Billion BiPAC 7300GX Specifications

Compatible 3G USB Modems *
4
Brand Model
Onda MT503HS 7.2MEGA
Novatel MC950D
Sierra Wireless AirCard 875U
Sierra Wireless AirCard 880U
Huawei E220
Option iCON 225
Compatible 3G Data Cards *
2
3G Operator Product name Manufacturer & Model name
T-Mobile web`n`walk card compact Option GlobeTrotter GT Max E
T-Mobile web`n`walk card compact II Option GX0201
T-Mobile web`n`walk card wlan Option GT Fusion+EMEA
T-Mobile Mobile DSL 1800 Option GlobeTrotter HSDPA
Huawei E630
Vodafone/ Huawei E620
Mobile Connect
Vodacom Option GT 3G+EMEA
Novatel Merlin U740
Novatel Merlin XU870
N/A N/A
(EXPRESS to PCMCIA converter required)
Option GlobeTrotter EXPRESS 7.2 GE0201
N/A N/A
(EXPRESS to PCMCIA converter required)
N/A N/A ONDA N501HS
Bandrich C100
N/A N/A
(EXPRESS to PCMCIA converter required)
Sierra Wireless Aircard 880E
Telstra Telstra Turbo 7 series Express Card (AC880E)
(EXPRESS to PCMCIA converter required)
N/A N/A HuaWei E600
N/A N/A Sierra Wireless Aircard 875
N/A N/A Sierra Wireless Aircard 880
Huawei E870
N/A N/A
(EXPRESS to PCMCIA converter required)
Novatel Merlin X950D
N/A N/A
(EXPRESS to PCMCIA converter required)
N/A N/A Globtrotter GT MAX 7.2 card
N/A N/A Option GlobeTrotter GT Max HSUPA
Above list will be continuously updated at http://www.billion.com/compatible-3G.html.
Benefits
Communication Flexibility via 3G/HSDPA
The BiPAC 7300GX router allows you to insert a 3G/HSDPA PC card to its built-in PC Card slot, enabling you to use a
3G/HSDPA, UMTS, EDGE, GPRS, or GSM Internet connection, makes downstream rates of to 14.4Mbps*
increasing popularity of the 3G standard, communication via the BiPAC 7300GX is becoming more convenient and widely
available - allowing you to watch movies, download music on the road, or access e-mail no matter where you are. You can even
share your Internet connection with others, no matter if you're in a meeting, or speeding across the country on a train.
Always Online
The BiPAC 7300GX is compliant with worldwide ADSL standards, and supports download rates of up to 12/24Mbps using
ADSL2/2+, 8Mbps using ADSL and an upload rate of up to 1Mbps. Using this technology you'll be able to enjoy high-speed
ADSL and broadband multimedia applications such as interactive gaming, video streaming and real-time audio. The integrated
Annex M standard supports ADSL2/2+ for higher upload speeds by doubling the upload data rate. Planned support for auto fail-
over means that you'll be assured of a constant Internet connection - in case your ADSL line fails, the BiPAC 7300GX will
connect via 3G to deliver uninterrupted connectivity.
Double-layer Protection
An integrated 802.11g Wireless Access Point offers quick yet easy access with data encryption for added security. Wireless
Protected Access (WPA-PSK/WPA2-PSK) and Wireless Encryption Protocol (WEP) support ensures high-level data protection
and WLAN access control. In addition, rich firewall security features such as SPI, DoS attack prevention and URL content
filtering are integrated to provide unparalleled protection for Internet access. Enjoy the benefits of added security by simply
pressing the Wi-Fi Protected Setup button to quickly and easily set up secure wireless communication.
