- Page 1 Model No. MT4010 Owner’s Manual MITER SAW STAND QUESTION... 1•847•780•6120 Visit us on the web at powertecproducts.com You will need this manual for safety instructions, operating procedures, and warranty. Put it and the original sales invoice in a safe, dry place for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRODUCT SPECIFICATIONS SECTION PAGE SAFETY RULES Net Weight..............33.6 lbs Weight Capacity At 32-3/8" setting ...........440 lbs ASSEMBLY At 26-7/16" setting ..........330 lbs Unpacking Extruded Bed ......9-3/8" wide x 34-1/8" long Tools Needed Height Top of Bed ..........33-19/50" Assemble Wheels Mounting Bracket ........1-13/16"... -
Page 3: Safety Rules
SAFETY RULES • Dress properly. Do not wear loose clothing or jewelry. WARNING Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught For your own safety, read all of the rules and precautions in moving parts. -
Page 4: Assembly
ASSEMBLY UNPACKING WARNING Refer to Figure 1 Check for shipping damage. Check immediately that all Do not use the miter saw stand for scaffolding or as parts and accessories are included. a ladder. Make sure to securely tighten all fasteners before using. -
Page 5: To Raise The Stand
MOUNTING THE MITER SAW • Depressing the side of the wheel bracket with the unlock symbol to unlock the wheel. Refer to Figure 6-7 Figure 3 WARNING Risk of accidental starting and serious personal injury. Unplug the miter saw and lock the head down before attaching it to the miter saw stand. -
Page 6: Operation
Figure 7 WARNING Hook to Rail Risk of serious personal injury. Always make sure the miter saw is fully supported and securely attached to a level work surface. Make sure the miter saw stand is located on a flat surface. Front of Saw •... -
Page 7: Transportation
TRANSPORTATION Handle Figure 11 Quick Release Knob Refer to Figure 10–12 WARNING Risk of unsafe operation. Ensure proper footing and use caution when rolling the miter saw stand to prevent tipping or loss of balance. • The miter saw stand can ONLY be rolled from one location to another with the miter saw mounted. -
Page 8: Maintenance
MAINTENANCE ADJUST QUICK RELEASE BRACKET GENERAL MAINTENANCE Refer to Figure 12 WARNING The quick release mounting brackets must be secure on When servicing, use only identical replacement parts. the miter saw stand. If adjustment is needed: Use of any other parts may create a hazard or cause Turn the adjusting nut on the adjustment screw clockwise product damage. -
Page 9: Warranty
30- DAY SATISFACTION GUARANTEE POLICY During the first 30 days after the date of purchase, if you are dissatisfied with the performance of this POWERTEC tool for any reason, you may return the tool to the retailer from which it was purchased for a full refund or exchange. You must present proof of purchase and return all original equipment packaged with the original product. -
Page 10: Parts Illustration
MITER SAW STAND PARTS ILLUSTRATION... - Page 11 MITER SAW STAND PARTS LIST Key# Part# Description Specifications Qty Key# Part# Description Specifications Qty MT4010039 Slide Base PA6+30%GF MT4010001 Work Frame (Middle) MT4010040 Slider Welding MT4010002 Work frame (left) MT4010041 Down Sliding Base PA6+30%GF MT4010003 Work Frame (Right) MT4010042 Compression Spring MT4010004 Heterotype Nut...
