Falltech SRL-LE User Instruction Manual page 12

Chart 2: Additional Fall Clearance Due to Swing Fall (meters) with Leading Edge Conditions
for 1.5 m (5 ft) Setback from Leading Edge with Foot Level Anchorage
15.2 0 0
13.7 0 0
12.2 0 0
10.7 0 0
9.1 0 0
7.6 0 0
6.1 0 0
4.6 0 0
3.0 0 0
1.5 0 0
Dorsal
0 0
D-Ring
-1.5 0 0
0 0.6
X-Axis: Lateral Work Zone (m)
Using Chart 2 to Find Additional Fall Clearance: Leading Edge Conditions
0.6 m (2 ft) increments along the X-Axis represent the
distance the user is working away from the SRD
At no time shall the expanded Work Zone exceed 4.9 m (16 ft), (2.4 m (8 ft) on each side of center)
To find the additional Fall Clearance needed to compensate for potential Swing Fall, note the starting location on
Chart 2 titled Dorsal D-Ring
Example:
The starting point shown is where the SRD is anchored at Foot Level (1.5 m (5 ft) below the Dorsal D-Ring) and has
1.5m (5 ft) of setback distance from the Leading Edge. From here, the user may expand the lateral work zone up to
2.4 m (8 ft) along the X-Axis and still remain inside the allowable and cautionary areas. The expanded work zone
indicates that 1.2 m (4 ft) of additional fall clearance should be added to the Sub-Total calculation in Figure 6.
Should the user need to expand the work zone to 3.7 m (12 ft), the SRD must be anchored 4.6 m (15 ft) above the
Dorsal D-Ring to remain in the allowed and cautionary areas. This change also indicates 1.2 m (4 ft) of additional fall
clearance to be added to Figure 6.
If the user cannot anchor the SRD above the Dorsal D-Ring but still must expand the work zone, the SRD will need to
be anchored with more than 1.5 m (5 ft) of setback distance from the leading edge.
Key to Work Zone Areas:
CMSRD08 Rev A
0 0 0.3 0.3 0.3
0 0 0.3 0.3 0.6
0 0 0.3 0.3 0.6
0 0.3 0.3 0.6 0.6
0 0.3 0.3 0.6 0.6
0 0.3 0.3 0.6 0.9
0 0.3 0.6 0.6 0.9
0.3 0.3 0.6 0.9 1.2
0.3 0.6 0.9 1.2 1.5
0.3 0.6 1.2 1.5 2.1
0.3 0.9 1.2 1.8 2.4
0.3 0.9 1.2 1.8 2.4
1.2 1.8 2.4 3.0 3.7
anchorage
Allowable Use Area
0.6 0.6 0.9 1.2 1.5
0.6 0.9 0.9 1.2 1.5
0.6 0.9 1.2 1.5 1.8
0.9 0.9 1.2 1.5 1.8
0.9 1.2 1.5 1.8 2.1
1.2 1.5 1.8 2.1 2.4
1.2 1.5 2.1 2.4 3.0
1.5 2.1 2.4 3.0 3.4
2.1 2.4 3.0 3.7 4.0
2.7 3.0 3.7 4.3 4.9
3.0 3.7 4.3 4.9 5.4
3.0 3.7 4.3 4.9 5.4
4.3 4.9 5.5 6.1 6.7
1.5 m (5 ft) increments up the Y-Axis represent the SRD
Anchorage height above or below the user's Dorsal
Cautionary Use Area
022420
1.5 1.8 2.1 2.4 2.7
1.8 2.1 2.4 2.7 3.0
2.1 2.4 2.7 3.0 3.4
2.1 2.7 3.0 3.4 3.7
2.4 3.0 3.4 3.7 4.3
3.0 3.4 3.7 4.3 4.6
3.4 4.0 4.3 4.9 5.2
4.0 4.6 4.9 5.5 6.1
4.6 5.2 5.8 6.4 7.0
5.5 6.4 6.7 7.3 7.9
6.1 6.4 7.0 7.6 8.2
6.1 6.4 7.0 7.6 8.2
7.3 8.0 8.5 9.1 9.8
D-Ring
Not Allowed Use Area
3.0 3.7
3.4 4.0
3.7 4.3
4.3 4.9
4.9 5.2
5.2 5.8
5.8 6.4
6.7 7.3
7.6 8.2
8.5 9.1
8.8 9.4
8.8 9.4
10.4 11.0
12
