GF7025-M2 Setup Manual
FCC Information and Copyright
This equipment has been tes ted and found to comply with the limits of a Class
B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed
to provide reasonable protec tion against harmful interference in a residential
installation. T his equipment generates , uses , and c an radiate radio frequency
energy and, if not ins talled and used in accordance with the instructions , may
cause harmful interference to radio communications . There is no guarantee
that interference will not occur in a particular ins tallation.
The vendor makes no representations or warranties with respec t to the
contents here and s pecially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make c hanges to the c ontents here without obligation to
notify any party beforehand.
D uplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be c hanged without notice and
we will not be res ponsible for any mis takes found in this user's manual. All the
brand and produc t names are trademarks of their respec tive companies .

Advertisement

Table of Contents
loading

Summary of Contents for Biostar GF7025-M2

  • Page 1 GF7025-M2 Setup Manual FCC Information and Copyright This equipment has been tes ted and found to comply with the limits of a Class B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed to provide reasonable protec tion against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ..........3 Before You Start..............3 Package Checklist..............3 Motherboard Features............4 Rear Panel Connectors............6 Motherboard Layout ............7 Chapter 2: Hardware Installation......8 Installing Central Processing Unit (CPU) ........ 8 FAN Headers...............10 Installing System Memory.............11 Connectors and Slots ............13 Chapter 3: Headers &...
  • Page 3: Chapter 1: Introduction

    GF7025-M2 CHAPTER 1: INTRODUCTION EFORE T ART Thank you for choosing our product. Be fore you start installing the mothe rboard, please make sure you follow the instructions be low: Prepare a dry and stable work ing environment with sufficie nt lighting.
  • Page 4: Motherboard Features

    Motherboard Manual OT HERBOARD EAT URES Ver 5.x Ver 6.x Socket AM2 Socket AM2 AMD Ath lon 64 / Ath lon 64 FX / Athlon 64 x2 / AMD Ath lon 64 / Ath lon 64 FX / Athlon 64 x2 / Sempron processors Sempron processors AMD 64 Architectu re enables 32 and 64 bit...
  • Page 5 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA OS Support Biostar Reserves th e righ t to add or remove Biostar Reserves th e righ t to add or remove support for any OS With or withou t notice.
  • Page 6: Rear Panel Connectors

    Motherboard Manual ANEL ONNECT ORS PS/2 Mouse Port PS/2 Keyboard Port DVI-D VGA Port The Digital Visual Interface (DVI) is a video i nterface trans mitting digital video signals to digital display devices s uch as flat panel LCDs or digital projectors. The DVI-D connector allows digital signals trans mission onl y .
  • Page 7: Motherboard Layout

    GF7025-M2 OT HERBOARD AYOUT JKB MS1 JCFA N1 JATX PWR2 JUSB1 JATXP WR1 JRJ45USB1 AUDIO1 (for Ver 5.x) GeForce 7025 / JA UDIO1 (for Ver 6.x) NF630 JNFA N1(Opt ional) J AUDIOF1 JUSB3 J US B4 PCI-EX1_1 JSP DIF_OUT1 J US B2...
  • Page 8: Chapter 2: Hardware Installation

    Motherboard Manual CHAPTER 2: HARDWARE INSTALLATION (CPU) NST ALLING ENT RAL ROCESSING Step 1: Remove the socket protection cap. Step 2: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle. Step 3: Look for the white triangle on socket, and the gold triangle on CPU should point towards this white triangle.
  • Page 9 GF7025-M2 Step 4: Hold the CPU down firmly, and then close the lever toward direct B to complete the installation. Step 5: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the JCFAN1. This completes the installation.
  • Page 10: Fan Headers

    Motherboard Manual FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 11: Installing System Memory

    GF7025-M2 NST ALLING YST EM EMORY A. Memory Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM vertically and firmly into the slot until the retaining...
  • Page 12 Motherboard Manual B. Memory Capacity DIMM Socket Total Memory DDR2 Module Location Size DIMMA1 256MB/512MB/1GB/2GB Max is 4GB. DIMMB1 256MB/512MB/1GB/2GB C. Dual Channel Memory installation To trigger the Dual Channel f unction of the motherboard, the memory module must meet the following requirements: Install memory module of the same density in pair, shown in the f ollowing table.
  • Page 13: Connectors And Slots

