Before You Begin
Tools
Gather required tools and parts before starting installation. Read
and follow the instructions provided with any tools listed here.
1.
Regular screwdriver
2.
Phillips screwdriver
3.
7/16" and 1/2" open-end wrenches (or an adjustable wrench)
4.
Pliers
5.
1/4" nut driver
6.
Level
7.
Ruler
8.
Electric screwdriver
Components
Remove the contents from the shipping carton and set them on a
table where they can be easily identified and located.
Do not discard any of the packing material until all required parts
are identified.
QTY
DESCRIPTION
Ice Maker Assembly
1
Jumper Harness
2
Ice Pan
1
Fill Tube Assembly
1
Water Line Cover
1
5/8" screws
5
Water Line Clamp
1
Compression Nut & Sleeve
1
Water Valve
2
Adhesive Clip
1
Splash Guard
1
Tube Guide
1
Air Diverter
1
Installation Instructions
1
Installation notes
For each set of steps shown, refer to the diagram immediately
beside or below the text for clarification. Some illustrations may
contain labels A, B, or C, which are referenced in associated
steps. Some illustrations also contain "DETAILS." DETAILS are
contained in bubbles alongside the larger illustration.
Install the parts as instructed in each step and corresponding
illustration.
4
