- Page 1 Audio/Video Grabber and Cables Quick Start Guide...
- Page 2 Package Content Congratulations on purchasing your Optional Cable 1. 1x Audio/Video Grabber Kit for Avaya CU360. This kit extends the features and 2. 1x USB 3.0 cable experience of CU users. It provides an audio-video 3. 1x USB 3.0 adapter Type A/F to Type C/M grabber that allows you to connect a wired computer output to the CU360 as a presentation source.
- Page 3 For further information please use the QR code or link on the Audio-Video Grabber. to the web support guide in page 2 Connect the USB 3.0 cable between the CU360 USB port type A and the Grabber USB port. Note: Avaya suggests to use the provided USB cable...
- Page 4 Grabber Grabber HDMI INPUT USB 3.0 Note: • The mini-jack audio input can be used as CU360 line-in audio (not as microphone). Computer • The mini-jack audio output provides a mix CU360 of line-in and HDMI audio. USB 3.0 adapter type C to type A...
- Page 5 3.0 or is not properly powered. Note: The grabber must be connected to the USB type USB 3.0 A of the CU360; the USB-C to USB-A adapter is suitable Computer to connect USB disks or control devices, such as CU360 keyboard, mouse and touch screen.
- Page 6 Experiences that Matter. Visit us at www.avaya.com. © 2021 Avaya Inc. All Rights Reserved. Avaya and the Avaya logo are trademarks of Avaya Inc. and are registered in the United States and other countries. All other trademarks identified by ®, TM, or SM are registered marks, trademarks, and service marks, respectively, of Avaya Inc.
- Page 7 700514973...