    GF7025-M2 ONNECT ORS AND LOT S FDD1: Floppy Disk Conne ctor The motherboard prov ides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk ty pes. This connector supports the prov ided f loppy drive ribbon cables.
  • Page 14 Motherboard Manual PCI-EX16: PCI-Express x16 Slot PCI-Express 1.0a compliant. Maximum theoretical realized bandwidth of 4GB/s simultaneously per direction, f or an aggregate of 8GB/s totally. PCI-EX1_1: PCI-Express x1 Slot PCI-Express 1.0a compliant. Data transf er bandwidth up to 250MB/s per direction; 500MB/s in total. PCI-Express supports a raw bit-rate of 2.5GB/s on the data pins.
  • Page 15: Chapter 3: Headers & Jumpers Setup

    GF7025-M2 CHAPTER 3: HEADERS & JUMPERS SETUP OW T O ET UP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.
  • Page 16 Motherboard Manual JATXPWR1: ATX Powe r Source Conne ctor This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V +12V +12V Ground...
  • Page 17 GF7025-M2 JUSB2/JUSB3/JUSB4: He ade rs for USB 2.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC f ront panel, and also can be connected with internal USB devices, like USB card reader.
  • Page 18: Cd-Rom Audio-In Connector

    Motherboard Manual JAUDIO F1: Front Panel Audio Heade r This header allows user to connect the front audio output cable with the PC f ront panel. It will disable the output on back panel audio connectors. Assignment Mic Left in Ground Mic Right in GPIO...
  • Page 19 GF7025-M2 JSPDIF_O UT1: Digital Audio-out Conne ctor This connector allows user to connect the PCI bracket SPDIF output header. Assignment SPDIF_OUT Ground JCMO S1: Cle ar CMOS Heade r By placing the jumper on pin2-3, it allows user to restore the BIOS saf e setting and the CMOS data, please carefully f ollow the procedures to avoid damaging the motherboard.
  • Page 20 Motherboard Manual JPRNT1: Printe r Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK Data 2 Ground -Scltin Busy Data 3 Ground Ground...
  • Page 21: Chapter 4: Raid Functions

    GF7025-M2 CHAPTER 4: RAID FUNCTIONS PERAT ION YST EM Supports Windows XP Home/Prof essional Edition, and Windows 2000 Prof essional. RRAYS RAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications.
  • Page 22 Motherboard Manual RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array.
  • Page 23 GF7025-M2 RAID 0+1: RAID 0 drives can be mirrored using RAID 1 techniques. Resulting in a RAID 0+1 solution for improved performance plus resiliency. Features and Benefits ­ Drives: Minimum 4, and maximum is 6 or 8, depending on the platform.
  • Page 24 Motherboard Manual RAID 5: RAID 5 stripes both data and parity information across three or more drives. It writes data and parity blocks across all the drives in the array. Fault tolerance is maintained by ensuring that the parity information for any given block of data is placed on a different drive from those used to store the data itself.
  • Page 25: Chapter 5: Useful Help

    GF7025-M2 CHAPTER 5: USEFUL HELP RIVER NST ALLAT ION OT E After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD The setup guide will auto detect your motherboard and operating system.
  • Page 26: Award Bios Beep Code

    Motherboard Manual BIOS B WARD Beep Sound Meaning One long beep followed by two short Video card not found or v ideo card beeps memory bad High-low siren sound CPU overheated System will shut down automatically One Short beep when system boot-up No error found during POST Long beeps every other second No DRAM detected or install XT RA...
  • Page 27: Troubleshooting

    GF7025-M2 ROUBLESHOOT ING Probable Solution No power to the system at all Make sure power cable is Power light don’t illuminate, f an securely plugged in. inside power supply does not turn Replace cable. Contact technical support. Indicator light on key board does not turn on.
  • Page 28: Chapter 6: Warpspeederâ„¢ Iii

