G31D-M7 BIOS Manual
BIOS Setup .................................................................................................1
1 Main Menu...............................................................................................3
2 Advanced Menu.......................................................................................7
3 PCIPnP Menu........................................................................................18
4 Boot Menu..............................................................................................22
5 Chipset Menu.........................................................................................24
6 Performance Menu...............................................................................29
7 Exit Menu...............................................................................................31
i
Advertisement
Table of Contents
Related Manuals for Biostar G31D-M7
Summary of Contents for Biostar G31D-M7
- Page 1 G31D-M7 BIOS Manual BIOS Setup ....................1 1 Main Menu....................3 2 Advanced Menu..................7 3 PCIPnP Menu..................18 4 Boot Menu....................22 5 Chipset Menu..................24 6 Performance Menu................29 7 Exit Menu....................31...
-
Page 2: Bios Setup
G31D-M7 BIOS Manual BIOS Setup Introduction T he purpose of this manual is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. T he power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off. -
Page 3: Pci Bus Support
G31D-M7 BIOS Manual PCI Bus Support T his AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconn ect) local bus speci fication. DRAM S upport DDR2 SDRAM (Double Data Rate II Synchronous DRAM) is supported. Supported CP Us T his AMI BIOS supports the Intel CPU. -
Page 4: System Memory
G31D-M7 BIOS Manual 1 Main Menu Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system inform ation. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot... -
Page 5: Ata/Ide Configuration
G31D-M7 BIOS Manual Floppy A Select the type of floppy disk drive installed in your system. Options: 360K, 5.25 in / 1.2M, 5.25 in / 720K, 3.5 in / 1.44M, 3.5 in / 2.88M, 3.5 in / None IDE Configuration T he BIOS will automatically detect the presence of ID E/SAT A devices. - Page 6 G31D-M7 BIOS Manual SATA1/2/3/4 Dev ice; IDE Channel 1 Master/Slave BIOS SETU P U TILITY Main SATA1 Device Select the type of device connected Device to the system. Type [Aut o] LBA/Large Mode [Aut o] Block (Multi-S ector Transfer)[Aut o]...
-
Page 7: Hard Disk Write Protect
G31D-M7 BIOS Manual S.M.A.R.T Set the Smart Monitoring, Analysis, and Reporting T echnology. Options: Auto (Default) / Disabled / Enabled 32Bit Data Transfer Enable or disable 32-bit data transfer. Options: Enabled (Default) / Disabled Hard Disk Write Protect Disable or enable device write protection. T his will be effective only if the device is accessed through BIOS. -
Page 8: Advanced Menu
G31D-M7 BIOS Manual 2 Advanced Menu T he Advanced Menu allows you to configu re the settings of CPU, Super I/O, Power Management, and other system devices. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. - Page 9 G31D-M7 BIOS Manual C1E Support C1E is “Enhanced Halt State” function, this f unction helps to save power and decrease heat by lowering CPU frequen cy while the processor is not working. Options: Enabled (Default) / Disabled Hardware Prefetcher T he processor has a hardw are prefetch er that automatically analy zes its requirements and prefetches dat a and instructions from the memory into the Level 2 cache that are likely to be required in the near future.
-
Page 10: Core Multi-Processing
G31D-M7 BIOS Manual PECI T his item allows you to control the PECI function for the processor which supports Platform Environment Control Interface for better therm al management. Options: Disabled (Default) / Enabled Core Multi-Processing T his item allows multi-processing fun ction for multi-core processors. - Page 11 G31D-M7 BIOS Manual Onboard Floppy Controller Select enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you installed another FDC or the system uses no floppy drive, select disabled in this field.
-
Page 12: Mouse Poweron
G31D-M7 BIOS Manual Specific Key Enter T his item will show only when Keyboard PowerOn is set “Specific Key.” Stroke Keys Selected T his item will show only when Keyboard PowerOn is set “Stroke Key.” Options: Ctrl+F1 (Default) / Wake Key / Power Key / Ctrl+F2 / Ctrl+F3 /... -
Page 13: Smart Fan Configuration
G31D-M7 BIOS Manual H/W Health Function If with a monitoring system, the system will show PC health status during POST stage. Options: Enabled (Default) / Disabled Shutdow n Temperature Function T his item allows you to set up the CPU shutdown T emperature. This item is only effective under Windows 98 ACPI mode. -
Page 14: Power Configuration
G31D-M7 BIOS Manual Control Mode T his item provides several operation modes of the fan. Options: Quiet / Performan ce / Manual Fan Ctrl OFF(℃ ) If the CPU/System T emperature is lower than the set value, FAN will turn off. - Page 15 G31D-M7 BIOS Manual Suspend mode T he item allows you to select the suspend type under the ACPI operating system. Options: S1 (POS) (Default) Power on Suspend S3 (ST R) Suspend to RAM Auto POS+STR Repost Video on S3 Resume T he item allows you to determine whether to invoke VGA BIOS post on S3/ST R resume.
- Page 16 G31D-M7 BIOS Manual APIC ACPI SCI IRQ Options: Disabled (Default) / Enabled USB Dev ice Wakeup from S3/S4 T his item allows you to enable or disabled the USB resume from S3/S4 function. Options: Disabled (Default) / Enabled High Performance Event Timer T his item allows you to enable or disabled the HPET.
