MEG10-01 10kV
Insulation tester
Line Input
(under cover)
Test Voltage
increase/
decrease
Polarisation Index
Insulation Resistance
Voltage
Indicator
Voltage at
Terminals
Quick Start
Measurement Terminals
-ve, Guard, +ve
LED
Power
Red - HT On
On/Off
Green - Charging Battery
Polarisation Index
Insulation Resistance
Digital Display
RS232 port
(under cover)
Test Duration
increase/
decrease
Display
Scroll
Test
Start/Stop
Recording
Timer ON
Time
Indicator
Analogue
Display
Voltage at
Terminals
