G965 Micro 775 Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
lim its are designed to provide reasonable protection against harm ful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harm ful
interference to radio communications. There is no guarantee that
interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves
the right to revise this publication and to make changes to the contents
here without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without
notice and we will not be responsible for any mistakes found in this
user's manual. All the brand and product names are trademarks of their
respective companies.

Advertisement

Table of Contents
loading

Summary of Contents for Biostar G965 MICRO 775

  • Page 1 All manuals and user guides at all-guides.com G965 Micro 775 Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These lim its are designed to provide reasonable protection against harm ful interference in a residential installation.
  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents Chapter 1: Introduction ..........1 Before You Start..............1 Package Checklist..............1 Motherboard Features............2 Rear Panel Connectors (for Ver 5.x)........4 Rear Panel Connectors (for Ver 6.x )........4 Motherboard Layout (for Ver 5.x )..........
  • Page 3: Chapter 1: Introduction

    All manuals and user guides at all-guides.com G965 Micro 775 CHAPTER 1: INTRODUCTION EFORE T ART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable work ing environment with sufficient lighting.
  • Page 4: Motherboard Features

    All manuals and user guides at all-guides.com Motherboard Manual OT HERBOARD EAT URES Ver 5.x Ver 6.x LGA 775 LGA 775 Intel Core2Duo / Core2Quad / Pentium D / Intel Core2Duo / Core2Quad / Pentium D / Pentium 4 / Celeron D processor up to 3.8 GHz Pentium 4 / Celeron D processor up to 3.8 GHz Supports Hyper-Threading / Execute Disable Bit Supports Hyper-Threading / Execute Disable Bit...
  • Page 5 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA OS Support Biostar Reserves the right to add or remove Biostar Reserves the right to add or remove support for any OS With or without notice. support for any OS With or without notice.
  • Page 6: Rear Panel Connectors (For Ver 5.X)

    All manuals and user guides at all-guides.com Motherboard Manual ANEL ONNECT ORS PS/2 LA N Mouse PS/2 USBX2 USB X2 COM1 Keybo ard Cente r Line In Re ar Line Out Side Mic In ANEL ONNECT ORS PS/2 Mouse Li ne In/ Surround Line Out Mic In 1/...
  • Page 7: Motherboard Layout (For Ver 5.X )

    All manuals and user guides at all-guides.com G965 Micro 775 OT HERBOARD AYOUT JKBM S1 JCF AN1 Super LGA775 CPU1 JPRNT1 JUSB1 JATXPWR1 Intel JRJ45USB1 G965 AUDIO1 PEX16_1 JATXPWR2 PCI1 JCMOS1 BIOS Intel ICH8 PCI2 JCI1 (Opti onal) Codec BAT1...
  • Page 8: Motherboard Layout (For Ver 6.X )

    All manuals and user guides at all-guides.com Motherboard Manual OT HERBOARD AYOUT JKBMS1 JCF AN 1 Super LGA775 C PU 1 JPRN T1 JUSB1 JATXPW R1 Intel JR J4 5USB1 G965 JAU DIO2 PEX16 _1 JATXPWR 2 PCI1 JCMOS1 BIOS Intel ICH8 PCI2...
  • Page 9: Chapter 2: Hardware Installation

    All manuals and user guides at all-guides.com G965 Micro 775 CHAPTER 2: HARDWARE INSTALLATION (CPU) NST ALLING ENT RAL ROCESSING Special Notice: Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged.
  • Page 10 All manuals and user guides at all-guides.com Motherboard Manual Step 2: Look for the triangular cut edge on socket, and the golden dot on CPU should point forwards this triangular cut edge. The CPU will fit only in the correct orientation. Step 2-1: Step 2-2: Step 3: Hold the CPU down firmly, and then lower the lever to locked...
  • Page 11: Fan Headers

    All manuals and user guides at all-guides.com G965 Micro 775 FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 12: Installing System Memory

    All manuals and user guides at all-guides.com Motherboard Manual NST ALLING YST EM EMORY A. DDR2 module Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot.
  • Page 13 All manuals and user guides at all-guides.com G965 Micro 775 B. Memory Capacity DIMM Socket DDR Module Total Memory Size Location DDR2_A1 256MB/512MB/1GB /2GB*1 DDR2_A2 256MB/512MB/1GB/2GB*1 Max is 8GB. DDR2_B1 256MB/512MB/1GB/2GB *1 DDR2_B2 256MB/512MB/1GB/2GB *1 C. Dual Channel Memory installation...
  • Page 14: Connectors And Slots