    Motherboard Manual WARPSPEEDER™ III CHAPTER 6: NT RODUCT ION [WarpSpeeder™ III], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 29: Installation

    GF7025-M2 NST ALLAT ION 1. Execute the setup execution file, and then the following dialog will pop up. Please click “Next” button and follow the default procedure to install. 2. When you see the following dialog in setup procedure, it means setup is completed.
  • Page 30: Warpspeederâ„¢ Iii

    Motherboard Manual 6.4 W ™ III PEEDER 1. Desktop Icon: After the [WarpSpeeder™ III] has been installed, a [WarpSpeeder™ III] icon will appear on the desktop, just like the icon shown below. Now you can launch the [WarpSpeeder™ III] utility simply by double-clicking the desktop icon.
  • Page 31 GF7025-M2 3. Overclock/Overvoltage Panel Click the Overclock/Overvoltage button in the Main Panel, the button will be highlighted and the Overclock/Overvoltage Panel will show up as the following figure. As you can see, the Overclock Panel is on the right side, and the Overvoltage Panel is on the left side.
  • Page 32 Motherboard Manual O ve rclock Panel contains these fe atures: a. “Auto-Overclock”: User can click this button and [WarpSpeeder™ III] will set the best and stable performance and frequency automatically. A warning dialog as below will show up to notify you that the system may become unstable, click on “OK”...
  • Page 33 GF7025-M2 O ve rvoltage Panel contains these fe ature s: a. “CPU Voltage”: This function allows user to adjust CPU voltage. Click on “+” to increase or “-“ to decrease the CPU voltage. b. “Memory Voltage”: This function allows user to adjust Memory voltage. Click on “+”...
  • Page 34 Motherboard Manual 5. About Panel Click the “about” button in Main Panel, the button will be highlighted and the About Panel will show up as the following figure. In this panel, you can get model name and detail information in hints of all the chipset that are related to overclocking.
  • Page 35 GF7025-M2 This page is intentionally left blank.
  • Page 36: Appendencies: Spec In Other Language

    Motherboard Manual APPENDENCIES: SPEC IN OTHER LANGUAGE ERMAN Ver 5.x Ver 6.x Sockel AM2 Sockel AM2 AMD Ath lon 64 / Ath lon 64 FX / Athlon 64 x2 / AMD Ath lon 64 / Ath lon 64 FX / Athlon 64 x2/ Sempron Prozessoren Sempron Prozessoren Die AMD 64-Architektur un terstü...
  • Page 37 Unterstü tzt RAID 0 / 1 / 5 / 0+1 onen Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Biostar beh ält sich das Rech t vor, ohne Biostar beh ält sich das Rech t vor, ohne OS-Un terstüt Ankündigung die Un terstützung für ein Ankündigung die Un terstützung für ein...
  • Page 38: France

    Motherboard Manual RANCE Ver 5.x Ver 6.x Socket AM2 Socket AM2 Processeu rs AMD Athlon 64 / Athlon 64 FX / Processeu rs AMD Athlon 64 / Athlon 64 FX / Ath lon 64 x2 / Sempron Ath lon 64 x2 / Sempron L'architecture AMD 64 permet le calcul 32 et 64 L'architecture AMD 64 permet le calcul 32 et 64 bits...
  • Page 39 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Support SE Biostar se réserve le droit d'ajouter ou de Biostar se réserve le droit d'ajouter ou de supprimer le support de SE avec ou sans préavis. supprimer le support de SE avec ou sans préavis.
  • Page 40: Italian

    Motherboard Manual T ALIAN Ver 5.x Ver 6.x Socket AM2 Socket AM2 Processori AMD Athlon 64 / Athlon 64 FX / Processori AMD Athlon 64 / Athlon 64 FX / Athlon 64 x 2 / Sempro n Athlon 64 x 2/ Sempron L’architettura AMD 64 abilita l a L’architettura AMD 64 abilita l a computazione 32 e 64 bit...
  • Page 41 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Sistemi Biostar si riserva il diritto di aggiungere o Biostar si riserva il diritto di aggiungere o operativi rimuovere il supporto di qualsiasi sistema rimuovere il supporto di qualsiasi sistema supportati operativo se nza pre avviso.
  • Page 42: Spanish

