4.1 Copper Ethernet Ports
1
Figure 4.2
4.1
Copper Ethernet Ports
The RUGGEDCOM M2100 supports several 10/100Base-TX and 10/100/1000Base-
TX Ethernet ports that allow connection to standard Category 5 (CAT-5) unshielded
twisted-pair (UTP) cables with Micro-D male connectors. The Micro-D connectors
are directly connected to the chassis ground on the device and can accept CAT-5
shielded twisted-pair (STP) cables.
Pin-Out
The following is the pin-out description for the Micro-D connectors:
Figure 4.3
Specifications
For specifications on the available copper Ethernet ports, refer to
Port Specifications (Page
24
Port LED
Port LEDs
1
6
Micro-D 10/100/1000Base-TX Port Pin Configuration
Pin
1
2
Reserved (Do Not Connect)
3
4
Reserved (Do Not Connect)
5
6
7
Reserved (Do Not Connect)
8
Reserved (Do Not Connect)
9
28)".
10/100Base-TX
RX+
Reserved (Do Not Connect)
TX+
RX-
TX-
1000Base-TX
A+
C+
D+
B+
A-
C-
D-
B-
"Copper Ethernet
RUGGEDCOM M2100
Installation Manual, 04/2021, C79000-G8976-1042-17