    All manuals and user guides at all-guides.com Motherboard Manual 2.4 C ONNECT ORS AND LOT S FDD1: Floppy Disk Connector The motherboard prov ides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk ty pes. This connector supports the prov ided f loppy drive ribbon cables.
  • Page 15 All manuals and user guides at all-guides.com G965 Micro 775 PEX16_1: PCI-Express x16 slots PCI-Express 1.0a compliant. Maximum theoretical realized bandwidth of 4GB/s simultaneously per direction, f or an aggregate of 8GB/s totally. PEX1_1: PCI-Express x1 slots PCI-Express 1.0a compliant.
  • Page 16: Chapter 3: Headers & Jumpers Setup

    All manuals and user guides at all-guides.com Motherboard Manual CHAPTER 3: HEADERS & JUMPERS SETUP OW T O ET UP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.
  • Page 17 All manuals and user guides at all-guides.com G965 Micro 775 JATXPWR1: ATX Power Source Connector By connecting this connector, it will provide +12V to CPU power circuit. Assignment +12V +12V Ground Ground JATXPWR2: ATX Power Source Connector This connector allows user to connect 24-pin power connector on the ATX power supply.
  • Page 18 All manuals and user guides at all-guides.com Motherboard Manual JUSB2/JUSB3/JUSB4: Headers for USB 2.0 Ports at Front Panel This motherboard prov ides 3 USB 2.0 headers, which allows user to connect additional USB cable on the PC front panel, and also can be connected with internal USB dev ices, like USB card reader.
  • Page 19 All manuals and user guides at all-guides.com G965 Micro 775 JCMO S1: Clear CMOS Header By placing the jumper on pin2-3, it allows user to restore the BIOS saf e setting and the CMOS data, please carefully f ollow the procedures to avoid damaging the motherboard.
  • Page 20 All manuals and user guides at all-guides.com Motherboard Manual JSPDIF_O UT: Digital Audio out Connectors This connector allows user to connect the PCI bracket SPDIF output header. Assignment SPDIF_OUT Ground JSPDIF_IN: Digital Audio in Connectors (optional) This connector allows user to connect the PCI bracket SPDIF input header. Assignment SPDIF_IN Ground...
  • Page 21 All manuals and user guides at all-guides.com G965 Micro 775 JPRNT1: Printer Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground...
  • Page 22: Chapter 4: Useful Help

    All manuals and user guides at all-guides.com Motherboard Manual CHAPTER 4: USEFUL HELP RIVER NST ALLAT ION OT E After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance.
  • Page 23: Award Bios Beep Code

    BIOS contents are corrupted. In this Case, please follow the procedure below to restore the BIOS: 1. Make a bootable floppy disk. 2. Download the Flash Utility “AWDFLASH.exe” from the Biostar website: www.biostar.com.tw 3. Confirm motherboard model and download the respectively BIOS from Biostar website.
  • Page 24 All manuals and user guides at all-guides.com Motherboard Manual B. CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.
  • Page 25: Troubleshooting

    All manuals and user guides at all-guides.com G965 Micro 775 4.4 T ROUBLESHOOT ING Probable Solution No power to the system at all Make sure power cable is Power light don’t illuminate, f an securely plugged in. inside power supply does not turn Replace cable.
  • Page 26: Chapter 5: Warpspeeder

    All manuals and user guides at all-guides.com Motherboard Manual WARPSPEEDER™ CHAPTER 5: NT RODUCT ION [WarpSpeeder™], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click.
  • Page 27: Installation

    All manuals and user guides at all-guides.com G965 Micro 775 NST ALLAT ION 1. Execute the setup execution file, and then the following dialog will pop up. Please click “Next” button and follow the default procedure to install. 2. When you see the following dialog in setup procedure, it means setup is completed.
  • Page 28: Warpspeeder