    Motherboard Manual PANISH Ver 5.x Ver 6.x Conector AM2 Conector AM2 Procesadores AMD Athlon 64 / Ath lon 64 FX / Procesadores AMD Athlon 64 / Ath lon 64 FX / Ath lon 64 x2 / Sempron Ath lon 64 x2/ Sempron La arqu itectu ra AMD 64 permite el procesado de La arqu itectu ra AMD 64 permite el procesado de 32 y 64 bits...
  • Page 43 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA sistema Biostar se reserva el derecho de añ adir o retirar Biostar se reserva el derecho de añ adir o retirar operativo el soporte de cualqu ier SO con o sin aviso previo.
  • Page 44: Portuguese

    Motherboard Manual ORT UGUESE Ver 5.x Ver 6.x Socket AM2 Socket AM2 Processadores AMD Ath lon 64 / Ath lon 64 FX / Processadores AMD Ath lon 64 / Ath lon 64 FX / Ath lon 64 x2 / Sempron Ath lon 64 x2/ Sempron A arquitectu ra AMD 64 permite u ma compu tação A arquitectu ra AMD 64 permite u ma compu tação...
  • Page 45 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Sistemas A Biostar reserva-se o direito de adicionar ou A Biostar reserva-se o direito de adicionar ou operativos remover suporte para qu alquer sistema remover suporte para qu alquer sistema suportados operativo com ou sem aviso prévio.
  • Page 46: Specifications

    Motherboard Manual OLISH Ver 5.x Ver 6.x Socket AM2 Socket AM2 AMD Ath lon 64 / Ath lon 64 FX / Athlon 64 x2 / AMD Ath lon 64 / Ath lon 64 FX / Athlon 64 x2 / Sempron Procesory Sempron Procesory Procesor Architektu ra AMD 64 umożliwia przetwarzanie...
  • Page 47 Obsluga Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA systemu Biostar zastrzega sobie prawo dodawania lub Biostar zastrzega sobie prawo dodawania lub operacyjne odwoływania obsługi dowoln ego systemu odwoływania obsługi dowoln ego systemu operacyjnego bez powiadomien ia.
  • Page 48: Russian

    Motherboard Manual USSIAN Ver 5.x Ver 6.x Гнездо AM2 Гнездо AM2 Процессоры AMD Ath lon 64 / Athlon 64 FX / Процессоры AMD Ath lon 64 / Athlon 64 FX / (центральн Ath lon 64 X2 / Sempron Ath lon 64 X2 / Sempron ый...
  • Page 49 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Поддержка Biostar сохран яет за собой право добавлять Biostar сохран яет за собой право добавлять или удалять средства обеспечения для OS с или удалять средства обеспечения для OS с...
  • Page 50: Arabic

    Motherboard Manual RABIC Ver 6.x Ver 5.x ‫ﻡﻘﺒﺲ‬AM2 ‫ﻡﻘﺒﺲ‬AM2 ‫ﻡﻌ ﺎ ﻟﺠﺎت‬AMD Athlon 64 / Athlon 64 FX / ‫ﻡﻌ ﺎ ﻟﺠﺎت‬AMD Athlon 64 / Athlon 64 FX / ‫وﺣﺪة ا ﻟﻤﻌ ﺎ ﻟﺠﺔ‬ Ath lon 64 x2 / Sempron Ath lon 64 x2 / Sempron ‫اﻟﻤﺮآ...
  • Page 51: Pci Express X16

    Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA ‫ﺗﺤﺘﻔﻆ‬Biostar ‫ﺏﺤﻘﻬﺎ ﻓﻲ إﺿﺎﻓﺔ أو إز ا ﻟﺔ اﻟﺪﻋﻢ ﻷ ي ﻥﻈﺎم ﺗﺸﻐﻴﻞ ﺏﺈﺥﻄﺎ ر أو‬ ‫ﺗﺤﺘﻔﻆ‬Biostar ‫ﺏﺤﻘﻬﺎ ﻓﻲ إﺿﺎﻓﺔ أو إز ا ﻟﺔ اﻟﺪﻋﻢ ﻷ ي ﻥﻈﺎم ﺗﺸﻐﻴﻞ ﺏﺈﺥﻄﺎ ر أو‬...
  • Page 52: Japanese

    Motherboard Manual APANESE Ver 5.x Ver 6.x Socket AM2 Socket AM2 AMD Ath lon 64 / Ath lon 64 FX / Athlon 64 x2/ AMD Ath lon 64 / Ath lon 64 FX / Athlon 64 x2/ Sempron プロセッサ Sempron プロセッサ AMD 64アーキテクチャでは、32ビットと64ビット計...
  • Page 53 GF7025-M2 Ver 5.x Ver 6.x ALC888 ALC662 サウンド 7.1 チャンネルオーディオアウト 5.1 チャンネルオーディオアウト Codec ハイデフィニションオーディオのサポート ハイデフィニションオーディオのサポート PCIスロット PCIスロット PCI Express x16スロット PCI Express x16スロット スロット PCI Express x 1スロット PCI Express x 1スロット フロッピーコネクタ フロッピーコネクタ プリンタポートコネクタ プリンタポートコネクタ IDEコネクタ IDEコネクタ SATAコネクタ SATAコネクタ...
  • Page 54 GF7025-M2 BIOS Setup BIOS Setup ....................1 1 Main Menu ..................... 3 2 Standard CMOS Features..............7 3 Advanced BIOS Features ..............9 4 Advanced Chipset Features..............16 5 Integrated Peripherals................. 18 6 Power Management Setup..............25 7 PnP/PCI Configurations..............29 8 PC Health Status ..................
  • Page 55: Bios Setup

    GF7025-M2 BIOS Setup Introduction The purpose of this manual is to describe the settings in the Phoenix-Award™ BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM.
  • Page 56: Acpi Support

    GF7025-M2 ACPI Support Phoenix-Award ACPI BIOS support Version 1.0b of Advanced Configuration and Power interface specification (ACPI). It provides ASL code for power management and device configuration capabilities as defined in the ACPI specification, developed by Microsoft, Intel and Toshiba.
  • Page 57: Main Menu

    GF7025-M2 1 Main Menu Once you enter Phoenix-Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions. Use the arrow keys to select among the items and press <Enter>...
  • Page 58: Load Optimized Defaults

    GF7025-M2 Advanced BIOS Features This submenu allows you to configure advanced features of the BIOS. Advanced Chipset Features This submenu allows you to configure special chipset features. Integrated Peripherals This submenu allows you to configure certain IDE hard drive options and Programmed Input/ Output features.
  • Page 59: Set Supervisor Password

    GF7025-M2 Set Supervisor Password Setting the supervisor password will prohibit everyone except the supervisor from making changes using the CMOS Setup Utility. You will be prompted with to enter a password. Set User Password If the Supervisor Password is not set, then the User Password will function in the same way as the Supervisor Password.
  • Page 60 GF7025-M2 Upgrade BIOS This submenu allows you to upgrade bios.
  • Page 61: Standard Cmos Features

    GF7025-M2 2 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into several categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the<PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 62 GF7025-M2 Item Options Description Press <Enter> to enter the Options are in its sub SATA Channel 1~4 sub menu of detailed menu. options. 360K, 5.25 in 1.2M, 5.25 in Select the type of floppy 720K, 3.5 in Drive A disk drive installed in your 1.44M, 3.5 in...
  • Page 63: Advanced Bios Features

    GF7025-M2 3 Advanced BIOS Features Figure 3: Advanced BIOS Setup CPU Feature...
  • Page 64: Virus Warning

