Installing the Device
2.1 General Procedure
of a tool, lock and key, or other means of security, and controlled by the authority
responsible for the location.
Note
For Canadian Standards Association (CSA) certification in non-hazardous
environments
•
•
•
•
•
•
•
•
•
•
•
•
2.1

General Procedure

The general procedure for installing the device is as follows:
IMPORTANT
The user is responsible for the operating environment of the device, including
maintaining the integrity of all protective conductor connections and checking
equipment ratings. Make sure to review all operating and installation instructions
before commissioning or performing maintenance on the device.
1.
2.
3.
4.
5.
8
Installation must be approved by the CSA or other regulator with jurisdictional
authority
The device must be permanently connected, reliably Earthed, and protected with
an appropriate power disconnect device as part of the building installation
Any DC power source must be from a certified power source
An approved disconnect device and overcurrent protection must be provided for
any DC power source
Only use properly rated and certified AC/DC power cables
Product must only be used in a restricted-access indoor location
Ambient temperature must not exceed 85° C (185° F)
A minimum forced airflow of 0.27 m/s at 400 CFM is required
A minimum of 2.5 cm (1 in) of space is required between units
A pollution degree of 2 is required
The failsafe relay connection must be from a certified Safey Extra-Low Voltage
(SELV) source isolated from the mains supply
Rack-mount installations must be performed by trained, certified personnel in
accordance to the installation instructions and local electrical code.
Review the relevant certification information for any regulatory requirements.
For more information, refer to
Mount the device.
Connect the failsafe alarm relay.
Connect power to the device and ground the device to safety Earth.
Connect the device to the network.
"Approvals (Page 35)".
