G965 Micro 775

Table of Contents

BIOS Setup .................................................................................................1
1 Main Menu...............................................................................................3
2 Standard CMOS Features......................................................................6
3 Advanced BIOS Features .......................................................................8
4 Advanced Chipset Features..................................................................16
5 Integrated Peripherals..........................................................................19
6 Power Management Setup....................................................................24
7 PnP/PCI Configurations.......................................................................30
8 PC Health Status ...................................................................................33
9 Performance Booster Zone...................................................................35

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G965 Micro 775 and is the answer not in the manual?

Questions and answers

Related Manuals for Biostar G965 Micro 775

Summary of Contents for Biostar G965 Micro 775

  • Page 1: Table Of Contents

    G965 Micro 775 Table of Contents BIOS Setup ...1 1 Main Menu...3 2 Standard CMOS Features...6 3 Advanced BIOS Features ...8 4 Advanced Chipset Features...16 5 Integrated Peripherals...19 6 Power Management Setup...24 7 PnP/PCI Configurations...30 8 PC Health Status ...33...

  • Page 2: Bios Setup

    Introduction The purpose of this manual is to describe the settings in the Phoenix-Award™ BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. The power of CMOS RAM is supplied by a battery so that it retains the Setup inform ation when the power is turned off.

  • Page 3: Pci Bus Support

    G965 Micro 775 ACPI Support Phoenix-Award ACPI BIOS support Version 1.0b o f Advan ced Con figuration and Power interface speci fi cation (ACPI). management and devi ce con figu ration cap abilities as defined in the ACPI speci fication, developed by Microsoft, Intel and Toshiba.

  • Page 4: Main Menu

    G965 Micro 775 1 Main Menu Once you enter Phoenix-Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions. Use the arrow keys to select among the items and press <Enter>...

  • Page 5: Advanced Chipset Features

    G965 Micro 775 Advanced BIOS Features This submenu allows you to configure advanced features of the BIOS. Advanced Chipset Features This submenu allows you to configure special chipset featu res. Integrated Peripherals This submenu allows you to configure cert ain IDE hard drive options and Programmed Input/ Output features.

  • Page 6: Set Supervisor Password

    G965 Micro 775 Set Supervisor Password Setting the supervisor password will prohibit everyone except the supervisor from making changes using the CMOS Setup Utility. You will be prompted with to enter a password. Set User Password If the Supervisor Password is not set, then the User Password will function in the same way as the Supervisor Password.

  • Page 7: Standard Cmos Features

    G965 Micro 775 2 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into several categori es. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the<PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 8 G965 Micro 775 Item Options 360K, 5.25 in 1.2M, 5.25 in Driv e A 720K, 3.5 in Driv e B 1.44M, 3.5 in 2.88M, 3.5 in None All Errors No Errors Halt On All, but Key board All, but Diskette...

  • Page 9: Advanced Bios Features

    G965 Micro 775 3 Advanced BIOS Features Figure 3: Advanced BIOS Setup Cache Setup...

  • Page 10: Boot Seq & Floppy Setup

    G965 Micro 775 CPU L3 Cache Depending on the CP U/chipset in use, you may be able to increase me mory access time with this option. Enabled (default) Enable cache. Disabled Disable cache. Boot Seq & Floppy Setup This item allows you to setup boot sequence & Floppy.

  • Page 11: Hard Disk Boot Priority

    G965 Micro 775 Hard Disk Boot Priority The BIOS will attempt to arrange the Hard Disk boot sequence automatically. You can change the Hard Disk booting sequence here. The Choices: Pri. Master, Pri. Slave, Sec. Master, Sec. Slave, USB HDD0, USB HDD1, USB HDD2, and Bootable Add-in Cards.

  • Page 12: Cpu Feature

    G965 Micro 775 Boot Up Floppy Seek When enabled, System will test the floppy drives to determine if they have 40 or 80 tracks during boot up. Disabling this option reduces the time it takes to boot-up. The Choices: Enabled (default), Disabled.

