PowerTec 71035 Instruction Sheet

INSTRUCTION SHEET
Table Saw Taper Jig
WARNING
For your own safety, read the table saw instruction manual
before using this accessory. Failure to heed these warnings
may result in personal injury and serious damage to the
table saw and the accessory.
WARNING
Always follow proper operating procedures as defined in
this manual even if you are familiar with use of this Taper
Jig. Remember that being careless for even a fraction of a
second can result in severe personal injury.
You must be familiar with the use of any tool or accessory
used with this Taper Jig. The supplier cannot be held
responsible for any accident, injury or damage incurred
while using this Taper Jig with any tool.
WARNING
Some dust created by operation of power tool contains
chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm. To reduce your
exposure to these chemicals, work in a well ventilated
area and work with approved safety equipment. Always
wear OSHA/NIOSH approved, properly fitting face mask or
respirator when using such tools.
CAUTION
Do not modify or use this Taper Jig for any application other
than that for which it was designed.
SAFETY RULES
• Disconnect plug of power tool from power source before
changing accessories. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
• Always keep your hands away from the cutting area and
be aware of the blade at all times. Use a push block
when needed.
• It is the sole responsibility of the purchaser of this tool to
ensure that anyone using this Taper Jig reads and agrees
to all the safety precautions outlined in this manual and the
table saw's manual prior to using the tool.
• The Taper Jig is intended only for use on table saws.
• Keep the saw blade as low as possible to make the cut as
specified by your saw's instruction manual.
• Before making the actual cut, become familiar with the
cutting process by practicing the motion of the cut with the
blade lowered and the power turned off.
• Use adequate outfeed support when cutting long pieces.
• The Taper Jig handle must be installed when making all
taper or straight line cuts.
• The Taper Jig must be used with table saw fence when
making cuts.
• The work stop on the Taper Jig must be used during cuts.
Make sure all fasteners are tight.
CAUTION
Think safety! Safety is a combination of operator common
sense and alertness at all times when Taper Jig is
being used.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
UNPACKING CONTENTS
NOTE: Check for shipping damage. Check immediately
whether all parts and accessories are included.
ITEM DESCRIPTION
A
Taper Jig
B Handle
C Knurled Knob
D
Washer
E Work Stop
F Nuts 3/16"
G
Screw 3/16"
Figure 1
ASSEMBLE THE TAPER JIG
NOTE: The handle and work stop can be assembled for left
and right side use.
• Assemble Knurled Knob and washer through the gauge and
into the threaded hole in the Taper Jig.
• Thread the handle into the correct threaded hole for left or
right side use. Tighten securely.
• Assemble the work stop in the correct mounting holes for
left or right side use. Make sure the hardware is tightened.
Model No. 71035
QTY
1
1
1
1
1
2
2
Refer to Figure 1
25-0102
