General Information

Both the CompacSet
Ophthalmic Set from Welch Allyn are the first diagnostic sets offering a
unique compact handle that houses both the instrument heads and the
power source. The Diagnostic Set comes with an otoscope
How to Open the Set
The instruments are housed inside the door with the long green stripe.
Positioning the Instruments
Once opened, extend the instrument you wish to use
until it locks into its upright position. For
best results, have only one instrument out
at a time. Having both instruments out at
the same time decreases light intensity
and wears down the battery. Once the
instrument is in the up position, it may be
swiveled in a clockwise direction to any
position that is comfortable for the examiner. (If swiveled in a counter-
clockwise direction, the head will unthread for lamp replacement.)
12/7/01
10:58 AM
Page 3
TM
Portable Diagnostic Set and the Portable
and ophthalmoscope while the Ophthalmic
Set is equipped with a retinoscope, oph-
To open the door, simply put your thumb or
your forefinger on top of the green stripe and
pull open.
NOTE: The retinoscope must be tele-
scoped out by pulling in an outward
direction. The retinoscope can only be
used if this operation is performed.
3
thalmoscope and transilluminator.
Both sets have been designed to be
lightweight and highly portable.
Plus, they deliver all the high-quality
performance you expect from Welch
Allyn instruments.