    GF7025-M2 Virtualization The item allows you control the Virtualization function. The Choices: Enabled (default), Disabled. AMD K8 Cool&Quiet control The item allows you select K8 Cool’n’Quiet control. The Choices: Auto (default), Disabled. Virus Warning This option allows you to choose the VIRUS Warning feature that is used to protect the IDE Hard Disk boot sector.
  • Page 65 GF7025-M2 Typematic Rate Setting When a key is held down, the keystroke will repeat at a rate determined by the keyboard controller. When enabled, the typematic rate and typematic delay can be configured. The Choices: Disabled (default), Enabled. Typematic Rate (Chars/Sec) Sets the rate at which a keystroke is repeated when you hold the key down.
  • Page 66: Summary Screen Show

    GF7025-M2 OS Select For DRAM > 64MB A choice other than Non-OS2 is only used for OS2 systems with memory exceeding 64MB. The Choices: Non-OS2 (default), OS2. Small Logo(EPA) Show This item allows you to select whether the “Small Logo” shows. Enabled (default) “Small Logo”...
  • Page 67 GF7025-M2 CPU Internal Cache Depending on the CPU/chipset in use, you may be able to increase memory access time with this option. Enabled (default) Enable cache. Disabled Disable cache. External Cache This option enables or disables “Level 2” secondary cache on the CPU, which may improve performance.
  • Page 68 GF7025-M2 Removable Device Priority Select Removable Boot Device Priority. The Choices: Floppy Disks, Zip100, USB-FDD0, USB-FDD1, USB-ZIP0, USB-ZIP1, LS120. Hard Disk Boot Priority The BIOS will attempt to arrange the Hard Disk boot sequence automatically. You can change the Hard Disk booting sequence here.
  • Page 69: Boot Other Device

    GF7025-M2 CD-ROM Boot Priority The Choices: Pri. Master, Pri. Slave, Sec. Master, Sec. Slave, USB CDROM0, USB CDROM 1. First/Second/Third Boot Device The BIOS will attempt to load the operating system in this order. The Choices: Removable, Hard Disk, CDROM, Legacy LAN, Disabled.
  • Page 70: Advanced Chipset Features

    GF7025-M2 4 Advanced Chipset Features This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus.
  • Page 71: Cpu Spread Spectrum

    GF7025-M2 K8<->NB HT Width The Choices: AUTO (default), ↓8↑8, ↓16↑16. CPU Spread Spectrum This item allows you to select the CPU Spread Spectrum function. The Choices: 0.50% H.Kiss Cntr, 0.50% H.Kiss Down, 0.75% H.Kiss Cntr, 0.75% H.Kiss Down, Disabled (default).
  • Page 72: Integrated Peripherals

    GF7025-M2 5 Integrated Peripherals Figure 5. Integrated Peripherals IDE Function Setup Highlight the “Press Enter” label next to the “IDE Function Setup” label and press enter key will take you a submenu with the following options:...
  • Page 73: Mcp Storage Config

    GF7025-M2 MCP Storage Config SATA Operation Mode This option allows you to choose SATA function. The Choices: IDE (default), RAID, AHCI, Linux AHCI. SATA Pri-/Sec- Master/Slave RAID This option allows you to enable or disable SATA Primary/Secondary RAID. The Choices: Disabled (default), Enabled.
  • Page 74: Ide Dma Transfer Access

    GF7025-M2 Primary Master/Slave UDMA Ultra DMA function can be implemented if it is supported by the IDE hard drives in your system. As well, your operating environment requires a DMA driver (Windows 95 or OSR2may need a third party IDE bus master driver). If your hard drive and your system software both support Ultra DMA, select Auto to enable BIOS support.
  • Page 75: Onboard Device

    GF7025-M2 Onboard Device Highlight the “Press Enter” label next to the “Onboard Device” label and press the enter key will take you a submenu with the following options: HD Audio This option allows you to control the onboard HD audio.
  • Page 76 GF7025-M2 Onboard SuperIO Device Press Enter to configure the Super I/O device. Onboard FDC Controller Select enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you installed another FDC or the system uses no floppy drive, select disabled in this field.
  • Page 77: Init Display First

