Page 5: Section 1 - Installation And Operation

    Use the following procedure when mounting an FPO power sup- Male to female Stando ply to a LifeSafety Power enclosure (figure 2) . 1 . Locate the appropriate mounting holes in the enclosure and snap the four or six standoffs provided into the holes .
  • Page 6 FlexPower Generation 2 DC Power System Installation Manual FPO75  REV BAT  120/230VAC Observe battery polarity Observe battery polarity  or damage may result or damage may result  Cut for 230V Cut for 230V    ...
  • Page 7: Jumper / Led / Connector Descriptions

    • 24 24VDC nominal out This connector allows connection of an external AC ON indicator in rack mount applications . Only a LifeSafety Power AC LED should be Remove power before changing output voltage or damage to the power connected .
  • Page 8 FlexPower Generation 2 DC Power System Installation Manual FPO75  REV BAT  120/230VAC Observe battery polarity Observe battery polarity  or damage may result or damage may result  Cut for 230V Cut for 230V    ...
  • Page 9 Installation and Operation • DC2  This faston provides an FAI controlled output that oper- DataLink Connection ates in conjunction with the DC2 output terminals . This con- This is the connector for the DataLink connection . It allows optional nection is typically only used in single voltage systems with D8 programming and monitoring of the FPO power supply via an optional accessory boards .
  • Page 10: Fai Input Usage

    FlexPower Generation 2 DC Power System Installation Manual 1 .3 FAI Input Usage This section provides more detailed information on the connection and usage of the FAI input . Activation with a Normally Open Relay Contact Latching the FAI Input...
  • Page 11: Typical Installation & Wire Routing

    Installation and Operation 1 .4 Typical Installation & Wire Routing AC Input Wiring AC Input Wiring Class Class FPO75 FPO150 FPO250 The drawing above shows a typical installation . • Any wiring passing through knockouts in the bottom or top surfaces of the enclosure must be enclosed in rigid Actual configuration and wire routing will vary based on or flexible metal conduit .
  • Page 12: Ac Switch And Terminal Wiring

    FlexPower Generation 2 DC Power System Installation Manual 1 .5 AC Terminal and Switch Wiring Some LSP enclosures contain a lighted AC disconnect switch and a terminal strip for the primary AC connection . The diagram below shows the connections for the switch and AC Input terminal strip .
  • Page 13: Power-Up And Basic System Verification Checklist

    Installation and Operation 1 .7 Power-Up and Basic System Verification Checklist 1 . Ensure proper configuration of all jumpers and 8 . If the battery presence jumper is enabled, remove switches . one lead from the battery – verify that the yel- low “SYS FLT”...
  • Page 14: Section 2 - Troubleshooting And Maintenance

    High or Low Output Voltage • Measure the output voltage at the DC1 terminals . The voltage should be 12 .50V for the 12V setting or 25 .00V for the 24V setting (±10%) . Contact LifeSafety Power if the voltage is outside of this range Blown Fuse •...
  • Page 15: Troubleshooting Table (Continued)

    Troubleshooting Section 2 – Troubleshooting and Maintenance 2 .1 Troubleshooting Table (continued) Symptom Possible Problem Information / Possible Solution No DC2 Output Output disabled due to FAI • The DC2 output is disabled when the FAI input is active . Verify the red DC2 LSD Extinguished FAI LED is extinguished .
  • Page 16: Section 3 - Specifications

    FlexPower Generation 2 DC Power System Installation Manual Section 3 – Specifications 3 .1 Electrical Specifications FPO Power Supplies Specifications FPO75 FPO150 FPO250 AC Input Voltage 120VAC or 230VAC 120VAC or 230VAC 120VAC or 230VAC +10%/-15% at 50- +10%/-15% at 50-...
  • Page 17: Temperature Specifications

    Specifications Section 3 – Specifications 3 .2 Temperature Specifications All Models Ambient Temperature 0°C to 49°C (32°F to 120°F) Ambient Humidity 93% at 32°C (90°F) maximum Storage Temperature –30°C to 70°C (–22°F to 158°F) 3 .3 Mechanical Specifications Visit www .lifesafetypower .com for AutoCAD files . Power Supply Board - FPO75 Size 6 .00"...
  • Page 18: Replacement Parts

    FlexPower Generation 2 DC Power System Installation Manual Section 3 – Specifications 3 .4 Replacement Parts Board Kits Description FPO250 FPO250 replacement board FPO150 FPO150 replacement board FPO75 FPO75 replacement board B100 DC-DC Convertor (12VDC or adjustable 5 to 18VDC) replacement board...
  • Page 19: Appendix 1 - Tamper Switch Wiring

    Tamper Switch / User Certificate Appendix 1 – Tamper Switch Wiring All FlexPower DC systems with an enclosure include a normally closed tamper switch for monitoring by the host panel . The tamper switch can either be brought into a dedicated input in the panel (see the panel's instructions), to the Event 1 input of a Netlink Network Module (See the Netlink's Instruction Manual), or the tamper switch may be series connected into the System...
  • Page 20: Appendix 3 - Ul Compliance Verification Sheet

    FlexPower Generation 2 DC Power System Installation Manual Appendix 3 – UL Compliance Verification Sheet General - All Applications: 1 . The power supply must be installed within the protected area . 2 . The LifeSafety Model EB-80 must be used to house the required battery(ies) when capacites of 40 to 80Ah are re- quired .
  • Page 21 UL Compliance Verification...
  • Page 22 Conditions of Sale for this product, and in no case will LifeSafety Power or its distributors be liable for any incidental, indirect, or consequential damages arising from the sale, resale, use, or misuse of the product. Specifications are subject to change without notice.
