- Page 1 READ AND SAVE THESE INSTRUCTIONS VERANDA ™ 52” Ceiling Fan Wet Location Owner's Manual Model Numbers CF552AW00 - Summer White CF552GES00 - Golden Espresso CF552ORB00 - Oil Rubbed Bronze 21.60 Net Weight: Lbs. Part No. F40BP73930003 Form No. BP7393-3 U.L. Model No.: CF552...
-
Page 2: Safety Instructions
NOTE: This product is suitable for use in wet locations when installed in a GFCI protection branch circuit. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan. -
Page 3: Tools Needed For Assembly
Emerson Electric Co. Substitution of parts or 2. Remove the fan assembly from the protective accessories not designated for use with this product by Emerson Electric Co. could result in personal plastic bag. Place the fan assembly into the upper injury or property damage. -
Page 4: Electrical Requirements
Electrical Requirements Your new ceiling fan will require a grounded electrical WARNING supply line of 120 volts AC, 60 Hz, 15 amp circuit. The outlet box must be securely anchored and Turning off wall switch is not sufficient. To avoid capable of withstanding a load of at least 50 pounds. - Page 5 4. The blade flanges have an interlocking feature that 9. Remove the three mounting screws from the must be fully engaged before tightening the screw. bracket switch housing assembly (Figure 5). Make sure all the flanges are properly engaged and then tighten the flange screws. If one of the flanges does not seat properly on the motor hub, loosen the adjacent flange screws, re-engage and reseat the flanges, then tighten the screws again.
- Page 6 12. Remove the hanger ball by loosening the 14. Make sure the grommet is properly installed in setscrew in the hanger ball until the ball falls the coupling cover, then slide the coupling cover freely down the downrod (Figure 7). Remove the on the downrod until it rests on the motor pin from the downrod, then remove the hanger housing.
-
Page 7: How To Hang Your Ceiling Fan
How to Hang Your Ceiling Fan 2. Carefully lift the fan and seat the hanger WARNING ball/downrod assembly on the hanger bracket that was just attached to the outlet box (Figure 13). Be The fan must be hung with at least 7' of clearance sure the groove in the ball is lined up with tab on from floor to blades (Figure 11). -
Page 8: How To Wire Your Ceiling Fan
Figure 14 OMITTED FOR CLARITY. LOCKWASHERS THREADED Figure 4 STUDS (2) NOTE: If you are using an Emerson Light Fixture with your fan, see Light Fixture Owner’s Manual KNURLED KNOBS (2) for wiring. Figure 15 2. Securely connect the fan motor white wire to the supply white (neutral) wire using wire connector supplied (Figure 14). -
Page 9: Using Your Ceiling Fan
Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. U.L. Model No.: CF552... -
Page 10: Energy Efficient Use Of Ceiling Fans
If ceiling height allows, install the fan 8 - 9 feet above the floor for optimal airflow. Consult your Emerson Turn Off When Not in the Room. Ceiling fans cool Retailer for optional mounting accessories. -
Page 11: How To Order Repair Parts
Repair Parts Listing Model Numbers Description CF552AW00 CF552GES00 CF552ORB00 Hanger Ball Assembly, 761655-21 761655-35 761655-32 Consisting of: Hanger Bracket — — — Hanger Ball — — — Downrod (4.5”) — — — Parts Bag Containing: 763913-3 763913-3 763913-3 Wire Connector (3) —... -
Page 12: Limited Warranty
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