    GF7025-M2 Parallel Port Mode This item allows you to determine how the parallel port should function. The default value is SPP. The Choices: SPP (default) Using Parallel port as Standard Printer Port. Using Parallel Port as Enhanced Parallel Port. Using Parallel port as Extended Capabilities Port.
  • Page 78 GF7025-M2 USB Keyboard/Storage Support This item allows you to enable or disable the USB Keyboard / storage Legacy Support. Enabled (default) Enable USB Keyboard / storage Support. Disabled Disable USB Keyboard/ storage Support. USB Mouse Support This item allows you to enable or disable the USB mouse Legacy Support.
  • Page 79: Power Management Setup

    GF7025-M2 6 Power Management Setup The Power Management Setup Menu allows you to configure your system to utilize energy conservation and power up/power down features. Figure 6. Power Management Setup ACPI Function This item displays the status of the Advanced Configuration and Power Management (ACPI).
  • Page 80: Video Off Method

    GF7025-M2 Power Management This category allows you to select the power saving method and is directly related to the following modes: 1. HDD Power Down. 2. Suspend Mode. There are three options of Power Management, three of which have fixed mode settings Min.
  • Page 81: Hdd Down In Suspend

    GF7025-M2 HDD Down In Suspend This option allows you to enabled or disabled the HDD power down function in suspend mode. The Choices: Disabled (default), Enabled Soft-Off by PBTN This item determines the behavior of system power button. Instant off turn off the power immediately, and Delay 4 Sec.
  • Page 82: Power On Function

    GF7025-M2 Date (of Month) Alarm You can choose which month the system will boot up. Time (hh:mm:ss) Alarm You can choose the system boot up time, input hour, minute and second to specify. Note: If you have change the setting, you must let the system boot up until it goes to the operating system, before this function will work.
  • Page 83: Pnp/Pci Configurations

    GF7025-M2 7 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components.
  • Page 84: Resources Controlled By

    GF7025-M2 The above settings will be shown on the screen only if “Manual” is chosen for the resources controlled by function. Legacy is the term, which signifies that a resource is assigned to the ISA Bus and provides non-PnP ISA add-on cards. PCI / ISA PnP signify that a resource is assigned to the PCI Bus or provides for ISA PnP add-on cards and peripherals.
  • Page 85: Pc Health Status

    GF7025-M2 8 PC Health Status Figure 8: PC Health Status Smart Fan Option...
  • Page 86: Shutdown Temperature

    GF7025-M2 CPU Smart Fan This item allows you to control the CPU Fan. The Choices: Disabled (default), Auto, 4-pin, 3-pin.. Smart Fan Calibration Choose this item and then the BIOS will auto test and detect the CPU fan functions and show CPU fan speed.
  • Page 87 GF7025-M2 CPU Vcore, Chipset Volt, +3.3V, +5.0V, +12.0V, DDR Voltage, HT Voltage, Voltage Battery Detect the system’s voltage status automatically. CPU Temp This field displays the current temperature of CPU. Current CPU FAN Speed This field displays the current speed of CPU fan.
  • Page 88: Performance Booster Zone

    GF7025-M2 9 Performance Booster Zone VCore Voltage This item allows you to adjust the CPU Vcore voltage. The Choices: Default (default), +3.3%, +6.6%, +10% Memory Voltage This item allows you to adjust the memory voltage. The Choices: Default (default), 2.000V, 2.045V, 2.100V CPU Frequency This item allows you to select the CPU Frequency.
  • Page 89: Dram Configuration

    GF7025-M2 DRAM Configuration Timing Mode This item allows you to choose to manually or automatically regulate the DDR Timing. The Choices: Auto (default), MaxMemClk. Memory Clock Value OR Limi The Choices: DDR 400 (default), DDR 533, DDR 667, DDR 800.
  • Page 90 GF7025-M2 Memory Hole Remapping The Choices: Enabled (default), Disabled. Auto Optimize Bottom IO The Choices: Enabled (default), Disabled. Bottom of [31:24] IO space The Choices: C0 (default); Min=0000, Max=00FF, key in a HEX number. Bottom of UMA DRAM [31:24] The Choices: FC (default); Min=0000, Max=00FC, key in a HEX number.