    All manuals and user guides at all-guides.com Motherboard Manual 5.4 W ™ PEEDER 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar. This utility is responsible for conveniently invoking [WarpSpeeder™] Utility.
  • Page 29 All manuals and user guides at all-guides.com G965 Micro 775 2. Main Panel If you click the tray icon, [WarpSpeeder™] utility will be invoked. Please refer to the following figure; the utility’s first window you will see is Main Panel.
  • Page 30 All manuals and user guides at all-guides.com Motherboard Manual 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not.
  • Page 31 All manuals and user guides at all-guides.com G965 Micro 775 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure. O verclock Panel contains the these features: a.
  • Page 32 All manuals and user guides at all-guides.com Motherboard Manual “Auto-overclock button”: User can click this button and [WarpSpeeder™] will set the best and stable performance and frequency automatically. [WarpSpeeder™] utility will execute a series of testing until system fail. Then system will do fail-safe reboot by using Watchdog function.
  • Page 33 All manuals and user guides at all-guides.com G965 Micro 775 6. About Panel Click the “about” button in Main Panel, the button will be highlighted and the About Panel will slide out to up as the following figure. In this panel, you can get model name and detail information in hints of all the chipset that are related to overclocking.
  • Page 34: Appendencies: Spec In Other Language

    All manuals and user guides at all-guides.com Motherboard Manual APPENDENCIES: SPEC IN OTHER LANGUAGE ERMAN Ver 5.x Ver 6.x LGA 775 LGA 775 Intel Core2Duo / Core2Quad / Pentium 4 / Intel Core2Duo / Core2Quad / Pentium 4 / Pentium D / Celeron D Prozessoren mit bis zu Pentium D / Celeron D Prozessoren mit bis zu 3,8 GHz 3,8 GHz...
  • Page 35 243 mm (B) X 243 mm (L) 243 mm (B) X 243 mm (L) Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Biostar behält sich das Recht vor, ohne Biostar behält sich das Recht vor, ohne OS-Unterstüt Ankündigung die Unterstützung für ein Ankündigung die Unterstützung für ein...
  • Page 36: France

    All manuals and user guides at all-guides.com Motherboard Manual RANCE Ver 5.x Ver 6.x LGA 775 LGA 775 Processeurs Intel Core2Duo / Core2Quad / Processeurs Intel Core2Duo / Core2Quad / Pentium 4 / Pentium D / Celeron D jusqu'à 3,8 Pentium 4 / Pentium D / Celeron D jusqu'à...
  • Page 37 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Support SE Biostar se réserve le droit d'ajouter ou de Biostar se réserve le droit d'ajouter ou de supprimer le support de SE avec ou sans préavis. supprimer le support de SE avec ou sans préavis.
  • Page 38: Italian

    All manuals and user guides at all-guides.com Motherboard Manual T ALIAN Ver 5.x Ver 6.x LGA 775 LGA 775 Processore Intel Core 2Duo / Core 2Quad / Processore Intel Core 2Duo / Core 2Quad / Pentium 4 / Pentium D / Celero n D fi no a 3.8 Pentium 4 / Pentium D / Celero n D fi no a 3.8 Supporto di Hyper -Threadi ng / Execute Supporto di Hyper -Threadi ng / Execute...
  • Page 39 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Sistemi Biostar si riserva il diritto di aggiungere o Biostar si riserva il diritto di aggiungere o operativi rimuovere il supporto di qualsiasi sistema rimuovere il supporto di qualsiasi sistema supportati operativo se nza pre avviso.
  • Page 40: Spanish

    All manuals and user guides at all-guides.com Motherboard Manual PANISH Ver 5.x Ver 6.x LGA 775 LGA 775 Procesador Intel Core2Duo / Core2Quad / Procesador Intel Core2Duo / Core2Quad / Pentium 4 / Pentium D / Celeron D hasta 3,8 GHz Pentium 4 / Pentium D / Celeron D hasta 3,8 GHz Admite Hyper-Threading / Bit de deshabilitación Admite Hyper-Threading / Bit de deshabilitación...
  • Page 41 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA sistema Biostar se reserva el derecho de añadir o retirar Biostar se reserva el derecho de añadir o retirar operativo el soporte de cualquier SO con o sin aviso previo.
  • Page 42: Portuguese

    All manuals and user guides at all-guides.com Motherboard Manual ORT UGUESE Ver 5.x Ver 6.x LGA 775 LGA 775 Processador Intel Core2Duo / Core2Quad / Processador Intel Core2Duo / Core2Quad / Pentium 4 / Pentium D / Celeron D até 3,8 GHz Pentium 4 / Pentium D / Celeron D até...
  • Page 43 Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Sistemas A Biostar reserva-se o direito de adicionar ou A Biostar reserva-se o direito de adicionar ou operativos remover suporte para qualquer sistema remover suporte para qualquer sistema suportados operativo com ou sem aviso prévio.
  • Page 44: Polish

