BP7502 LK70, 80, 90, 140 LED
READ AND SAVE THESE INSTRUCTIONS
Ceiling Fan LED Light Fixture
LK70LED
LK71LED
LK72LED
LK74LED
LK77LED
2.6
Net Weight:
Emerson Electric Customer Service - 8 a.m. - 6 p.m., Eastern, Monday-Friday
Part No. F40BP75020000
Revision: 151015
10/13/15
3:02 AM
Owner's Manual
Model Numbers
LK80LED
LK81LED
LK83LED
Net Weight:
Lbs.
Questions, problems, missing parts: Before returning to the store call
1-800-654-3545
www.emersonfans.com
Page 1
2.9
Lbs.
LK140LED
LK141LED
ETL Model No.: LK70LED/LK71LED/LK72LED/LK74LED/LK77LED/
LK80LED/LK81LED/LK83LED/LK90LED/LK91LED/LK140LED/LK141LED
LK90LED
LK91LED
2.6
Net Weight:
Lbs.
3.5
Net Weight:
Lbs.
Form No. BP7502
Advertisement
Related Manuals for Emerson LK70LED
Summary of Contents for Emerson LK70LED
- Page 1 Net Weight: Lbs. Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service - 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 www.emersonfans.com Form No. BP7502 Part No. F40BP75020000 ETL Model No.: LK70LED/LK71LED/LK72LED/LK74LED/LK77LED/...
-
Page 2: Table Of Contents
CF742 in damp locations with the WLP100 wet location painting, or working near the fan. Before installing or plate. Permissible to use this light kit on all Emerson CF servicing the light fixture or ceiling fan, switch power model ceiling fans installed in indoor locations. -
Page 3: Unpacking Instructions
Emerson Electric Co. Substitution of parts or Couplers/Wood Pendants 2 each accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. WARNING Before assembling your light fixture, refer to section on proper method of wiring your light fixture. -
Page 4: Electrical Requirements
National and Local codes and the ceiling fan must be properly grounded as a precaution against possible electrical shock. 3. Installation on Emerson Fans Having a Modular Switch Cup with Center Screw WARNING Disconnect electrical power to the branch circuit at the circuit breaker or fuse box before attempting to install Turning off wall switch is not sufficient. - Page 5 BP7502 LK70, 80, 90, 140 LED 10/13/15 3:02 AM Page 5 3. Installation on Emerson Fans Having a Modular Switch Cup with Center Screw (Continued) REMOVE WIRE CONNECTORS (2) Carefully locate the white and blue wires (labeled either "L" or "LIGHT") in the switch cup and remove the wire connectors from the wires (Figure 2).
- Page 6 BP7502 LK70, 80, 90, 140 LED 10/13/15 3:02 AM Page 6 3. Installation on Emerson Fans Having a Modular Switch Cup with Center Screw (Continued) LED LIGHT FIXTURE LED LIGHT FIXTURE ASSEMBLY WHITE ASSEMBLY BLACK Connect the white wire from the switch cup to the white...
- Page 7 BP7502 LK70, 80, 90, 140 LED 10/13/15 3:02 AM Page 7 3. Installation on Emerson Fans Having a Modular Switch Cup with Center Screw (Continued) 3.10 GLASS BOWL Insert the LED light fixture assembly chain and the fan speed control switch chain through the hole in the glass bowl (Figure 9).
-
Page 8: Installation On Emerson Fans Having A Two-Piece Die-Cast Switch Housing
BP7502 LK70, 80, 90, 140 LED 10/13/15 3:02 AM Page 8 4. Installation on Emerson Fans Having a Two-Piece Die-Cast Switch Housing WARNING Disconnect electrical power to the branch circuit at the circuit breaker or fuse box before attempting to install Turning off wall switch is not sufficient. - Page 9 BP7502 LK70, 80, 90, 140 LED 10/13/15 3:02 AM Page 9 4. Installation on Emerson Fans Having a Two-Piece Die-Cast Switch Housing (Continued) SWITCH Connect the white wire from the switch cup to the white HOUSING wire of the LED light fixture assembly using the...
- Page 10 BP7502 LK70, 80, 90, 140 LED 10/13/15 3:02 AM Page 10 4. Installation on Emerson Fans Having a Two-Piece Die-Cast Switch Housing (Continued) GLASS BOWL Insert the LED light fixture assembly chain and the fan speed control switch chain through the hole in the glass bowl (Figure 19).
-
Page 11: Limited Warranty
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Light Fixture should be properly packed to avoid damage in transit since we will not be responsible for any such damage. - Page 12 10/13/15 3:02 AM Page 12 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 www.emersonfans.com...