  • Page 13: Virtualization Technology

    G965 Micro 775 TM2 Bus Ratio This option represents the frequency (bus ratio) of the throttled performance state that will be initiated when the on-die sensor detects temperature increase. Min= 0 Max= 255, Key in a DEC number. The Choices: 0 X (default)

  • Page 14: Quick Power On Self Test

    G965 Micro 775 Hyper-Threading Technology This option allows you to enable or disabled Hyper-Threading Technology. “ Enabled” Windows Hyper-Threading Technology). “ Disable” for other OS (OS not optimized for Hyper-Threading Technology). The Choices: Enabled (default), Disabled. Quick Power On Self Test Enabling this option will cause an abridged version o f the Power On Self-Test (POST) to execute after you power up the computer.

  • Page 15: Mps Version Control For Os

    G965 Micro 775 Typematic Dela y (Msec) Sets the delay time after the key is held down before it begins to repeat the keystroke. The Choices: 250 (default), 500, 750, 1000. Security Option This option will enable only individuals with passwords to bring the system online and/or to use the CMOS Setup Utility.

  • Page 16: Summary Screen Show

    G965 Micro 775 Small Logo(EPA) Show This item allows you to select whether the “Small Logo” shows. Enabled “Small Logo” shows when system boots up. Disabled (default) No “Small Logo” shows when system boots The Choices: Disabled (default), Enabled. Summary Screen Show This item allows you to enable/disable the summary screen.

  • Page 17: Advanced Chipset Features

    G965 Micro 775 4 Advanced Chipset Features This submenu allows you to configure the speci fic features o f the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus.

  • Page 18: Memory Hole At 15M-16M

    G965 Micro 775 Memory Hole At 15M-16M You can reserve this area of system memory for ISA adapter ROM. When this area is reserved it cannot be cached. Check the user information of periph erals that need to use this area of system memory fo r the memory requirements.

  • Page 19: Dvmt Mode

    G965 Micro 775 VGA Settings PEG/Onchip VGA Control This item allows you to enable or disable P EG/On-chip VGA controller. The Choices: Auto (default), P EG P ort, Onchip VGA. PEG Force X1 When using on-chip VGA, this item has to be set as X1.

  • Page 20: Integrated Peripherals

    G965 Micro 775 5 Integrated Peripherals Figure 5: Integrated Peripherals OnChip IDE Device...

  • Page 21: Ide Dma Transfer Access

    G965 Micro 775 IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sectors read / write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read / write per sector where the drive can support.

  • Page 22: Onboard Device

    G965 Micro 775 Onboard Device USB Controller Select enabled if your system contains a Universal Serial Bus (USB) controller and you use USB peripherals. The Choices: Enabled (default), Disabled USB 2.0 Controller This entry is to enabled/ disabled EHCI controller only. This Bios itself may/may not have high speed USB support.

  • Page 23: Super Io Device

    G965 Micro 775 Onboard Azalia Audio This item allows you to enable or disable to support Onboard Azalia Audio function. The Choices: Auto (default),Disabled. Onboard PATA IDE(VT6410) This item allows you to support the Onboard P ATA IDE. The Choices: Enabled (default), Disabled.

  • Page 24: Onboard Parallel Port

    G965 Micro 775 Onboard Serial Port 1 Select an address and corresponding interrupt for the first and second serial ports. The Choices: 3F8/IRQ4 (default), Disabled, 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Auto. The Choices: SCR, AS KIR, IrDA (default). Onboard Parallel Port This item allows you to determine access onboard parallel port controller with which I/O Address.

  • Page 25: Power Management Setup

    G965 Micro 775 6 Power Management Setup The Power Management Setup Menu allows you to con figure you r system to utilize energy conservation and power up/power down featu res. Figure 6. Power Management Setup ACPI & Wake Up Events...

