- Page 1 Core Health & Fitness Star Trac 8-CT ASSEMBLY MANUAL...
-
Page 2: Product Spotlight
PRODUCT SPOTLIGHT 9-6140 8-CT Cross Trainer Overall Weight Width Length Height Max User Weight 420 lbs (190 kg) 29 in (73.6 cm) 79 in (200.6 cm) 50 in (127 cm) 0-350 lbs (0-159 kg) All products may be covered by US and Foreign Patents and Patents Pending. Page 1... - Page 3 Description 740-7919-XX ASSY, HANDLEBAR, LEFT, E-CT 740-7920-XX ASSY, HANDLEBAR, RIGHT, E-CT 740-4589 Screw, M8x1.25, 20mm, HHC, SS 740-4591 Washer, Lock, EXT, M8, Ø8.4xØ15x0.8mm, SS 740-7855 ASSY, HANDLEBAR, RIGHT, E-CT 740-7856 ASSY, HANDLEBAR, RIGHT, E-CT 740-7855 COVER, UPPER BODY JOINT, FRONT, LEFT, E-CT 740-7856 COVER, UPPER BODY JOINT, BACK LEFT, E-CT 740-7853...
- Page 4 Use a 13mm socket to secure the left side upper handrail (740-79119-XX) to the lower left handrail using four (4) pieces each of the M8 x 20mm hex head cap screw (740-4589) and M8 toothed lock washer (740-7856). Repeat Step 1 for the right side upper handrail (740-7920-XX).
- Page 5 Use a 4mm allen key to lock the mast assembly to the frame using one (1) piece of the M8 x 40mm set screw (740-4593). Use a #2 phillips screwdriver to secure the back console shroud to the console weldment using eight (8) pieces of the #8-18 x 3/4”...
-
Page 6: Support And Service
SUPPORT AND SERVICE The Support website provides a wealth of resources to help you get the best experience from your unit. It is important to check the website periodically for Owner’s Manual and Installation Instruc- tions, Service Bulletins, and other information. The resources include: •... - Page 7 © 2019 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8384, REV B...
