Ground Balance (Ground, Tracking, Autoset); Master Volume, Backlight And Bluetooth (Volume, Backlight, Bluetooth, Pair) - C-SCOPE EVO6000 User Manual

The EVO6000 has three audio ranges, each has a tone, or range of tones, and a separate volume
level. The volume of all the tones is controlled by the
volume (VOLUME) to zero will mute all tones. A deep, small target generates a quieter tone than a
shallow, large target. The
from one to up to twelve, giving up to 36 tones in total.

Ground Balance (GROUND, TRACKING, AUTOSET)

The ground balance is the level the detector uses to ignore signals which are generated by
movement of the search head relative to the ground or changes in soil conditions. The level can be
set to track the correct ground level continuously (TRACKING), or to a level you choose. The
EVO6000 can suggest a level for you to choose (AUTOSET) or you can set a value manually
(MANUAL).
GROUND
TRACKING
AUTOSET
The simplest way to set the ground level is to use TRACKING. When you chose this option the
GTRACK indicator under the small digits on the left of the screen will light up, the EVO6000 will
continuously adjust the ground level, and the small digits will show the ground level being used.
To set the ground level manually choose GROUND put the search head on the soil or sand and then
repeatedly raise it and bring it back down. Use the up and down buttons
ground level. When the detector is silent and ignores the ground signal press the OK button
To use a ground level automatically calculated by the EVO6000 choose AUTOSET put the search
head on the soil or sand and then repeatedly raise it and bring it back down. The EVO6000 will
calculate a ground level and display it on the screen. You can alter the level using the up and down
buttons . When the detector is silent and ignores the ground signal press the OK button
When you use GROUND or AUTOSET and the ground conditions change, the EVO6000 will tell you by
flashing a HI or LO message on the small digits on the left hand side of the screen. You can correct
the ground level by repeating the GROUND or AUTOSET process.
Master Volume, Backlight and Bluetooth (VOLUME, BACKLIGHT,
BLUETOOTH, PAIR)
The master volume, which affects all tones, is controlled by the VOLUME setting.
VOLUME
BACKLIGHT
BLUETOOTH
PAIR
Extras menu can be used to increase the number of tones in each range
Set the ground level manually.
Track the correct ground level continuously.
Your EVO6000 will calculate a level for you.
Menu 3
The master volume level. Set to zero to mute all sound.
Set the brightness of the backlight.
Turn on aptX™ Low Latency Bluetooth to connect your
Forget the current wireless headphones
headphones to PAIR to.
19 / 32
master volume (VOLUME). Setting the master
headphones.
and search for a new set of
to change the
.
.
wireless