-
Page 17: Usb Configuration
G31D-M7 BIOS Manual RTC Alarm Time You can choose the system boot up time, input hour, minute and second to specify. Note: This function will be effective only when the operating system finishes all procedure of booting. USB Configuration T his item shows the USB controller and using USB device information. - Page 18 G31D-M7 BIOS Manual USB Mass Storage Dev ice Configuration BIOS SETUP UTILITY Advanced USB Mass Storage Device Configuration Number of seconds POST waits for the USB Mass Storage Reset Delay [20 Sec] USB mass storage device after start Device # unit command.
-
Page 19: Pcipnp Menu
G31D-M7 BIOS Manual 3 PCIPnP Menu T his section describes con figuring the PCI bus system. PCI, or Personal Computer Interconn ect, is a system which allows I/O devices to operate at speeds nearing the speed o f the CPU itself uses when communicating with its own special components. -
Page 20: Pci Latency Timer
G31D-M7 BIOS Manual PCI Latency Timer T his item controls how long a PCI device can hold the PCI bus bef ore another takes over. T he longer the latency, the longer the PCI device can retain control of the bus before handing it over to another PCI device. -
Page 21: Reserved Memory Size
G31D-M7 BIOS Manual IRQ3/4/5/7/9/10/11/14/15 T hese items will allow you to assign each system interrupt a type, depending on the type of device using the interrupt. T he option “Available” means the IRQ is going to assign automatically. Options: Available (Default) / Reserved... - Page 22 G31D-M7 BIOS Manual SB PCIE Ports Configuration BIOS SETU P U TILITY PCIPnP PCIE Ports Con figuration Options PCIE Port 0 [Aut o] PCIE Port 1 [Aut o] Auto PCIE Port 2 [Aut o] Enabled PCIE Port 3 [Aut o]...
-
Page 23: Boot Device Priority
G31D-M7 BIOS Manual 4 Boot Menu T his menu allows you to setup the system boot options. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset Performance Exit Boot Settings Specifies the Boot Device Priority sequence. > Boot Device Priority >... -
Page 24: Cd/Dvd Drives
G31D-M7 BIOS Manual CD/DV D Drives T he BIOS will attempt to arrange the CD/DVD drive boot sequence automatically. You can also change the booting sequence. The number of device items that appears on the screen depends on the number of devices installed in the system. -
Page 25: Chipset Menu
G31D-M7 BIOS Manual 5 Chipset Menu T his submenu allows you to configure the speci fic features of the chipset installed on your system. T his chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. -
Page 26: North Bridge Configuration
G31D-M7 BIOS Manual North Bridge Configuration BIOS SETU P U TILITY Chipset North Bridge C hipset Configuratio n ENABLE: Allow remapping of Memory Remap F eature [E nabled] overlapped PCI memory PCI MMIO All ocation: above the total Memory Hole [D isabled] physical memory. -
Page 27: Video Function Configuration
G31D-M7 BIOS Manual PEG Port T his BIOS feature is a toggle that enables or disables the PCI Express port. Options: Auto (Default) / Disabled Video Function Configuration BIOS SETU P U TILITY Chipset Video Function Configuration Options DVMT Mode Sele ct... -
Page 28: South Bridge Configuration
G31D-M7 BIOS Manual South Bridge Configuration BIOS SETU P U TILITY Chipset South Bridge C hipset Configuratio n Options USB Functions [8 USB Ports] Disabled USB 2.0 Contro ller [E nabled] 2 USB Ports Audio Controll er [A zalia] 4 USB Ports... -
Page 29: Onboard Lan Control
G31D-M7 BIOS Manual Onboard Lan Control T his item allows you to enable or disable the Onboard LAN. Options: Enabled (Default) / Disabled Onboard Lan Boot Rom T his item allows you to select the Onboard LAN Boot ROM. Options:... -
Page 30: Performance Menu
G31D-M7 BIOS Manual 6 Performance Menu T his submenu allows you to change voltage and clock of various devices. (Howev er, we suggest you to use the def ault setting. Changing the voltage and clock improperly may damage the device.) - Page 31 G31D-M7 BIOS Manual CPU Voltage T his item allows you to select CPU Voltage Control. Options: Default (Default) / +5% / +10% / +15% FS B Voltage T his item allows you to select FSB Voltage Control. Options: Default (Default) / +0.1V / +0.2V / +0.3V Memory Voltage T his item allows you to select Memory Voltage Control.
-
Page 32: Save Changes And Exit
G31D-M7 BIOS Manual 7 Exit Menu T his menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset Performance Exit... -
Page 33: Change Supervisor Password
G31D-M7 BIOS Manual Security T his sub-menu allows you to provide/revise supervisor and user password. BIOS SETU P U TILITY Exit Security Setti ngs Install or Change the password. Supervisor Pas sword :Not Installe d User Password :Not Installe d... - Page 34 G31D-M7 BIOS Manual Passw ord Check T his item is for setting the timing that checking password. Options: Setup (Default) / Always Boot Sector Virus Protection T his option allows you to choose the VIRUS Warning feature that is used to protect the IDE H ard Disk boot sector.