  • Page 26: Acpi Suspend Type

    G965 Micro 775 ACPI Function This item displays the status of the Advanced Configuration and P ower Management (ACP I). The Choices: Enabled (default), Disabled. ACPI Suspend Type The item allows you to select the suspend type under the ACP I operating system.

  • Page 27: Reload Timer Events

    G965 Micro 775 You can choose the system boot up time, input hour, minute and second to specify. Note: If you have change the setting, you must let the system boot into operating system, before this function will work. POWER ON Function This item allows you to choose the power on method.

  • Page 28: Power Management

    G965 Micro 775 Primary/Secondary IDE 0/1 You can enable or disable P rimary or Secondary RAID 0 or RAID 1 function under this item. The Choices: Disabled (default), Enabled. FDD, COM, LPT Port You can enable or disable FDD, COM, and LP T port under this item.

  • Page 29: Video Off In Suspend

    G965 Micro 775 Video Off Method This option determines the manner when the monitor goes blank. V/H SYNC+Blank This selection will cause the system to turn off the vertical and horizontal synchronization ports and write blanks to the video buffer.

  • Page 30: Soft-Off By Pwr-Btn

    G965 Micro 775 Soft-Off by PWR-BTN This item determines the behavior of system power button. Instant off turn o ff the power immediately, and Delay 4 Sec. will require you to press and hold the power button for 4 seconds to cut off the system power.

  • Page 31: Pnp/Pci Configurations

    G965 Micro 775 7 PnP/PCI Configurations This section describes configu ring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components.

  • Page 32: Resources Controlled By

    G965 Micro 775 the new configuration varies from the last one. If the Enabled option is chosen, the system is forced to update ESCDs and then is automatically set to the “ Disabled” mode. The above settings will be shown on the screen only if “ Manual” is chosen for the resources controlled by function.

  • Page 33: Maximum Payload Size

    G965 Micro 775 Assign IRQ For USB This item allows the users to choose which IRQ to assign for the USB. The Choices: Enabled (default), Disabled. Maximum Payload Size Set maximum TLP payload size for the PCI Express device.The unit is byte .

  • Page 34: Pc Health Status

    G965 Micro 775 8 PC Health Status Figure 8: PC Health Status CPU FAN Control by Choose “ smart” to reduce the noise caused by CPU FAN. The Choices: Smart (default), Always On. CPU Fan Off<℃> If the CPU Temperature is lower than the set value, FAN will turn off.

  • Page 35: Shutdown Temperature

    G965 Micro 775 Start PWM Value When CPU temperature arrives to the set value, the CPU fan will work under Smart Fan Function mode. The range is from 0~127, with an interval of 1. Min= 0 Max= 127, Key in a DEC number.

  • Page 36: Performance Booster Zone

    G965 Micro 775 9 Performance Booster Zone Figure 9: Performance Booster Zone DRAM Timing Selectable When synchronous DRAM is installed, the number of clock cy cles o f CAS latency depends on the DRAM timing. This item allows you to choose between auto and manual adjusting DRAM Timing.
  • Page 37 G965 Micro 775 DRAM RAS# to CAS# Dela y This field allows you to insert a timing delay between the CAS and RAS strobe signals, used when DRAM is written to, read from, or refreshed. Low value will provide a fast er performance; and high value made the system more stable. This fi eld applies only when synchronous DRAM is installed in the system.

  • Page 38: Fsb Termination Voltage

    G965 Micro 775 CPU Clock Ratio This item allows you to select the CPU Ratio. Min= 8 Max= 50, Key in a DEC number. The Choices: 8X (default). CPU Clock This item allows you to select CPU Clock, and CPU over clocking.

  • Page 39: Memory Voltage

    G965 Micro 775 (G)MCH Voltage This item allows you to select (G)MCH Voltage Control. The Choices: 1.25V (default), 1.35V, 1.45V, 1.55V. Memory Voltage This item allows you to select memory Voltage Control. The Choices: 1.85V (default), 1.95V, 2.05V, 2.15V, 2.25V, 2.35V, 2.45V,...
