Javad TRE Application Notes page 9

DE-9 Female,
Cable Wiring
side 1
Signal Pair Number: Wire
Pin
Name Number
CAN_H 7 Pair 1: Wire 2
8
9
Shield shell Shield + Drain Wire
When two OEM receivers connected directly through
CAN cable, their CAN ports should be terminated by
120 Ohm resistors on both ends. This may be achieved
by jumpers at J126 for CAN A and J127 for CAN B ports
on Evaluation Kit board.
Additionally, CAN ports messages identifiers should be
configured in both OEM receivers, so each receiver will
accept messages transmitted only by its partner.
Example: Two receivers connected together through
their CAN A ports.
Receiver 1 settings:
%%set,dev/can/a/sid/in/first,0x710
%%set,dev/can/a/sid/out/first,0x700
Receiver 2 settings:
%%set,dev/can/a/sid/in/first,0x700
%%set,dev/can/a/sid/out/first,0x710
www.javad.com
DE-9 Female, side 2
Pin Signal Name
7 CAN_H
8
9
shell Shield
9