Features & Specifications
ADSL Compliance
• Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.lite (ITU G.992.2)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
• Compliant with ADSL2 Standard
- G.dmt.bis (ITU G.992.3)
- ADSL2 Annex M (ITU G.992.3 Annex M)
(Available on BiPAC 7300GXA only)
• Compliant with ADSL2+ Standard
- G.dmt.bisplus (ITU G.992.5)
- ADSL2+ Annex M (ITU G.992.5 Annex M)
(Available on BiPAC 7300GXA only)
Network Protocols and Features
• NAT, static routing and RIP-1/2
• NAT supports PAT and multimedia applications
• Transparent Bridging
• Dynamic Domain Name System (DDNS)
• SNTP
• DDNS relay
• Virtual Server and DMZ
• Virtual LAN (VLAN)
Firewall & Virtual Private Network (VPN)
• Built-in NAT Firewall
• Stateful Packet Inspection (SPI)
• Prevents DoS attacks including IP spoofing, land attack, Smurf attack,
ping-of-death, etc.
• Remote access control for web base access
• Packet Filtering
• URL Content Filtering
• Password protection for system management
• VPN pass-through
W ireless 802.11g
• Compliant with IEEE 802.11g and 802.11b standards
• 2.4GHz - 2.484GHz frequency range
• Up to 54Mbps wireless operation rate
• 64-/128-bit WEP supported for encryption
• Auto channel select
• Wireless Security with WPA-PSK/WPA2-PSK support
• Wireless Distribution System (WDS) repeater function supported
• Wi-Fi Protected Setup
Operating Environment
• Operating temperature: 0 - 40°C
• Storage temperature: -20 - 70°C
2
possible. With the • Humidity: 20 - 95% non-condensing
*
Notes:
1. The router may require firmware modification for certain ADSL2/2+/ Annex M DSLAMs.
2. The 3G/HSDPA data rate is dependent on your local service provider and your 3G/HSDPA card and USB modem.
3. Specifications in this datasheet are subject to change without prior notice.
4. Compatible with 3G USB Modems (USB to PCMCIA converter required)
Billion Electric Co., Ltd.
8F , No.192, Sec.2, Chung Hsing Road,
Hsin Tien City, Taipei County, Taiwan
Copyright © Billion Electric Co., Ltd. All rights reserved.
ATM and PPP Protocols
• ATM Adaptation Layer Type 5 (AAL5)
• Multiple protocols over AAL5 (RFC 2684, formerly RFC 1483)
• Bridged or routed Ethernet encapsulation
• VC and LLC based multiplexing
• PPP over Ethernet (PPPoE)
• PPP over ATM (RFC 2364)
• OAM F4/F5
Management
• Quick Installation Wizard and Auto ADSL settings
• Web-based GUI for remote and local management
• Firmware upgrade and configuration data upload and download via
web-based GUI
• Embedded Telnet server for remote and local management
• Available Syslog monitoring
• Supports DHCP server/client/relay
• Mail Alert
Quality of Service Control
• Supports DiffServ approach
• Traffic prioritization and bandwidth management based-on IP protocol,
port number and address
Hardware Specifications
Physical Interface
• DSL: ADSL Port
• Ethernet: 4-port 10/100Mbps auto MDI/MDI-X Switch
• WLAN: one 2 dBi detachable antenna
• 3G/HSDPA PC Card Slot: for a mobile broadband data card
• Compatible with 3G USB Modems (USB to PCMCIA converter required)
• WPS button: for WPS Push Button Configuration
• Factory default reset button
• Power jack
• Power switch
Physical Specifications
• Dimensions: 8.27" x 5.83" x 1.42"
(210mm x 148mm x 36mm)
Power Requirements
• Input:12V DC, 1A
• Car power cable
Models & Standards Supported
• BiPAC 7300GXA: Annex A and Annex M
• BiPAC 7300GXU: U-R2 and Annex B
• Annex A and Annex M: ADSL over POTS
• Annex B and Annex U-R2: ADSL over ISDN
V.073108
TEL : +886-2-2914-5665
www.billion.com
FAX : +866-2-2918-6731,+886-2-2918-2895
E-mail : sales@billion.com
Connect anywhere, anytime!
Mobile - Secure - Always online
- 3G/ADSL for true always-on connectivity
BiPAC 7300GX - Mobility assured by 3G support
- Automatically switch between ADSL and
3G as needed
3G/ADSL2+ Wireless Router
- Car power cable for ultimate portability