    All manuals and user guides at all-guides.com Motherboard Manual OLISH Ver 5.x Ver 6.x LGA 775 LGA 775 Procesor Intel Core2Duo / Core2Quad / Procesor Intel Core2Duo / Core2Quad / Pentium 4 / Pentium D / Celeron D do 3,8 GHz Pentium 4 / Pentium D / Celeron D do 3,8 GHz Procesor Obsługa Hyper-Threading / Execute Disable Bit /...
  • Page 45 243 mm (S) X 243 mm (W) płyty Obsluga Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA systemu Biostar zastrzega sobie prawo dodawania lub Biostar zastrzega sobie prawo dodawania lub operacyjne odwoływania obsługi dowolnego systemu odwoływania obsługi dowolnego systemu operacyjnego bez powiadomienia.
  • Page 46: Russian

    All manuals and user guides at all-guides.com Motherboard Manual USSIAN Ver 5.x Ver 6.x LGA 775 LGA 775 Процессор Intel Core2Duo / Core2Quad / Процессор Intel Core2Duo / Core2Quad / Pentium 4 / Pentium D / Celeron D до 3.8 ГГц Pentium 4 / Pentium D / Celeron D до...
  • Page 47 панели Windows 2000 / XP / VISTA Windows 2000 / XP / VISTA Поддержка Biostar сохраняет за собой право добавлять Biostar сохраняет за собой право добавлять или удалять средства обеспечения для OS с или удалять средства обеспечения для OS с...
  • Page 48: Arabic

    All manuals and user guides at all-guides.com Motherboard Manual RABIC Ver 6.x Ver 5.x LGA 775 LGA 775 ‫ﻡﻌ ﺎ ﻟﺠﺎت‬Intel Core2Duo / Core2Quad / Pentium 4 ‫ﻡﻌ ﺎ ﻟﺠﺎت‬Intel Core2Duo / Core2Quad / Pentium 4 / Pentium D / Celeron D / Pentium D / Celeron D ‫ﺝﻴﺠﺎ...
  • Page 49 All manuals and user guides at all-guides.com G965 Micro 775 Ver 6.x Ver 5.x Realtek RTL 8110SC Realtek RTL 8110SC ‫1 و‬ ‫1 و‬ ‫دا ﺥ ﻠﻴﺔ‬ ‫ﺵﺒﻜﺔ‬ ‫ﺙﺎﻥﻴﺔ‬ ‫ﺑﺖ‬ ‫ﺝﻴﺠﺎ‬ ‫ﺙﺎﻥﻴﺔ‬ ‫ﺑﺎﻳﺖ‬ ‫ﻡﻴﺠﺎ‬ ‫ﺕﻠﻘﺎﺋﻲ‬ ‫ﺕﻔﺎوض‬ ‫ﺙﺎﻥﻴﺔ‬ ‫ﺑﺖ‬ ‫ﺝﻴﺠﺎ‬ ‫ﺙﺎﻥﻴﺔ‬...
  • Page 50: Japanese

    All manuals and user guides at all-guides.com Motherboard Manual APANESE Ver 5.x Ver 6.x LGA 775 LGA 775 Intel Core2Duo / Core2Quad / Pentium 4 / Intel Core2Duo / Core2Quad / Pentium 4 / Pentium D / Celeron D processor up to 3.8 GHz Pentium D / Celeron D processor up to 3.8 GHz Hyper-Threading / Execute Disable Bit / Hyper-Threading / Execute Disable Bit /...
  • Page 51 All manuals and user guides at all-guides.com G965 Micro 775 Ver 5.x Ver 6.x Realtek RTL 8110SC Realtek RTL 8110SC 10 / 100 Mb/秒および1Gb/秒のオートネゴシエーシ 10 / 100 Mb/秒および1Gb/秒のオートネゴシエーシ ョン ョン 半/全二重機能 半/全二重機能 ALC888 ALC861VD サウンド ハイデフィニションオーディオのサポート ハイデフィニションオーディオのサポート Codec 7.1 チャンネルオーディオアウト...
