Cpu Clock Ratio; Cpu Voltage; Fsb Termination Voltage - Biostar G965 Micro 775 Bios Setup Manual

G965 Micro 775

CPU Clock Ratio

This item allows you to select the CPU Ratio.
Min= 8 Max= 50, Key in a DEC number.
The Choices: 8X (default).
CPU Clock
This item allows you to select CPU Clock, and CPU over clocking.
Min= 100 Max= 333 Key in a DEC number.
The Choices: 100Mhz (default).
Special Notice:
If the system's frequency that you are selected is not functioning, there are two
methods of booting-up the system.
Method 1:
Clear the COMS data by setting the JCOMS1 ((2-3) closed)) as " ON" status. All
the CMOS data will be loaded as defaults setting.
Method 2:
Press the <Insert> key and Power button simultaneously, after that keep-on
pressing the <Insert> key until the power-on screen showed.
This action will boot-up the system according to FSB of the processor
It's strongly recommended to set CPU Vcore and clock in d efault setting. If the
CPU Vcore and clock are not in default setting, it may cause CPU or M/B
damage.
PCIE Clock Select
The Choices: Auto (default), Upto CPU, Fixed 100, Manual.
PCIE Clock
The Choices: 100MHz (default), Min=100; Max=200; key in DEC number.

CPU Voltage

This item allows you to select CPU Voltage Control.
The Choices: StartUp (default), +0.012V ~ +0.787V.

FSB Termination Voltage

This item allows you to select FSB termination Voltage.
The Choices: 1.2V (default), 1.3V, 1.4V, 1.5V.
37
