XM-D9001GTR
Key Features
1300W max power
500W x 1 RMS into 4 ohms
High Level Sensing Power
On
900W x 1 RMS into 2 ohms,
20Hz-100Hz @ 0.6% THD
1300W max power
500W x 1 RMS into 4 ohms
High Level Sensing Power
On
Variable 50 - 300 Hz low pass
filter
40 Hz EQ boost
Specifications
Audio
Frequency Response: 5 - 300 Hz
Noise Level: 93 dB
Power
Power Consumption (in
Operation): 1200 Watts
Output Power: Bridged into 4 ohms,
THD% N/A
Current Drain: 95A
Dimensions
Weight: 11 lbs, 14 oz (5.4 Kg)
Measurements: 10 7/8 x 2 1/4 x 15
7/8" (276 x 57 x 403mm)
UPC Code: 027242686700
MOSFET output stage &
power supply
RCA & speaker level inputs
Line level thru-put
CEA-2006 Power Compliant
900W x 1 RMS into 2 ohms,
20Hz-100Hz @ 0.6% THD
Subsonic filter (15 Hz)
Amplifier
Advertisement
Related Manuals for Sony XM-D9001GTR
Summary of Contents for Sony XM-D9001GTR
- Page 1 XM-D9001GTR Key Features 1300W max power 500W x 1 RMS into 4 ohms High Level Sensing Power 900W x 1 RMS into 2 ohms, 20Hz-100Hz @ 0.6% THD 1300W max power 500W x 1 RMS into 4 ohms High Level Sensing Power Variable 50 - 300 Hz low pass filter 40 Hz EQ boost...
