SpectraMax iD3 Multi-Mode Microplate Reader Installation Guide

Removing the Transport Locks

Transport locks are placed on the transport slide and the plate drawer to protect the
instrument during shipment.
Required Tools
Illustration
To remove the transport lock:
1. Remove the black cover from the travel lock opening in the center on the rear of the
instrument. This cover prevents high dark counts for Luminescence reads and will be put
back in after the following step.
9
CAUTION! The instrument can be damaged if the transport locks are not removed
before the instrument is powered on.
Part Number
YW 000 006
YW 000 012
CAUTION! Do not touch or loosen screws or parts other than those specifically
designated in the instructions. Doing so could cause misalignment and possibly void
the warranty.
Description
Hex key, 2.0 mm
Holex HEXAGON ballhead bolt driver 3 mm
5054744 C
